Video input — S-video (SMX 84/88/1616 SV, SMX 84/88/1616 YC)
Number/signal type ..................... 8 or 16 S-video, composite video
Connectors
SMX 84/88/1616 SV ......... 8 or 16 female 4-pin mini DIN
SMX 84/88/1616 YC ......... 8 or 16 x 2 female BNC
Nominal level ................................ 1 Vp-p for Y of S-video
Minimum/maximum levels ........ Analog: 0.1 V to 2.0 Vp-p with no offset
Impedance ...................................... 75 ohms
Return loss ...................................... <-40 dB @ 5 MHz
DC offset (max. allowable)........... 1.0 V
Video output — S-video (SMX 84/88/1616 SV, SMX 84/88/1616 YC)
Number/signal type ..................... 4, 8, or 16 S-video, composite video
Connectors
SMX 84/88/1616 SV ......... 4, 8, or 16 female 4-pin mini DIN
SMX 84/88/1616 YC ......... 4, 8, or 16 x 2 female BNC
Nominal level ................................ 1 Vp-p for Y of S-video
Minimum/maximum levels ........ 0.1 V to 2.0 Vp-p (follows input)
Impedance ...................................... 75 ohms
Return loss ...................................... <-40 dB @ 5 MHz
DC offset ......................................... ±5 mV with input at 0 offset
Sync — S-video (SMX 84/88/1616 SV, SMX 84/88/1616 YC)
Standards ........................................ NTSC 3.58, NTSC 4.43, PAL, SECAM
Video — wideband (SMX 84/88/1616 WB)
Routing
SMX 84 WB ......................... 8 x 4 matrix
SMX 88 WB ......................... 8 x 8 matrix
SMX 1616 WB ..................... 16 x 16 matrix
Gain ................................................. Unity
Bandwidth ...................................... 400 MHz (-3 dB), fully loaded
Crosstalk
8x8 ....................................... -82 dB @ 1 MHz, -72 dB @ 5 MHz, -68 dB @ 10 MHz, -61 dB @ 30 MHz,
16x16 ................................... -74 dB @ 1 MHz, -64 dB @ 5 MHz, -56 dB @ 10 MHz, -48 dB @ 30 MHz,
Switching speed ............................ 200 ms (max.)
Video input — wideband (SMX 84/88/1616 WB)
Number/signal type ..................... 8 or 16 VGA-QXGA RGBHV, RGBS, RGsB, RsGsBs, HDTV, component
Connectors ..................................... 8 or 16 female BNC
Nominal level ................................ 0.7 Vp-p for RGB
Minimum/maximum levels ........ Analog: 0.3 V to 1.5 Vp-p with no offset
Impedance ...................................... 75 ohms
Horizontal frequency .................... 15 kHz to 150 kHz
Vertical frequency .......................... 30 Hz to 150 Hz
Return loss ...................................... <-30 dB @ 5 MHz
DC offset (max. allowable)........... 1.0 V
0.3 Vp-p for C of S-video
0.3 Vp-p for C of S-video
-53 dB @ 100 MHz
-38 dB @ 100 MHz
video, S-video, composite video, S/PDIF digital audio (not reclocked)
SMX System MultiMatrix Switchers • Reference Information
B-3
