Section 9: Quick Reference Guide
System Diagnosis
To clear an active alarm, press the ENTER button twice and then press AUTO. If the alarm reoccurs, contact an
Independent Authorized Service Dealer.
Active Alarm LED
NONE GREEN
HIGH RED
TEMPERATURE
RPM SENSE LOSS RED
LOW OIL RED
PRESSURE
RPM SENSE LOSS RED
OVERCRANK RED
NO LEDs LIT None
OVERSPEED RED
UNDERSPEED
UNDERVOLTAGE RED
MISWIRE RED
BATTERY YELLOW
PROBLEM
CHARGER YELLOW
WARNING
Installation Guidelines for 50 Hz PowerPact™
Table 9-1. System Diagnosis
Problem Things to Check
Unit running in AUTO but Check MLCB.
no power in house.
Unit shuts down during Check the LED's /
operation. Screen for alarms.
Unit was running and Check the LED's /
shuts down, attempts to Screen for alarms.
restart.
Unit will not start in Check the LED's /
AUTO with utility loss. Screen for alarms.
Unit will not start in Check the LED's /
AUTO with utility loss. Screen for alarms.
Unit will not start in Check the LED's /
AUTO with utility loss. Screen for alarms.
Unit will not start in Check the LED's /
AUTO with utility loss. Screen for alarms.
Unit will not start in Check the LED's /
AUTO with utility loss. Screen for alarms.
Unit will not start in Check the LED's /
AUTO with utility loss. Screen for alarms.
Unit will not start in Check the LED's /
AUTO with utility loss. Screen for alarms.
Yellow LED illuminated in Check the screen for
any state. additional information.
Yellow LED illuminated in Check the screen for
any state. additional information.
Quick Reference Guide
Solution
Check MLCB. If it is in the ON position,
contact an Independent Authorized
Service Dealer.
Check ventilation around the generator,
intake, exhaust and rear of generator. If no
obstructions exist, contact an Independent
Authorized Service Dealer.
Clear alarm and remove household loads
from the generator. Put back in AUTO and
restart. If generator does not start, contact
an Independent Authorized Service Dealer.
Check oil level / add oil per Owners
Manual. If oil level is correct, contact an
Independent Authorized Service Dealer.
Clear alarm. Using the control panel, check
the battery by navigating to the BATTERY
MENU option from the MAIN MENU. If it
states battery is GOOD, contact an
Independent Authorized Service Dealer. If
it states CHECK BATTERY, replace the
battery.
Check fuel line shutoff valve is in the ON
position. Clear alarm. Attempt to start the
unit in MANUAL. If it does not start or starts
and runs rough, contact an Independent
Authorized Service Dealer.
®
Check ATO 7.5 Amp ATO
with same type fuse if bad. Contact
Independent Authorized Service Dealer if
fuse is good.
Contact Independent Authorized Service
Dealer.
Contact Independent Authorized Service
Dealer.
Contact Independent Authorized Service
Dealer.
Contact Independent Authorized Service
Dealer.
Contact Independent Authorized Service
Dealer.
fuse. Replace
