A.3.9

Ku-Band 1:1 Redundancy Switch/Waveguide Kit (Comtech P/N KT/12337-1)

Table A-12. Ku-Band 1:1 Redundancy Switch/Waveguide Kit (Comtech P/N KT/12337-1) Parts List

ITEM
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
Appendix A
QTY Comtech P/N
1 SW/WGS+28V-75SB
1 RF/TERM75/350W
1 FP/BR12338-1
1 FP/WG11934-1
1 FP/WG11935-1
2 HW/3/8SPRINGNUT
2 HW/3/8-FLT
2 HW/3/8-SPLIT
2 HW/3/8-16X1BLT
20 HW/6-FLT
20 HW/6-SPLIT
4 HW/6-32X7/8SHCS
16 HW/6-32X1/2SHCS
2 GA/WR75-R-F-C
4 GA/WR75-R-H-C
1 FP/SP12360-1
4 HW/4-FLT
4 HW/4-SPLIT
4 HW/440X3/8SHCS
DESCRIPTION
Switch, Waveguide
Waveguide, Termination
Bracket, Mounting (ROHS)
Waveguide, Left
Waveguide, Right
Springnut
Washer, Flat
Washer, Split
Bolt, Hex-Head
Washer, Flat
Washer, Split
Screw, Cap
Screw, Cap
Gasket, Full-Thickness
Gasket, Half-Thickness
Spacer (ROHS)
Washer, Flat
Washer, Split
Screw
A–30
