I/O Specifications - Omron SYSMAC CPM2B Operation Manual

Specifications
2-1-3

I/O Specifications

CPU Board Input Specifications
Item
Input voltage All
Input impedance IN00000 to IN00001
IN00002 to IN00006
IN00007 and up
Input current IN00000 to IN00001
IN00002 to IN00006
IN00007 and up
ON voltage/current IN00000 to IN00001
IN00002 and up
OFF voltage/current All
ON delay All
OFF delay All
Circuit configuration IN00000 to IN00001
IN00002 to IN00006
IN00007 and up
Note
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Inputs
+10%
24 V DC
2.7 kΩ
3.9 kΩ
4.7 kΩ
8 mA typical
6 mA typical
5 mA typical
17 V DC min., 5 mA
14.4 V DC min., 3 mA
5.0 V DC max., 1 mA
1 to 80 ms max. Default: 10 ms (See note.)
1 to 80 ms max. Default: 10 ms (See note.)
1. The input time constant can be set to 1, 2, 3, 5, 10, 20, 40, or 80 ms in the
PLC Setup. See page 84.
2. The value in parentheses shows the resistance for the CPM2B-32C@D1T-
D12.
Specification
/ 12 V DC
–15%
1.5 kΩ
2.0 kΩ
2.4 kΩ
8 mA typical
6 mA typical
5 mA typical
9.5 V DC min., 5 mA
8.0 V DC min., 3 mA
IN
2.7 kΩ
0.01 µF
(1.5 kΩ)
IN
680 Ω
COM
IN
3.9 kΩ
IN
750 Ω
(2.0 kΩ)
COM
IN
IN 4.7 kΩ
750 Ω
(2.4 kΩ)
COM
Section 2-1
+10%
/
–15%
Input LED
Internal
circuits
Input LED
Internal
circuits
Input LED
Internal
circuits
27
