Site Selection and Preparation
Transportation Recommendations
1. Use a two wheeled hand cart or metal rails to carry
the generator (including the wooden pallet) to the
installation site. Place cardboard between the hand
cart and the generator to prevent any damage or
scratches to the generator.
2. Remove bolts from the pallet brackets (A).
Figure 3-5. Generator on Pallet
3. Lift the generator from the wooden pallet.
NOTE: Be extremely careful when removing the
generator from the pallet. Dragging it off the pallet WILL
damage the base!
4. Unhook and remove the brackets from the
generator.
14
A
001121
Installation Guidelines for 50 Hz PowerPact™
