The Dynamic Range dialog box

By default, this tool automatically determines the lightest density or tone (Dmin)
and darkest tone (Dmax) of the original; then it captures the image color data
(histogram area) with the full input tonal range of the scanner. This setting
optimizes color balance and the contrast of the output image, and is most useful
for scanning negative films. You can override the auto-settings by defining your
own custom dynamic range (Dmin/Dmax) values to all or each individual RGB
channels. Manual setting tools are provided in the AIC Dynamic Range
box shown below.
Access to
other AIC tools
Drag sliders to
define custom
Dmin/Dmax
settings
Enter custom
Dmax setting
here
Enter custom
Dmin setting
here
Click to revert to the
Scan Wizard Pro
default setting
Click to apply or revert to
automatic setting (Scan-
Wizard Pro algorithm) when
dissatisfied with manual
64 Microtek ScanWizard Pro for Windows
Click to revert to
the custom setting
defined right after
current start up
setting
"Automatic" is
checked & will
display to indicate
auto setting is on
when the Auto
button is clicked
Click to auto-
matically or
manually balance
all RGB channels
Click to auto-
matically or
manually balance
individual RGB
channel
Click to save and add
the current custom
setting to Dynamic
Range pre-set
settings
Dynamic Range dialog Dynamic Range Dynamic Range
Dynamic Range
Click to auto-
matically apply the
full range setting
"Custom" is
checked & will
display to indicate
manual setting is
on when the Dmin
or Dmax is
manually adjusted
Click to delete
saved custom
Dynamic Range
settings (if any)
from folder
Observe histogram
density values at cursor
position as it is swept
around the histogram
