4-14 Features description
Table 4-5xxx
Programmable touch position functions
Telephone State
Activating Ring Again when a
busy DN is reached
Ring Again Notification
indicates that the dialed DN is
available
Note 1: If the DTE is set to Automatic Answer, all data calls are answered automatically by the
terminal. If the DTE is on but not set to Automatic Answer, the incoming data call can be connected
by touching the Y and the Carriage Return on the keyboard.
Note 2: Activating Ring Again when the Ring Again is already in effect for a previous call causes
the previous Ring Again to be canceled. Ring Again is canceled by touching the CANCEL RING
AGAIN touch position on the RING AGAIN screen, which is accessed by touching the RING AGAIN
position on the IDLE screen.
Table 4-6xxx

Feature touch positions description

Feature

Call Forward
Call Park
Call Pickup
Call Waiting
Call Transfer
Data Call
Make Set Busy
Conference 6
Message Waiting
555-4001-112 Standard 05.01 March 1995
(continued)
Text Displayed On Screen
Notify line displays the dialed
DN and the BUSY screen is
displayed.
Prompt line displays
CONNECT RING AGAIN
CALL? and bar line displays
CONNECT touch position.
-end-
-continued-
Possible Actions
Touch RING AGAIN position
to activate Ring Again.
If the M3000 Touchphone is
active on another DN, place
the current call on hold and
touch CONNECT to connect
the Ring Again call. If the
M3000 Touchphone is idle,
touch CONNECT to connect
the call.
Touch Position Description
FORWARD
PARK
CONNECT
TRANSFER
DATA LINE
MAKE BUSY
CONFERENCE
MESSAGE
PRIVACY OFF
