4.15 Replacement of brake resistor bleeder

Location
The following illustration shows the location of the brake resistor bleeder.
xx1400001457
A
B
C
Required equipment
Equipment
Brake resistor bleeder
Standard toolkit
Removal
Use the following procedure to remove the line filter.
1
Product manual - IRC5 Compact
3HAC047138-001 Revision: G
Bleeder
Fan cover
Attachment screws
Action
DANGER
Before commencing any work
inside the cabinet, please ob-
serve the safety information in
section DANGER - Make sure
that the main power has been
switched off! on page 33.
© Copyright 2009-2017 ABB. All rights reserved.
4.15 Replacement of brake resistor bleeder
A
Note
See Miscellaneous parts on page
The content is described in section
IRC5 on page 207.
Note/illustration
Continues on next page
4 Repair
B C
212.
Standard toolkit,
175
