Safety Outputs - Omron DeviceNet DST1 Series Operation Manual

1-3 Functions
1-3-4

Safety Outputs

Item
Output channel Any of the following three modes can be selected according to the external input
mode device.
Dual channel The consistency between signals on two channels can be evaluated. Either of the
mode following settings can be selected.
Output error latch The OFF status is held for at least the output error latch time (0 to 65,530 ms, in
time increments of 10 ms) when the individual safety output status turns OFF.
Short-circuit Supported.
detection
Overcurrent Supported.
detection
1-10
Not Used The safety output is not used.
(External output device not connected.)
Safety Specifies not outputting the test pulse when the output is ON.
Contact between the output signal line and the power supply
(positive) when the output is OFF and ground faults can be
detected.
Safety Pulse Test Outputs the test pulse when the output is ON. Contact
between the output signal line and the power supply, and short
circuits with other output signal lines can be detected.
Single Channel Specifies using Single Channel Mode. When Single Channel
is set, the safety output that would be paired for the dual
channel parameter is also set to Single Channel Mode.
Dual Channel Specifies using Dual Channel Mode. When both of the safety
outputs to be paired are normal, the outputs can be turned
ON.
