Board Components and their Functions

2-2

Board Components and their Functions

2-2-1

CPU Board Components

CPM2B-32C@DR-D 32-point CPU Boards with Relay Outputs
8. RS-232C port
4. PLC status indicators
7. Peripheral port
9. Communications Switch SW201
CPM2B-40C2DR-D 40-point CPU Boards with Relay Outputs
9. Communications Switch SW201
9. Communications Switch SW202
8. RS-232C port
7. Peripheral port
13. Battery
34
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
1. Power supply terminals
13. Battery
1. Power supply terminals
9. Communications Switch SW202
10. Analog settings
11. DIP Switch inputs
2. Input connector
5. Input indicators
12. Expansion I/O connector
6. Output indicators
3. Output terminals
10. Analog settings
2. Input connector
4. PLC status indicators
5. Input indicators
12. Expansion I/O connector
6. Output indicators
3. Output terminals
Section 2-2
