Administration using the CLI
CLI System Administration menu
To access the CLI System Administration menu from the CLI Main Menu, enter sa, SA, or
the full command SAdmin.
the CLI System Administration menu and all the accessible submenus.
Figure 13: CLI System Administration menu
System Attributes Editor
Use this menu to modify system attributes as follows:
• Card name – a character string with maximum length of 10 characters. The name appears
at the top of the MIVS BUI Login window, if a name is specified.
• Agent ID – default is not defined. If necessary, enter the same information defined in the
system software.
• Subnet mask – has XXX.XXX.XXX.XXX format, where every XXX is in the range 0–255.
The subnet mask in binary presentation of 32 bits has at least the first eight digits as 1
and the last digit as 0.
• Gateway address – has XXX.XXX.XXX.XXX format, where every token is in the range
0–255.
• IP address – the Ethernet IP address; has the same format as the gateway address.
Example:
login: user
Previous user login: Feb 11, 1997 10:00
SAdmin, SMaint, PAdmin, PMaint, LOgout, ?: sa
SYstem, ?: sy
78
Hospitality Integrated Voice Services Fundamentals
Figure 13: CLI System Administration menu
Comments? infodev@avaya.com
on page 78 illustrates
March 2013
