Procedure 6-2 (continued)
Installing the Internet BWA System 3200 on a pole
Step
15
Figure 6-6
Antenna installation (2 of 2)
Mount the ODU
16
Action
Use the antenna mounting bolts in four places to hold the antenna to the
mounting assembly (see
perfrom the alignment procedures
Antenna
mounting
bolts
Insert the ODU screws into the ODU mounting slots and twist the ODU
completely counterclockwise (see
Installation and commissioning procedures 6-11
Figure 6-6). Do not tighten the bolts completely to
Figure 6-5 on page
—continued—
User guide NTXXXXXX Rel 3.0 Draft October 2000
MOP0095p.eps
Antenna
mounting
bolts
Azimuth
adjustment
plate
Part of U-bolt
6-10).
