4-38 Features description
Table 4-17xxx
Consultation state
(continued)
Action Responses
Hold Notify line remains blank. Both the
consulting party and the originating party
are put on Hold. If the originating party is
at a DN icon, this DN icon winks.
Digits End-to-end signaling takes place, and user
receives the EES tone until digit is
released. Notify line echoes digits entered.
Switch Parties Puts originating party on Hold and returns
(Consult) to consulting party. If the originating party
is at a DN icon, this icon winks. Notify line
displays: the consulting party's DN.
Digits End-to-end signaling takes place, and user
receives the EES tone until digit is
released. Notify line echoes digits entered.
Join Parties Sends Switch Parties and Complete to the
Meridian SL-100. Meridian SL-100 does
not support Complete in Consultation Hold
state
Hold Notify line remains blank. Both the
consulting party and the originating party
are put on Hold. If the originating party is
at a DN icon, this DN icon winks.
Table 4-18xxx

Intercom dial state

Action Responses
INTERCOM DIAL TONE State (Figure 4-8)
Directory If directory is Locked, the Unlock screen
prompts user to enter a password.
If the directory is not locked, displays a
maximum of 12 quick-access entries from
the user's directory.
555-4001-112 Standard 05.01 March 1995
-end-
-continued-
Next Screen/State
Idle
No change
Consultation
No change
(a) Consultation
(b) Active
Idle
Next Screen/State
Unlock
Directory Page 1
