Analog I/O Boards - Omron SYSMAC CPM2B Operation Manual

System Configurations
1-2-3

Analog I/O Boards

Analog input
Input signal Number of
range inputs
0 to 5 V, 1 to 5 V, 0 6 points
to 10 V, −10 to
10 V, 0 to 20 mA,
and 4 to 20 mA
4 points
2 points
10
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Analog I/O Boards are Expansion Boards that have built-in analog input and
output functions. Up to three Analog I/O Boards with a maximum of eight ana-
log inputs and four analog outputs can be connected to a single CPU Board.
For further details on the number of Analog I/O Boards that can be connected,
refer to 3-1-4 Number of Expansion Boards.
Analog output
Output signal Number of
range outputs
1 to 5 V, 0 to 10 V, 3 points
−10 to 10 V, 0 to
20 mA, and 4 to
20 mA
2 points
1 point
Resolu- Model
tion
6,000 CPM2B-MAD63 Input: 6
CPM2B-MAD42 Input: 4
CPM2B-MAD21 Input: 2
Section 1-2
Allocated Maximum
words number of
Boards
1
words
Output: 3
words
2
words
Output: 2
words
3
words
Output: 1
words
