Brief descriptions follow for the first-level configuration menu options:
•
QUICK SETUP — These options allow quick access to the most
frequently changed or inputted parameters during the installation of the
printer.
•
ZTP SETTINGS These options allow you to set parameters for zero tear
pedestal printers.
•
CONFIG. CONTROL — These options allow you to save, print, load,
delete, name, and reset entire sets of configuration parameters.
•
HOST INTERFACE — These options allow you to select either the Serial
RS-232, Serial RS-422, Centronics
Long Lines, Ethernet
Twinax interface for the printer. This menu also allows you to configure
several parameters for each interface.
•
NETWORK SETUP — This option allows you to select from Ethernet
Address options and Ethernet Parameters options.
•
ACTIVE (IGP) EMUL — This menu allows you to select the PGL or VGL
emulation from the menu if IGP is installed.
•
ACTIVE EMULATION — This menu allows you to activate the desired
emulation to be used with your printer.
•
EMULATION — This menu allows you to configure the options which are
available for the current operating (active) emulation. For example, if
LinePrinter+ is the active emulation, then the LinePrinter+ emulation
options can be configured using this menu.
•
PRINTER CONTROL — This menu allows you to select parameters
common to a general user, such as display language and Barcode
quality.
•
ADVANCED USER — This menu allows you to select several advanced
operating parameters for the printer, such as the speed at which paper
will advance when slewing.
•
DIAGNOSTICS — This menu includes the diagnostic tests, system
memory, and statistics of the printer.
•
DATE – This menu allows you to set the printer's real time clock. The
parameters include hours, minutes, year, month, and day.
•
Printer MGMT – These options allow you to select the PNE port type,
port number, port timeout period, status port number, and management
port number.
®
parallel, Dataproducts
™
®
, IEEE
1284 parallel, Auto Switching, Coax or
®
parallel and
61
