Saturation tool (LCH Mode Only)

Saturation tool allows you to optimize image by manipulating the Saturation
Curve Curve Curve while correcting the chroma channel of the LCH at the same time. Full
Curve Curve
range effect is the default, while options to saturate highlight, midtone, or
shadow area only, are also available.

The Saturation dialog box

Dragging the curve (or line) above the default
diagonal line will create a result color with
luminance & hue of the base color (relative to the
selected Range)
Dragging the curve (or line) below the default
diagonal line will de-saturate color into gray level
Click to revert to the
default Scan Wizard
Pro default setting
76 Microtek ScanWizard Pro for Windows
Click to revert to the
custom setting defined
right after recent start up
Saturation Saturation Saturation
Saturation
Select Saturation method.
"Curve" is the
default
Enable this check box to show
simulated effect of the adjust-
ment made on the prescan
Select Saturation Range. "All"
is the default
Coordinates information of
cursor position within the
grids
Click to save current custom
(curve) parameters in
Saturation preset settings
