3-2 Performance specifications
The maximum loop length assumes no under-carpet cable. With
under-carpet cable, the maximum allowable loop length must be reduced
using the following equation:
LM = (14 - (UC x UL)) / 14
where:
•
•
•

Data characteristics

The TADO communicates with Data Terminal Equipment (DTE) using the
characteristics listed in Table 3-2.
Table 3-2xxx

TADO data characteristics

Characteristic
Data type
Synchronization
Number of bits
Parity
Data rate
Stop bits
Datamode
555-4001-112 Standard 05.01 March 1995
LM = loop length in ft (km)
UC = length of the under-carpet cable in ft (km)
UL = loss of the under-carpet cable in dB/ft (dB/km) at 256 kHz
Specification
ASCII (ANSI standard X3.4-1977)
Asynchronous
7 bits plus parity or 8 bits no parity
None, odd, or even
110, 150, 300, 600, 1200, 2400, 4800,
9600, or 19200 bits per second
1 bit for all speeds
Full Duplex
