The Settings Window

The Settings window contains the parameters for outputting your scanned
image for the current scan job and includes the advanced image correction tools
of the program.
Resolution edit
box: Lets you enter
a resolution value in
which your image will
be output (not
scanned).
Image Dimension
controls: include
various parameters
for specifying scan
frame width and
height, scaling,
output width and
height, and unit of
measurement.
Elements of the Settings window
Type menu: Lets you
select the image type in
which your image will be
scanned and
processed.
Unit selection: Lets
you choose the unit of
measurement for
resolution in either ppi
(pixel per inch) or lpi
(lines per inch).
Advanced Image
Correction tools:
Improve image quality
by enhancing image
characteristics such as
brightness and contrast,
white and black points,
and others.
Reference: The Settings Window 49
