Redundant 1:1 With Load Switching
1+1 With Soft Fail
Initial Turn On
MNC-0400-048
EAR EXPORT CONTROLLED: The information contained in this Manual refers or relates to a product that is subject
to the U.S. Export Administration Regulations (EAR). Transfer of data herein by any means to a Foreign Person,
whether in the U.S. or abroad, may require an export license from the U.S. Department of Commerce.
This configuration provides another level of switching. Either the
online amplifier, the backup amplifier, or both amplifiers may be
fed to a dummy load. This ability allows you to perform
maintenance on both amplifiers at the same time.
The load switch is not part of the automatic switching capability.
It must be selected manually.
This configuration may be used as a Redundant 1:1 or Power
Combined Redundant System.
In 1:1 Redundant the online amplifier is switched to bypass the
hybrid combiner. When the online amplifier faults the automatic
switching will act on both switches to switch the backup amplifier
online.
In Power Combined Redundant the two amplifier outputs are
combined through the hybrid combiner and the output is
switched online. When one of the amplifiers faults the other
amplifier will be switched online bypassing the hybrid combiner.
After the switching occurs, the output level will only decrease by
3 dB (Soft Fail.)
In order to ensure proper operation of the amplifier perform the
Preturn On Procedure before you turn on the amplifier for the
first time.
Ensure that all of the following instructions are followed.
Failure to comply could result in permanent damage to
the amplifier.
Stellen Sie sicher, dass alle folgenden Anweisungen
befolgt werden. Nichtbeachtung kann bleibende
Schäden am Verstärker verursachen.
5 of 14
Operation, TWTA ODU Amplifier
Caution
Vorsicht
Revision B
