Denon AVR-4310CI Owner's Manual page 42

Making Detailed Settings (Manual Setup)
Setting items
EQ Customize Audyssey Byp. L/R : Set when not using the "Audyssey Byp L/R"
Set so that unused equalizer equalizer.
settings are not displayed • Used : Use.
[MULTEQ XT]
when is • Not Used : Do not use.
pressed.
Set so that the "Audyssey Byp. L/R" settings can be made when the
Audyssey Auto Setup procedure is performed.
Equalizer settings for which Audyssey Flat : Set when not using the "Audyssey Flat" equalizer.
• Used : Use.
"Not Used" is set with the
• Not Used : Do not use.
Quick Select function cannot
be stored and called out.
Set so that the "Audyssey Flat" settings can be made when the
Audyssey Auto Setup procedure is performed.
Manual : Set when not using the "Manual" equalizer.
• Used : Use.
• Not Used : Do not use.
Making the Network Settings (Network Setup)
Make network settings.
Setting items
Network Connecting
1. Connect the LAN cable (vpage 23 "Connecting to a Home Network
Make settings for wired (LAN)").
LAN. 2. Turn on the AVR-4310CI (vpage 24 "Turning the Power On").
AVR-4310CI performs automatic network setup due to the DHCP
function.
When connecting to a network that has no DHCP function, perform the
setting in step 3.
3. Set the IP address at the "Network Connecting".
NETWORK CONNECTING
DHCP
IP Address
Exit
Detail
Set IP address and proxy manually

Main remote control
operation buttons
Setting contents
Default settings are underlined.
Setting contents
NETWORK CONNECTING
w
DHCP OFF
ON IP Address 192 . 168 . 100 . 033
192.168.100.33 Subnet Mask 255 . 255 . 255 . 000
Default Gateway 000 . 000 . 000 . 000
Primary DNS 000 . 000 . 000 . 000
Secondary DNS 000 . 000 . 000 . 000
Proxy
Exit
r
q
Enter
RETURN
Set IP address manually
:Displaying the menu
Cancel the menu
Setting items
Network Connecting
Make settings for wired
LAN.
b
•
•
•
•
•
e
Cancel
:Moves the cursor
:Confi rm the setting
(Up/Down/Left/Right)
Setting contents
q On the GUI menu, select "Network Connecting" – "Detail" and
ENTER
press .
w Use o p to set "DHCP" to "OFF", then press
The DHCP function is disabled.
e Use uip to input the address and press
• IP Address : Set the IP address within the ranges shown below.
The Network Audio function cannot be used if other IP addresses
are set.
CLASS A: 10.0.0.0 ~ 10.255.255.255
CLASS B: 172.16.0.0 ~ 172.31.255.255
CLASS C: 192.168.0.0 ~ 192.168.255.255
• Subnet Mask : When connecting an xDSL modem or terminal
adapter directly to the AVR-4310CI, input the subnet mask
indicated in the documentation supplied by your provider. Normally
input 255.255.255.0.
• Default Gateway : When connected to a gateway (router), input
its IP address.
• Primary DNS, Secondary DNS : If there is only one DNS address
indicated in the documentation supplied by your provider, input it
at "Primary DNS". If there are two or more DNS addresses, input
the fi rst one at "Secondary DNS".
ENTER
r Use i to select "Exit" and press
Setup is complete.
When connecting to the network via a Proxy server, select "Proxy" and
ENTER
press (vpage 40 "Proxy settings").
If you are using a broadband router (DHCP function), there is no need
to make the settings at "IP Address" and "Proxy", since the DHCP
function is set to "ON" in the AVR-4310CI's default settings.
If the AVR-4310CI is being used connected to a network without the
DHCP function, the network settings must be made. In this case, some
knowledge of networks is required. For details, consult a network
administrator.
If you cannot connect to the Internet, recheck the connections and
settings (vpage 23).
If you do not understand about Internet connection, contact your ISP
(Internet Service Provider) or the store from which you purchased your
computer.
When you want to cancel the setting during IP address input, press
RETURN
.
:Return to previous menu
i .
ENTER
.
.
See overleaf
