Page 3: Introduction
Your printer is the IP-5630/5530 Color Inkjet Printer (hereafter simply called the printer.) The IP-5630 and IP-5530 printer models are color inkjet printers using solvent ink and equipped with USB 2.0 interface. They support media up to 64 inches in width and 54 inches in width respectively.
Page 4 To maintain an excellent print quality Be sure to pay attention to the following three points to maintain an excellent print quality and use the printer over a long time. (1) Load the media correctly (2) Adjust the media advance adjustment value and the bidirectional print value properly (3) Perform the necessary maintenance operations...
Page 5 If the media is not set correctly… The media may skew or contact the print heads, which will decrease the print quality. Media jam caused by skewed media Incorrect winding <Examples> Colors on the right and left The printout is not clean due to di er due to skewed media.
Page 6 2. Adjust the media advance adjustment value and the bidirectional print value properly Media advance Bidirectional print positions page 72 page 72 If these adjustment operations are not performed when using a new media… The ink may not be output to the right position and the print quality may decrease. <Examples>...
Page 7 3. Perform the necessary maintenance operations Clean the capping unit. Check the wiper cleaning liquid. Good page 112 page 104 If the printer is used when not clean… The print quality may not only decrease but the printer may also malfunction. The capping unit is dirty.
Page 8 Starting out... Connect to a computer. Turn on the power. page 35 page 32 Replace the ink cartridge (CIS). Load the roll media. page 201 page 40 Register the media. Replace the media. Media name Head height Color stripe Media advance adjustment value page 44 page 53 Turn o the power.
Page 9 Regular Inspection (Maintenance) Check the Waste ink bottle. Check the wiper cleaning liquid. Good page 102 page 104 Check stains on the wiper blade. Clean the capping unit. page 106 page 112 Perform a NORMAL print head cleaning. Perform a NOZZLE PRINT pattern. # PH RECOV ERY >N O R M AL page 115...
Page 10 When you want to... Print on a thick media. Print on the margin of the media. page 165 page 179 Change the media advance adjustment Change the heater temperature value during printing. during printing. page 189 page 194 Remove media wrinkles during printing (During holidays and so on) Switch o the printer for a long period of time.
Page 11 Replacement and troubleshooting Replace consumables. Wiper sponge Wiper blade page 111 page 106 Wiper cleaning liquid Waste ink bottle page 104 page 102 A warning message is displayed. An error message is displayed. PERFORM CAP CLEANING page 224 page 215 The media is not straight.
Page 12: Table Of Contents
Table of Contents Introduction ............. Adjustment of the take-up reel unit ... Adjustment during operation ............Table of Contents ........... Removing the media ........Safety precautions ......... Procedure to print the amount of remaining media ..Symbol on the printer ........Procedure to remove the roll media (feed side) ....Cutting the media ..........
Page 13 Preparing the sheet mount cleaning ........Set the carriage speed ..............Performing sheet mount cleaning .......... Print speed ....................Maintenance when the printer is dirty ... Adjust the heaters temperatures .... Procedure to set the heaters temperatures ...... J Printer cleaning ........... Display the heater control menu ..........
Page 14: Safety Precautions
Safety precautions The following symbols are used in the guide to ensure the printer’s proper operation and to prevent the printer from being damaged. Follow the instructions marked with these symbols: Failure to follow the guidelines marked with this WARNING symbol could result in serious personal injury or death.
Page 15 WARNING Be sure to read warnings below before use. Use the power supply voltage specified on the nameplate. Turn off the printer, unplug the power cord from the Avoid overloading the electrical outlet used for the printer power outlet, and contact your service representative in with multiple devices.
Page 16 4. Unpack the OKI Data ink cartridges only to install them. Do not store OKI Data ink cartridges in direct sunlight. Store the OKI Data ink cartridges in a cool, dry place. This prevents deterioration of the ink during storage.
Page 17 Media Supported media The Printer supports solvent inkjet media of the types below. Note that print conditions may change depending on environmental conditions and the media production batch. So you are recommended to test the print with the media beforehand. For details, contact your service representative.
Page 18 Other precautions Media loses its color and quality with age. Check the media condition and select the media in the best condition. Cut the media carefully, as paper dust may make irregular surfaces. When adhesive-backed media is applied, some adhesive agent may be left on the platen, which may cause a media jam.
Page 19: Manual Legend (Notational Rules)
Manual legend (Notational rules) The notational rules used for explanation in this guide are as follows: Marks WARNING ‹ Boxes marked with a WARNING describe points of caution to avoid serious personal injury. CAUTION ‹ Boxes marked with a CAUTION describe points of caution to avoid injury to yourself or damage to the printer. TIP: š...
Page 20: Components Delivered With The Printer
Components delivered with the  printer Various components, including optional parts, are delivered with the printer. They must be attached to the printer during its installation. Check that all the components below are delivered. If any item is missing or damaged, contact the dealer from whom you purchased the printer or a service representative.
Page 21: Operating Conditions
Installation and maintenance space Adequate space is required around the printer for replacement of consumables and parts, print processing, and ventilation during normal operation and maintenance. Secure the space shown in the figure below. IP-5630: 3630 *6630 IP-5530: 3380 *6380 1000 *1500...
Page 22: Environmental Conditions
Environmental conditions Operating temperature and humidity levels Use the printer within the temperature and humidity levels shown below. Temperature: 15°C to 30°C (60°F to 80°F) Humidity: 30% to 70% To obtain better print quality, use the printer within a temperature range of 20 to 25°C (68 to 77°F). To ensure a stable and good print quality, the printer slows down the print speed when the head temperature exceeds 40°C (104°F).
Page 23: Fftss Library, Employed By The Software Installed On The Printer
Strategic Basic Research Programs(CREST) of Japan Science and Technology Agency. The Software including the FFTSS is supported by OKI Data Corporation, and the FFTSS library’s developers and its related organizations do not undertake any responsibility and obligations on the Software.
Page 25: Before Printing
Before printing...
Page 26: Functions
Appearance / Main components Printer front (take-up side) Front cover Operation panel Must be closed during printing. Equipped with LEDs and LCD to display the printer status, and buttons to set functions. Maintenance area cover Capping unit cover Open to perform print head Opened when cleaning the maintenance.
Page 27: Printer Rear (Supply Side)
and their functions Printer rear (supply side) Position to install optional exhaust attachment Pressure roller up/down lever A lever used to fixe or release the media. Moves together with the pressure roller lever at the printer front side. Media holder To be installed at both ends of the roll media.
Page 28: Printer Interior
Printer interior Carriage Sensors for automatic print Wiping unit adjustment Houses the print heads inside, and Removes foreign substances on prints image while moving over the Optical sensors used for automatic the print head’s nozzle surface. media. print adjustment. Ionizer (option) Removes static electricity from the media and reduces print defects caused by ink mist.
Page 29: Operation Panel
Operation panel The buttons, LEDs and LCD are placed on the printer's operation panel as shown below. In addition, the operation panel is also equipped with a buzzer to draw attention in case an error occurs or an invalid button is pressed. The printer enters waiting mode if it is not used for a given length of time.
Page 30: Lcd Messages
LCD messages This LCD installed on the printer operation panel can display two rows of 20 characters. Examples of messages displayed on the LCD are shown below. Menu display The level of the menu is indicated by the number of > marks displayed at the left of the upper row on the LCD. Top menu: >...
Page 31: Printer Heater Unit
Printer heater unit The printer is equipped with three heaters for ink fusing and image quality stabilization. Carriage Print head After heater Media feed direction Dries ink to stabilize print quality. Paper guide (rear) Preheater Preheats the media. Print heater Media Make the ink penetrate into the media to fuse the ink.
Page 32: To Turn The Printer On And Off
To turn the printer on and off CAUTION ‹ Do not use any power cable other than the one supplied with the printer. Use the power switch on the operation panel to turn the printer on and off. Supply side Printer power inlet Power-on procedure Plug one end of the supplied power cable...
Page 33 Press the power switch on the operation panel. The printer executes a self-diagnostic test and displays the message to the left on the operation panel. LOA D MEDIA If an error message appears... š To recover the error, refer to When an error message is displayed.
Page 34: Power-Off Procedure
Power-off procedure To turn off the power of the printer, keep the SHUTTING DOWN... power switch on the operation panel pressed PLEASE WAIT for 2 seconds. The message shown above is displayed on the LCD to indicate that the shutdown process is being executed. The power turns off after the shutdown procedure is finished.
Page 35: To Connect The Usb Cable
To connect the USB cable Connect the printer’s USB 2.0 cable to the USB connector USB connector at the center of the printer rear. Important! š Use the supplied USB 2.0 cable. š For the USB connection and related systems, use hubs and cables supporting USB 2.0.
Page 36: Online And Offline
Online and offline The printer operates in both online and offline states. When the printer is in online: - The printer prints the data sent from the computer’s Raster Image Process (RIP) software. When the printer is in offline: - The menu is operated with the operation panel buttons. The Online button switches between online and offline states.
Page 37: Cp_Manager
CP_Manager The Printer supports the CP_Manager software which provides a general view of the printer status. The following operations can be performed with CP_Manager™. Panel operations - Display the printer status - Create media preset, input adjustment values - Execute nozzle print, adjustment patterns print - Maintenance time notice, maintenance operation Additional functions - Display operation guidance...
Page 38: Supported Media
Supported media Vinyl Vinyl is media with PVC-material surface. As generally vinyl is adhesive-backed, by removing the release paper on the back you can stick the media easily. Depending on its gloss grade, the vinyl is classified into three categories: glossy vinyl (with high gloss), matte vinyl (with no gloss), and semi-glossy vinyl (with medium gloss).
Page 39: Loading The Media
Loading the media...
Page 40: Loading The Media On The Printer
Loading the media on the printer Procedure to load roll media Open the front cover and slide the media edge guards to each end of the platen. Then, close the front cover. Notes ‹ Move the media edge guards to both ends so they cannot enter under the media.
Page 41 Set the roll media to the media holder fixed on the left side. Notes ‹ When inserting the roll media in the media holder, be careful not to cause the media to shift on the roll or damage the end surface of roll media. ‹...
Page 42 Raise the pressure roller up / down lever. Note ‹ There are three selectable positions (up, middle and down) on the pressure roller up / down lever. To raise (release) the pressure roller here, raise the pressure roller up / down lever to the top position. Note ‹...
Page 43 Move the media holders so that the both edges of the media are equally distributed on the pressure roller. Load the media so that the media is evenly applied to the pressure roller. š Noting the relationship between the label gradation (indication line) and the media width will let you easily adjust the position next time you will set the media.
Page 44 Lower the pressure roller up / down lever. After this, follow the instructions on LCD screen. Note ‹ To lower (press) the pressure roller, lower the pressure roller up/down lever to the lowest position (see the Note of Step 6 on page page 42).
Page 45 Set the amount of remaining media. ENTER REMAIN MEDIA Set the amount of remaining media and press the OK 01: XXX.X YYY.Ym button. To register the amount of remaining media The menu used to set the amount of remaining media is displayed only when ON is set for REMAIN MEDIA MONIT in the media preset menu.
Page 46 <Correct installation> Make sure that the media is stretched tight as shown in the gure below. <In case of roll media with print side outside> <In case of roll media with print side inside> Rear paper guide Roll media Rear paper guide Roll media Feeding pipes Feeding pipes...
Page 47: Procedure To Monitor Remaining Media
Example 2 <In case of roll media with print side outside> <In case of roll media with print side inside> Slack within Slack within 15 cm 15 cm Procedure to monitor remaining media Press the MENU button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select EDIT MEDIA MENU PRESETS.
Page 48: Procedure To Load Transparent Media And Media With A Black Reverse Side
Press the Down button to select REMAIN >>MISC SETTING MEDIA MONIT. REMAINING MEDIA Press the OK button. >>MISC SETTINGS REMAIN MEDIA MONIT Press the Down button once. >>>REMAIN MEDIA MONIT Press the OK button. >>>REMAIN MEDIA MONIT >>>REMAIN MEDIA MONIT š...
Page 49 Press the OK button. MENU EDIT MEDIA PRESETS Press the Down button to select MISC >EDIT MEDIA PRESETS SETTINGS. SELECT PRESET NO. Press the OK button. >EDIT MEDIA PRESETS MISC SETTINGS Press the Down button to select DETECT >>MISC SETTINGS MEDIA.
Page 50 Press the Up button to select DETECT MEDIA >>MISC SETTINGS WIDTH. DETECT MEDIA Press the OK button. >>MISC SETTINGS DETECT MEDIA WIDTH Press the Down button once. >>>DETECT MEDIA WIDTH AUTO Press the OK button. >>>DETECT MEDIA WIDTH MANUAL Press the CANCEL button to exit the DETECT >>>DETECT MEDIA WIDTH MEDIA WIDTH menu.
Page 51 Open the front cover and place both edge EDGE GUARDS POSITION guards on the media edges. Place the media edges in the notches on the edge guards. Then close the front cover. Check that the edge guards do not go under the media, or that the media advance smoothly in case of particularly thick media.
Page 52 Press the OK button to set the media right SET MEDIA RIGHT EDGE edge position. Press the Left or Right button to move the MOVE CARR. TO MEDIA carriage to the left edge of the media. L EDGE WITH R/L KEY Align the s mark at the bottom left on the front of the carriage cover with the media left edge.
Page 53: Replacing The Media After A Media Jam
Replacing the media when the end of the roll is reached When there is no more media on the roll, the printer detects it automatically and displays a message. However, note that with some media types, the printer may not be able to automatically detect the end of the roll. If printing continues when there is no more media, the printer may get dirty or malfunction.
Page 54: Setting The Media On The Take-Up Reel Unit
Setting the media on the take-up reel unit Length limit of the paper tube for winding Use a paper tube of more than 750 mm (30 inches) in length for winding. (Example: Use a paper tube of 36 inches (914.4 mm) when rewinding a media of 24 inches (609.6 mm) in width. Use a paper tube of 750 mm or more for media of 750 mm or less in width.
Page 55 Move the tension roller in the top position. Tension roller <Tension roller fixed position> Tension roller Left side flange Plate (left) <Tension roller top position> Insert the paper tube in the right side flange (fixed side). Note ‹ It is normally not necessary to move the position of the right side flange, it is used in the fixed position.
Page 56 After setting the media, feed the media until its leading edge reaches the paper tube. Paper tube After the media has reached the paper tube, loosen the fixing knob of the right flange and move the flange to align the end surface of the media with the end surface of the paper tube.
Page 57 When the media has reached the paper tube, attach it to the paper tube using tape while keeping it stretched. Notes ‹ Attach tape to three positions, to the center and to both ends. ‹ Pay attention when attaching the media as the media may skew if it is not straight to the tube.
Page 58: Tension Take-Up / Loose Take-Up Setting
Tension take-up / Loose take-up setting With the take-up reel, either tension or the loose configuration can be selected. In normal use vinyl chloride with adhesive), the loose method is preferred. With tarpaulin and other media that does not slide well, use the tension configuration is take-up shifts occur. Loose take-up configuration Tension take-up configuration Tension take-up configuration / Loose take-up configuration setting procedure...
Page 59 Press the OK button. >EDIT MEDIA PRESETS MISC SETTINGS Press the Down button to select TUR MODE. >>MISC SETTINGS REMAINING MEDIA Press the OK button. >>MISC SETTINGS TUR MODE Select LOOSE or TENSION using the Up and >>>TUR MODE Down buttons, and then press the OK button. *LOOSE Press the CANCEL button to exit the TUR >>>TUR MODE...
Page 60: Take-Up Switch Setting
Take-up switch setting For the take-up direction, the outer take-up (print side out) or inner take-up (print side in) can be selected. When take-up is not used, set the take-up switch to OFF. Set the switch to the proper mode based of the figure below. Winding Take-up switch Outer...
Page 61 Slit (hole) š Install the removed attachment into the left and right plates to keep them for later use.(See the figure at the right hand side.) š Insert the 3 inch adapter in the slits (holes) of the left and right plates and turn clockwise ( in the arrow direction).
Page 62: Adjustment Of The Take-Up Reel Unit
Adjustment of the take-up reel unit As the state of roll media during operation always changes depending on the state of roll media finishing (winding shift) and the environment during printing (such as temperature and humidity), wind the roll media while adjusting. Adjustment during operation If the adjustment is left in the initial adjustment state, depending on this state of media, winding problems such as winding shifts may occur.
Page 63: Removing The Media
Removing the media Procedure to print the amount of remaining media The amount of remaining media can be printed on the media before removing the media. š Printing the amount of remaining media before removing it allows you to refer to it to enter the exact amount of remaining media the next time you install the same media.
Page 64: Procedure To Remove The Roll Media (Feed Side)
Procedure to remove the roll media (feed side) Raise the pressure roller up / down lever. Pressure roller up / down lever Rewind the flange to roll back the media. Loosen the screw of the media holder to the right, and while moving this media holder slightly to the right, remove the roll media from the media holder.
Page 65: Cutting The Media
Cutting the media This section describes the cutting procedure using the optional cutter unit (64) (cutter unit (54) for the IP-5530) Clip both ends of the media with the media clip. Move the media cutter blade and cut the media. š...
Page 66: Procedure To Feed The Media Up To The Cut Position After Printing
Procedure to feed the media up to the cut position after printing Follow the procedure below to cut the media at the end of the print out after printing. Press the Down button. PRINTER READY 01: PAPER/1626mm After the operation panel display has FEEDING MEDIA...
Page 67: Procedure To Backfeed The Media To The Print Position After Cutting
Procedure to backfeed the media to the print position after cutting Press the Up button. PRINTER READY 01: PAPER/1626mm After the operation panel display has BACKFEEDING MEDIA... changed to the screen shown on the left, STOP AT PRINT POS > keep the Up button pressed and press Right button.
Page 68: Unwind The Media From The Tur Unit
Unwind the media from the TUR unit Procedure to unwind the media from the TUR unit Follow the procedure below to unwind the media wound on the TUR unit. Press the MENU button. PRINTER READY 01: PAPER/1626mm Press the Down button to select UNWIND MENU MEDIA.
Page 69 About the unwinding direction š The unwinding direction depends on the take-up direction switch setting. You must set the switch to a different position if the media has been taken up in the inner or the outer take-up direction. Refer to the figure below when setting the switch. About the duration of the unwinding operation š...
Page 70 Loading the media...
Page 71: Adjustment
Adjustment...
Page 72: Before Making Adjustment
Before making adjustment Make adjustments to maximize the print quality. Notes ‹ Before starting the adjustment, turn on the force heating function on the printer for 30 minutes or more. ‹ Correct adjustment is not possible if the printer is not sufficiently warmed. ‹...
Page 73: Cautions Regarding Automatic Print Adjustment
Cautions regarding automatic print adjustment Notes ‹ The printer cannot set a correct media advance adjustment value through automatic print adjustment in the following cases. In such cases, improve the conditions or perform manual print adjustment. The automatic print adjustment determines mechanically the media advance adjustment value, so absolute precision of the setting cannot be guaranteed.
Page 74 Meaning The adjustment values cannot be determined correctly. MANUALLY ADJUST ADV VAL/PRINT POS Items to be checked Corrective measures Check that the media is not Reinstall the media or feed the media until you reach wrinkled. a section without wrinkles. Check that no nozzles are Perform a print head cleaning.
Page 75: Adjustment Methods
Adjustment methods Adjusting media feeding: Media advance adjustment The media feeding operation can be adjusted depending on media characteristics, such as thickness, rigidness, and smoothness of the surface. To maintain a high print quality, perform media advance adjustment and set the most suitable media advance adjustment value.
Page 76 Press the OK button. ADJUST MEDIA ADVANCE Press the Up and Down buttons to select >MEDIA ADVANCE MEDIA ADVANCE AUTO. MEDIA ADVANCE AUTO Press the OK button. >MEDIA ADVANCE MEDIA ADVANCE AUTO Press the OK button to execute media >MEDIA ADVANCE advance adjustment.
Page 77 Manual print adjustment Through manual adjustment, you can choose between 1 pattern or 3 patterns to be printed. With 1 pattern, the printer prints the media advance adjustment pattern with the set adjustment value. With 3 patterns, the printer prints three media advance adjustment patterns, one with the set adjustment value, one with the set adjustment value +0.2%, and one with the set adjustment value -0.2%.
Page 78 Press the OK button. >MEDIA ADVANCE MEDIA ADV MANUAL Press the Up and Down buttons to select >>MEDIA ADV MANUAL MEDIA ADV VALUE. MEDIA ADV VALUE Press the OK button. >>MEDIA ADV MANUAL MEDIA ADV VALUE Press the Right and Left buttons to select the >>>MEDIA ADV VALUE digit, and press the Up and Down buttons to *XXX.XX...
Page 79 Press the OK to print the media advance >>>1 PATTERN adjustment pattern. PRINT? The print starts. >>>1 PATTERN EXECUTING... Check the printed pattern visually. When adjustment value is correct, the adjustment procedure is complete. If the adjustment value is not suitable, perform the adjustment procedure again from step 9 through 17. Check the media advance adjustment pattern When the media advance adjustment value is too low.
Page 80: Correcting Ink Output Position: Bidirectional Adjustment
Correcting ink output position: Bidirectional adjustment During bidirectional printing, a slight difference may appear in the ink output position between the first scanning direction and the second scanning direction. To maintain a high print quality, perform bidirectional adjustment and set the most suitable bidirectional adjustment value.
Page 81 Press the Up and Down buttons to select >BIDIR POSITION BIDIR AUTO. BIDIR AUTO Press the OK button. >BIDIR POSITION BIDIR AUTO Press the Up and Down buttons to select >>BIDIR AUTO CARRIAGE SPD NORM or CARRIAGE SPD CARRIAGE SPD NORM SLOW.
Page 82 Manual print adjustment <Workflow> STEP1 STEP2 STEP3 Check visually the bidirectional Completed Print the bidirectional Enter the bidirectional adjustment pattern and select a adjustment pattern. adjustment value. bidirectional adjustment value. <Procedure> Load the media. Load the media in the same conditions as normal printing. Press the ADJUST button.
Page 83 Press the Up and Down buttons to PRINT >>>CARRIAGE SPD NORM PATTERN. PRINT PATTERN Press the OK button. >>>CARRIAGE SPD NORM PRINT PATTERN Press the OK button to print the bidirectional >>>CARRIAGE SPD NORM adjustment pattern. PRINT? The print starts. >>>CARRIAGE SPD NORM EXECUTING...
Page 84 Press the OK button. >>>CARRIAGE SPD NORM *M_L:±XX Print head color Adjustment value right or left ±XX : Current adjustment value Press the Right and Left buttons to select the >>>>BIDIR ADJ VALUE digit, and press the Up and Down buttons to *M_L:±XX ±YY select a value for bidirectional adjustment.
Page 85: Correcting Ink Output Position: Detailed Bidirectional Adjustment
Correcting ink output position: Detailed bidirectional adjustment If the ink output position is still misaligned between the first scanning direction and the second scanning direction after performing the adjustment described from page 78 to page 82, you can perform more detailed adjustment. <Workflow>...
Page 86 Press the Up and Down buttons to select >>DETAILED 1 PRINT MODE. PRINT MODE Press the OK button. >>DETAILED 1 PRINT MODE Press the Up and Down buttons to select the >>>PRINT MODE print mode you want to adjust. UNDEFINED 3:HIGH QUALITY is selected in the example on the left.
Page 87 Press the CANCEL button. >>>CARRIAGE SPEED SLOW The following describes the procedure with automatic adjustment. Press the Up and Down buttons to select >>DETAILED 1 AUTO BIDIR ADJUST. CARRIAGE SPEED Press the OK button. >>DETAILED 1 AUTO BIDIR ADJUST Press the OK button to print the bidirectional >>DETAILED 1 adjustment pattern.
Page 88 Press the OK button to print the bidirectional >>>BIDIR MANUAL adjustment pattern. PRINT? The print starts. >>>BIDIR MANUAL EXECUTING... Check visually the bidirectional adjustment pattern and select a bidirectional print value. Select a value for both the right and left of each print head. page 83 for how to check a bidirectional adjustment pattern.
Page 89: Maintenance
Maintenance...
Page 90: Daily Maintenance
Daily maintenance Replacement period of consumable. Item Quantity Replacement period(Warning message appear) IP6-251 Wiper cleaning liquid set A (200ml) 3 bottles 1 bottel per 1 month Perform daily maintenance to maintain the printer in good condition and maximize the print quality. IP5-282 Wiper sponge 1 piece...
Page 91: Routine Maintenance
Routine maintenance A Media installation Check that the media is not wrinkled. CHECK MEDIA If it is wrinkled, either set the media again or feed it up to an FOR WRINKLES area without wrinkles. * Printing on wrinkled media may damage the nozzle surfaces.
Page 92: B Nozzle Print
B Nozzle print Print the NOZZLE PRINT pattern Nozzle print is used to check that no nozzle (opening to eject ink) on the print heads is clogged. Perform a nozzle print following the timing below. - Every day before the first print. - When the carriage has been separated from the capping unit for a long time, for example after cleaning the capping unit.
Page 93: Configure Nozzle Map
Configure nozzle map When lines are missing on the nozzle print pattern or the ink is not ejected straight, that means that a nozzle is clogged. Nozzle map can be configured to set a nozzle that will be used instead of the clogged nozzle. With this function, good print quality can be maintained without reducing the print speed.
Page 94: Cautions Regarding Automatic Configuration
Cautions regarding automatic configuration Notes ‹ Automatic configuration sets nozzle map mechanically, so absolute precision of the setting cannot be guaranteed. ‹ The printer cannot configure correctly nozzle map in the following cases. In such cases, improve the conditions or perform manual configuration.
Page 95 Press the OK button. >> SET NOZZLE MAP Lc #1:***/VAR Press the Up, Down, Left, Right buttons to >>>Lc:#1 set the nozzle map or nozzle number, and ***/VAR 165 /VAR then press the OK button. The setting is complete. >> > Lc:#1 165/VAR 165/VAR To check the numbers of the nozzles...
Page 96 Press the Up or Down button to select AUTO NOZZLE PRINT NOZZ MAP. PRINT? Press the OK button. NOZZLE PRINT AUTO NOZZ MAP Press the Right or Left button to select the >AUTO NOZZ MAP cursor, and press the Up or Down button to PRINT HEAD:123456 select a print head number.
Page 97 Error message page 100 for details. See When an error occurs with automatic configuration on Completed successfully is printed when the configuration ends normally. ************************* Nozzle number Color/Head number Completely clogged nozzle Partially clogged nozzle Nozzle that does not eject ink straight These nozzle numbers are detected as defective ************************* Numbers of the nozzle for which overwrite protection has been set.
Page 98 Completely clogged nozzle Will be substituted. Normal nozzle Will not be substituted. Partially clogged nozzle Go to STEP 2 Will be substituted or not depending on its condition. Go to STEP 2 Nozzle that does not eject ink straight Go to STEP 2 Will not be substituted.
Page 99 Press the OK button. ADJUST SET NOZZLE MAP Press the Up and Down buttons to select the >SET NOZZLE MAP color to be set and press the OK button. This shows an example of setting nozzle 165 of print head Lc in nozzle map 1 with the overwrite protection set.
Page 100: When An Error Occurs With Automatic Configuration
When an error occurs with automatic configuration If one of the following errors occurs when executing automatic configuration, try manual configuration or perform the checks and the actions explained below. INSTALL WIDER MEDIA * Automatic configuration is not performed. Nozzle map settings from before the execution are maintained. Meaning Media of less than 762 mm (30 inches) is used.
Page 101 (Panel display) AUTO NOZZ MAP ERROR Lc Lm C Y K M The lower line shows the color with which the automatic nozzle map error occurs. The error message is also printed on the result of automatic nozzle map. (Print result of automatic nozzle map error) XXX: ERROR 1 MANUALLY CONFIGURE XXX: ERROR 2 MANUALLY CONFIGURE * XXX indicates the head color and number (e.g.
Page 102: C Waste Ink Bottle Check And Replacement
C Waste ink bottle check and replacement Remove the bottle from the waste ink spout Waste ink spout (tube) by slightly tilting the full waste ink bottle. Put the cap on the bottle and remove the ink spout bottle. Wipe off any ink stains around the waste ink bottle.
Page 103 Install a new (empty) waste ink bottle. The following message is displayed to reset #BOTTLE EMPTY? (clear) the waste ink counter. #BOTTLE EMPTY? *YES Note ‹ The printer automatically calculates waste ink with a counter and displays the message prompting replacement of the waste ink bottle when the waste ink bottle is full.
Page 104: D Wiper Cleaning Liquid Check And Supply
D Wiper cleaning liquid check and supply Supply wiper cleaning liquid with the procedure below in the following cases. - When a printer message prompts you to do so. - When you notice that the liquid level is low during a daily inspection. Generally, wiper cleaning liquid should be supplied approximately once per month.
Page 105 Replace the cap of the new wiper cleaning liquid bottle with the printer dedicated cap. Printer set cap Set the wiper cleaning liquid bottle in the printer and push in the stopper of the printer cap by pressing the top of it. Close the capping unit cover and the front AFTER REPLACING WCL cover.
Page 106: E Wiper Blade Cleanliness Check And Replacement
E Wiper blade cleanliness check and replacement Wiper blades check Check that the wiper blades are not damaged or dirty during the daily inspection. If one of the wiper blades is as shown below, replace it following the F Wiper blade cleanliness check and page 106.
Page 107 Open the front cover, and then the capping OPEN THE COVERS AND unit cover. CHECK WIPER BLADE If a wiper blade is dirty or damaged, perform WIPER BLADE CHECK at the end of the cap cleaning operation to replace the wiper blade.
Page 108: Wiper Blades Replacement
Wiper blades replacement Replace the wiper blade in the following cases. - When a printer message prompts you to do so. - When you notice that the blade is not clean or damaged during a daily inspection. Follow the procedure below to replace the wiper blade. Wiper blade replacement is performed in two steps: first replace the sponge blade, and then replace the two rubber blades.
Page 109 Open the front cover, and then the capping OPEN THE COVERS AND unit cover. REPLACE SPONGE BLADE Pinch the lower edge of the wiper blade with a pair of tweezers and pull out the plastic protrusion. Lift upward to remove the wiper blade. Pinch the rubber portion of a new wiper blade with the pair of tweezers and insert the wiper blade straight from the top.
Page 110 Notes ‹ If the rubber blades are not installed correctly, the print head cleaning will not be effective. As a result not only the print quality will decrease, but this may also lead to a malfunction. Refer to the example below to install the blades correctly. <Correct installation>...
Page 111 CARRIAGE IS MOVING PLEASE WAIT Carriage stops moving. Press the Down button to select YES. REPLACED WIPER BLADE? Press the OK button. REPLACED WIPER BLADE? >WIPER MAINTENANCE REPLACE BLADE Maintenance...
Page 112: Weekly Maintenance
Weekly maintenance F Cap cleaning (capping unit cleaning, cleaning) Select START MAINTENANCE on the panel and follow the instructions to perform both capping unit cleaning and cleaning at the same time. You may also perform cleaning independently in this manner. Performing wiper blades check, capping unit cleaning and cleaning at the same time CAUTION To prevent the ink from drying inside the print head’s nozzles:...
Page 113 If you notice dirt or damage on the wiper blades, execute REPLACE BLADE to replace them after the start maintenance has finished. GOOD The procedure Continue the procedure is nished. from step 2. Soak the cleaning swab (thick) in the cap cleaning liquid.
Page 114 Close the capping unit cover and the front CLEAN CAPS, CHECK cover. WIPER & CLOSE COVERS The carriage returns automatically to the home position. Press the OK button. CAP CLEANING COMPLETES Press the OK button. START PH RECOVERY? Press the CANCEL button to skip the cleaning. OK/CANCEL Press the OK button.
Page 115: Performing Cleaning Independently
Missing dots are still found even after the cap cleaning... š If you still see missing dots even after the cap cleaning above, check the caps visually and remove foreign matters and ink stains from them with a cleaning swab dampened with cap cleaning liquid. Performing cleaning independently Press the PH.RECOVERY button.
Page 116: G Pressure Roller Cleaning
G Pressure roller cleaning If ink or other substances are on the pressure roller, they may soil the media printed surface. In such cases, wipe off any substances using a soft cloth moistened with water or water-diluted neutral detergent. Notes ‹...
Page 117: Maintenance When A Message Is Displayed
Maintenance when a message is displayed H Wiper sponge replacement Replace the wiper sponge with the procedure below when a printer message prompts you to do so. Generally, the wiper sponge should be replaced approximately once every six month. Press the MAINTENANCE button. PRINTER READY 01: PAPER / 1626mm Press the DOWN button to select WIPER...
Page 118 Raise the wiper cleaning liquid bottle a little and pull out the bottle after making sure that all the liquid has flowed into the printer. Note ‹ Visually check that the waste ink bottle is not full before removing it. Lift the wiper sponge little by little while pulling it toward you.
Page 119 Close the capping unit cover and the front AFTER REPLACING WIPER over. SPONGE, CLOSE COVERS CARRIAGE IS MOVING PLEASE WAIT Carriage stops moving. Press the Down button to select YES. REPLACED SPONGE? Press the OK button. REPLACED SPONGE? >WIPER MAINTENANCE REPLACE SPONGE You may also be prompted by a printer message to replace one of the following consumables.
Page 120: I Sheet Mount Cleaning
I Sheet mount cleaning Perform sheet mount cleaning using a head cleaning sheet when the printer displays a message prompting you to do so. Generally, sheet mount cleaning should be performed approximately once per month. How long does it take? š...
Page 121: Performing Sheet Mount Cleaning
Performing sheet mount cleaning Perform the operation following the instructions below. Press the MAINTENANCE button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select PH MAINTENANCE MAINTENANCE. START MAINTENANCE Press the OK button. MAINTENANCE PH MAINTENANCE Press the Down button to select SHEET >PH MAINTENANCE MOUNT CLNG, and then press the OK button.
Page 122 INSTALL GRAY SHEET Place the gray sheet (cap cleaning sheet) to cover all six caps. Note ‹ Do not place the sheet onto the 4 rollers indicated by the arrows in the figure on the left. Otherwise this may decrease the cleaning effectiveness. Press the OK button.
Page 123 INSTALL PINK SHEET Place the pink sheet (head cleaning sheet) over the gray sheet and attach the hooks. Note ‹ Securely attach the four hooks. Otherwise the sheet may detach when entering into contact with the print heads, which decreases the effectiveness of the cleaning. The four hooks are placed at the four corners of the capping unit as shown in the figure to the left.
Page 124 Note CLEANING… REQUIRED TIME XX:XX ‹ The required time for sheet mount cleaning is approximately 1 hour. The sheet mount cleaning is complete. When sheet mount cleaning has finished, follow the panel messages to remove the cleaning sheet without delay. To interrupt the sheet mount cleaning Press the CANCEL button.
Page 125 Remove the gray sheet (cap cleaning sheet) REMOVE GRAY SHEET and press the OK button. Close the capping unit cover and the front CLOSE COVERS cover. The carriage moves to the home position. CARRIAGE IS MOVING PLEASE WAIT Carriage stops moving. Press the OK button.
Page 126: Maintenance When The Printer Is Dirty
Maintenance when the printer is dirty J Printer cleaning Clean the printer when the dirt becomes noticeable. Clean the printer approximately once per week. Pressure roller Front cover Media edge guards Platen Paper guide Head guard cleaning Press the MAINTENANCE button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select PH...
Page 127 Press the OK button. >>SET PH FOR CHECK The carriage moves to the maintenance area. CARRIAGE IS MOVING PLEASE WAIT The printer issues a warning beep. Carriage stops moving. š When the carriage moves, the printer issues a warning beep. To disable the warning beep, see the page 187.
Page 128: Media Edge Guard Cleaning
Media edge guard cleaning If a media is installed, remove it. Open the front cover. Soak a cleaning swab in the cap cleaning liquid. š To keep the cap cleaning liquid clean, do not soak the cleaning swab in the cap cleaning liquid bottle again after you have cleaned the edge guards with it.
Page 129: Front Cover Cleaning
Close the front cover. Front cover cleaning If the printer exterior is smeared, moisten a soft cloth with water or water-diluted neutral detergent, wring it, and clean the exterior. Notes ‹ Always turn the printer off before cleaning or doing other maintenance operation on the printer. ‹...
Page 130: Platen Cleaning
Platen cleaning Use the following procedure to clean the platen if - vinyl chloride adhesive gets on the platen - ink drops on the platen (the procedure to clean ink stains is explained) Open the front cover and soak up the ink on the platen with a piece of waste cloth.
Page 131: K Cleaning Around The Ionizers And The Sensors For Automatic Print Adjustment
K Cleaning around the ionizers and the sensors for automatic print adjustment Ink may adhere to the area around the ionizers and to the sensors for automatic print adjustment due to the effect of the ions generated by the ionizers. Periodic cleaning is required because this may cause a loss of precision of the automatic print adjustment function and ink particles to fall onto the printout.
Page 132 Open the front cover, and then the OPEN COVERS AND maintenance area cover. CHECK PRINT HEADS Clean the surface of the sensors for automatic print adjustment with a cleaning swab. Three holes are aligned on the bottom plate at the carriage left side. There is a sensor inside each hole.
Page 133 Note ‹ Do not touch the inside of the ionizer module (blue part) with the cleaning swab. The electrode that generates ions is made of a thin wire and can be broken easily if touched. If broken, the ionizers will not generate ions anymore.
Page 134: After The Operation Of The Day
After the operation of the day The printer has an internal clock which allows it to wash the print heads automatically, flushing some ink through the print heads, which keeps the print heads in good condition. To ensure the printer’s automatic maintenance operation, after the operations of the day keep the printer in the conditions below.
Page 135: Advanced Operations
Advanced operations...
Page 136: When Not Using The Printer For More Than 2 Weeks
When not using the printer for more than 2 weeks Always set the printer power to on to perform the fill cap operation. What is fill cap? š This function fills the caps with ink to soak the print heads (nozzle surface) in order to prevent clogged nozzles due to ink drying.
Page 137: Service Cleaning
Service cleaning Press the MAINTENANCE button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select PH MAINTENANCE MAINTENANCE. START MAINTENANCE Press the OK button. MAINTENANCE PH MAINTENANCE Press the Down button to select CLEAN FOR >PH MAINTENANCE STORAGE.
Page 138 Confirm that the waste ink bottle is empty START DRAINING and press the OK button. BOTTLE IS EMPTY? Draining starts. DRAINING REQUIRED TIME Y:YY Y: YY : Required time (min:sec, decrease every 10 seconds) SET STORAGE LIQUID CARTRIDGE IN SLOT Lc Insert the storage liquid cartridges in all the slots.
Page 139: Head Wash
Head wash š Set the cleaning liquid cartridges to the optional ink trays in advance to facilitate the procedure. Press the MAINTENANCE button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select PH MAINTENANCE MAINTENANCE. START MAINTENANCE Press the OK button.
Page 140 Confirm that the waste ink bottle is empty START DRAINING and press the OK button. BOTTLE IS EMPTY? Draining starts. DRAINING REQUIRED TIME Y:YY Y: YY : Required time (min:sec, decrease every 10 seconds) SET CLEANING LIQUID CARTRIDGE IN SLOT Lc Insert the cleaning liquid cartridges in all the slots.
Page 141 Confirm that the waste ink bottle is empty START DRAINING and press the OK button. BOTTLE IS EMPTY? Draining starts. DRAINING REQUIRED TIME Y:YY Y: YY : Required time (min:sec, decrease every 10 seconds) Repeat steps SET Lc INK CARTRIDGE Advanced operations...
Page 142: Priming The Ink System After Head Wash
Priming the ink system after head wash Press the MAINTENANCE button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select PH MAINTENANCE MAINTENANCE. START MAINTENANCE Press the OK button. MAINTENANCE PH MAINTENANCE Press the Down button to select PRIME INK >PH MAINTENANCE SYSTEM.
Page 143 Confirm that the waste ink bottle is empty START INK CHARGING and press the OK button. BOTTLE IS EMPTY? CHARGING INK REQUIRED TIME Y:YY Y:YY : Required time (min:sec, decrease every 10 seconds) Press the OK button. START CLEANING BOTTLE IS EMPTY? Normal cleaning starts.
Page 144: Check The Printer Information
Check the printer information š Press the MENU button during printing to check the printer information. Then press the ONLINE button to return to the normal panel display. Check the remaining ink level During printing Press the MENU button. PRINTING... STANDARD ND BI Press the Down button to select INK MENU...
Page 145 Not during printing Press the MENU button. PRINTER READY 01: PAPER / 1626mm Press the OK button. MENU INFORMATION Press the Down button to select INK >INFORMATION INFORMATION. WARNING INFO Press the OK button. >INFORMATION INK INFORMATION Press the OK button. >>INK INFORMATION REMAINING INK When the remaining ink (total ink - used ink) falls under 10%,...
Page 146: Export Printer Information
Export printer information Menu information can be exported in the PDF format to the USB drive. Insert a USB drive in the USB port. USB port The FAT32 format is recommended for the USB drive. Press the MAINTENANCE button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select EXPORT MAINTENANCE...
Page 147: Check Remaining Media Length
EXPORT COMPLETED is displayed when the export >EXPORT DATA TO USB finishes successfully. EXPORT COMPLETED Press the OK button. If the export failed, an error message is displayed. >EXPORT DATA TO USB EXPORT FAILED :XX XX is an error code. Insufficient space on the USB drive The USB drive is write-protected.
Page 148 Not during printing Press the MENU button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select MENU INFORMATION, and then press the OK WARNING INFO button. Press the Down button to select REMAINING >INFORMATION MEDIA. INK INFORMATION Press the OK button.
Page 149: Check The Usb Connection Status
Check the USB connection status During printing The USB connection status cannot be checked during printing. Check the connection when the printer is not printing. Not during printing Press the MENU button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select MENU INFORMATION, and then press the OK INFORMATION...
Page 150: Check The Firmware Version On The Printer
Check the firmware version on the printer During printing The firmware version cannot be checked during printing. Check the version when the printer is not printing. Not during printing Press the MENU button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select MENU INFORMATION, and then press the OK INFORMATION...
Page 151: Check The Print Length
Check the print length During printing Press the MENU button. PRINTING... STANDARD ND BI Press the Down button to select TOTAL MENU PRINT LENGTH. WARNING INFO Press the OK button. MENU TOTAL PRINT LENGTH >TOTAL PRINT LENGTH YYYYYm Displayed in the unit set in the length unit menu. Not during printing Press the MENU button.
Page 152 Press the OK button. >INFORMATION TOTAL PRINT LENGTH >>TOTAL PRINT LENGTH YYYYYm Displayed in the unit set in the length unit menu. Advanced operations...
Page 153: Handle The Media
Handle the media Create a new media preset You can register 20 media presets in the printer (No.01 to 20). The parameters in the preset menu are in the order shown below. You can select the number of the preset to edit with SELECT PRESET NO.
Page 154 Press the OK button. MENU EDIT MEDIA PRESETS Press the OK button. >EDIT MEDIA PRESETS SELECT PRESET NO. Press the Down button. >>SELECT PRESET NO. *01PAPER Press the OK button. >>SELECT PRESET NO. The paper type of the preset changes from 01PAPER to *02Glossy 02Glossy.
Page 155 Press the ONLINE button. >EDIT MEDIA PRESETS MEDIA ADV VALUE PRINTER READY 01: PAPER / 1626mm Preset media default values Up to 20 presets (No. 01 to 20) of media can be registered. Media presets can also be deleted or changed. However, preset No.
Page 156: Minimize The Right And Left Margins
Minimize the right and left margins Deactivate the media edge guards Press the MENU button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select EDIT MEDIA MENU PRESETS. INFORMATION Press the OK button. MENU EDIT MEDIA PRESETS Press the Down button to select MISC >EDIT MEDIA PRESETS SETTINGS.
Page 157 Press the CANCEL button to exit the MEDIA >>>MEDIA EDGE GUARDS EDGE GUARDS menu. Press the ONLINE button. >>MISC SETTINGS MEDIA EDGE GUARDS PRINTER READY 01: PAPER / 1626mm Activate the color stripe Press the MENU button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select EDIT MEDIA MENU PRESETS.
Page 158 Press the OK button. >>MISC SETTINGS COLOR STRIPE Press the Down button once. >>>COLOR STRIPE Press the OK button. >>>COLOR STRIPE Press the CANCEL button to exit the COLOR >>>COLOR STRIPE STRIPE menu. Press the ONLINE button. >>MISC SETTINGS COLOR STRIPE PRINTER READY 01: PAPER / 1626mm Advanced operations...
Page 159: Prevent The Media From Sticking And Wrinkling
Prevent the media from sticking and wrinkling Decrease the platen suction fan power The vacuum pressure applied to the media in the printing zone helps to hold the media down on the platen to keep the distance from media to print heads constant. When the media sticks to the platen, set the vacuum pressure to LOW.
Page 160 Press the OK button. >>>SUCTION FAN POWER Press the CANCEL button to exit the >>>SUCTION FAN POWER SUNCTION FAN POWER menu. Press the ONLINE button. >>MISC SETTINGS SUCTION FAN POWER PRINTER READY 01: PAPER / 1626mm Advanced operations...
Page 161 Change the media advance mode Some types of media may tend to adhere to the platen or the paper guide, making it difficult for the media to advance smoothly. In such cases, change the media advance mode. The operation required to advance the media smoothly depends on the level of adhesion. Change the advance mode in accordance with the media being used.
Page 162 TUR MODE LOOSE TENSION SUCTION FAN POWER HIGH (recommended) HIGH (recommended) FORWARD ONLY MEDIA ADVANCE BACK & FWD LOW FORWARD ONLY MODE BACK & FWD HIGH FWD LESS WRINKLES FWD LESS WRINKLES Target media Vinyl and coated paper Banner Inner take-up Cannot be used Can be used Outer take-up...
Page 163: Prevent The Media From Lifting Up
Press the OK button. >>MISC SETTINGS MEDIA ADVANCE MODE Press the Up and Down buttons to select an >>>MEDIA ADVANCE MODE advance mode. FORWARD ONLY Press the OK button. >>>MEDIA ADVANCE MODE BACK & FWD LOW Press the CANCEL button to exit the MEDIA >>>MEDIA ADVANCE MODE ADVANCE MODE menu.
Page 164 Press the OK button. MENU EDIT MEDIA PRESETS Press the Down button to select MISC >EDIT MEDIA PRESETS SETTINGS. SELECT PRESET NO. Press the OK button. >EDIT MEDIA PRESETS MISC SETTINGS Press the Down button to select SUCTION >>MISC SETTINGS FAN POWER.
Page 165: Print On A Thick Media
Print on a thick media Change the height of the print heads Be sure to adjust the height of the print heads when printing on thick media to prevent the print heads from contacting the media. The height of the print heads must be changed depending on the thickness of the media. Change the print head height depending on the media used with the head up/down mechanism.
Page 166 Press the Down button once. >>>PRINT HEAD HEIGHT NORMAL Press the OK button. >>>PRINT HEAD HEIGHT HIGH Press the CANCEL button. >>>PRINT HEAD HEIGHT The printer exits the setting screen for print head height. HIGH Press the ONLINE button. >>MISC SETTINGS PRINT HEAD HEIGHT PRINTER READY 01: PAPER / 1626mm...
Page 167 Press the OK button. >PH MAINTENANCE CHANGE PH HEIGHT Press the OK button. >>CHANGE PH HEIGHT CARRIAGE IS MOVING PLEASE WAIT Carriage stops moving. (When the media is installed) - The height of the print heads is set to NORMAL in the media preset menu.
Page 168 While raising the front of the carriage, change the position of the left head up/down mechanism. š We recommend wearing glove during this operation to keep your hands clean. Head up/down mechanism positions Normally the mechanism is set to the up position.
Page 169 Tighten the two securing screws. Note ‹ Securely tighten the head securing screws using a flathead screwdriver. If the head securing screws become loose, the print heads may incline to the right or left, which may affect the print quality. Close the maintenance area cover and the AFTER CHANGING PH front cover.
Page 170: Suspend Printing When Media Wrinkles Are Detected
Suspend printing when media wrinkles are detected To prevent the printouts to be soiled due to the print heads touching the media, this function can suspend printing when contact between the print heads and the media is detected. Select the mode according to the characteristics of the media used.
Page 171 Press the Down button to select EDIT MEDIA MENU PRESETS. INFORMATION Press the OK button. MENU EDIT MEDIA PRESETS Press the Down button to select MISC >EDIT MEDIA PRESETS SETTINGS. SELECT PRESET NO. Press the OK button. >EDIT MEDIA PRESETS MISC SETTINGS Press the Down button to select SAFE >>MISC SETTINGS...
Page 172: Prevent The Ink From Spreading Over The Printout (When An Option Is Installed)
Press the ONLINE button. >>MISC SETTINGS The printer exits the safe scanning setting screen. SAFE SCANNING PRINTER READY 01: PAPER / 1626mm Prevent the ink from spreading over the printout (when an option is installed) š Turning the ionizer on may solve the problem in the following situations. - Ink dribbles on the media when using a type of media that easily generates static electricity.
Page 173 Press the Down button to select IONIZER. >>MISC SETTINGS REMAINING MEDIA Press the OK button. >>MISC SETTINGS IONIZER Press the Up and Down buttons to select ON. >>>IONIZER Press the OK button. >>>IONIZER Press the CANCEL button to exit the IONIZER >>>IONIZER menu.
Page 174: Change The Automatic Cleaning Timing
Change the automatic cleaning timing To ensure the print heads’ good condition, the printer performs the automatic cleaning. The cleaning mode can be specified for each media preset. Select the cleaning mode depending on the media characteristics. BEFORE&AFTER Based on the previous printing operations, the printer performs the automatic cleaning when starting or when completing the print operation.
Page 175 Press the Down button to select AUTO PH >>MISC SETTINGS CLEANING. REMAINING MEDIA Press the OK button. >>MISC SETTINGS AUTO PH CLEANING Press the Up and Down buttons to select >>>AUTO PH CLEANING BEFORE&DURING PRNT. *OFF Press the OK button. >>>AUTO PH CLEANING BEFORE&DURING PRNT Press the CANCEL button to exit the AUTO PH...
Page 176: Copy A Media Preset
Copy a media preset The following procedure explains how to copy the parameters registered in media preset No. 2 to media preset No. Press the MENU button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select EDIT MEDIA MENU PRESETS.
Page 177: Change The Type Of The Preset Media Without Reloading The Media
Press the ONLINE button. >EDIT MEDIA PRESETS COPY MEDIA PRESET PRINTER READY 01: PAPER / 1626mm Change the type of the preset media without reloading the media The following procedure explains how to change from Paper media type in preset No. 1 to Glossy media type in preset No.
Page 178: Feed Or Rewind Media
Press the CANCEL button to exit the CHANGE >CHANGE PRESET PRESET menu. 02:Glossy Press the ONLINE button. >MENU CHANGE PRESET PRINTER READY 02:Glossy/1626mm Feed or rewind media Feeding and rewinding operations can be executed in the online state (idle mode). Press and hold the Up or Down button.
Page 179: Move The Print Start Position
Move the print start position Move the print start position (origin), to start printing on your preferred position. After printing, rewind the roll, and with this function you can print an image in the blank area. CAUTION ‹ Complete this operation as quickly as possible. Otherwise the print heads may dry, which may cause ink ejection failure. In such a case perform a cleaning.
Page 180: Exit Origin Setting Mode
SET ORIGIN *OK? Carriage stops moving. Press the OK button to set the origin. SET ORIGIN The carriage returns, and the printer enters online state and becomes ready to print. SETTING ORIGIN... PLEASE WAIT During origin setting mode, a symbol is displayed next to PRINTER READY the media width value.
Page 181: Adjust The Head Margin Before Printing
Adjust the head margin before printing Advance or rewind the media during the preheating time before printing to adjust the margin to the previous printout. Once printing (scan) has started, this function cannot be used until the job has finished. Press the ONLINE button during the PREHEATING...
Page 182: Fix The Print Position (Margin Size)
Fix the print position (margin size) To secure the print position (margin size) from the media edges, even if the media has skewed, change the SKEW CHECK setting from ON to ON, FIXED MARGIN. Press the MENU button. PRINTER READY 01: PAPER / 1626mm Press the Down button to select EDIT MEDIA MENU...
Page 183 Press the OK button. >>>SKEW CHECK ON, FIXED MARGIN Press the CANCEL button to exit the SKEW >>>SKEW CHECK CHECK menu. *ON, FIXED MARGIN Press the ONLINE button. >>MISC SETTINGS SKEW CHECK PRINTER READY 01: PAPER / 1626mm Advanced operations...
Page 184 Difference in the print position (margin size) between the SKEW CHECK ON and ON, FIXED MARGIN settings. Depending of the media used, even if it is installed straight, it may become skewed because it has shifted on the roll or when being fed into the printer. Usually the image is not printed outside the media width, but this may happen when the image width is almost the same as the media width (with SKEW CHECK set to ON).
Page 185: Remove Some Media Wrinkles During Printing
Remove some media wrinkles during printing If the media wrinkles during printing (online mode), put the printer in pause mode to be able to release the grip. CAUTION ‹ Some wrinkles can be removed by releasing the the pressure roller (lifting the lever) but this may also decrease the print quality as the media may slip.
Page 186: How To Use The Lifter
How to use the lifter Unless the media is under the entire pressure roller, wrinkles and skews may occur. In such case, pull toward you the lifter at the upper side of pressure roller to release the pressure force of pressure roller.
Page 187: To Change The Printer's Basic Settings
To change the printer’s basic settings Turn the warning beep off Normally, the printer emits a warning beep when an error occurs. However, the warning beep can be turned off for the three following cases. - When the print heads are not covered by the caps (during daily maintenance operations, print head height adjustment, or when a media jam occurs) - When a media take-up error occurs - When the ink runs out or ink cartridges are not installed...
Page 188 Press the Up and Down buttons to select the >>>WARNING SOUND type of the warning sound to change. PH UNCAPPED Press the OK button. >>>WARNING SOUND INK ERRORS Press the Down button to select OFF. >>>>INK ERRORS Press the OK button. >>>>INK ERRORS >>>>INK ERRORS Advanced operations...
Page 189: Controlling The Media Advance Adjustment Value
Controlling the media advance adjustment value Change the media advance adjustment value during printing Press the Up or Down button while PRINTING... PRINTING... is displayed. STANDARD ND BI Press the Up and Down buttons to modify Adjustment FINE ADJ VAL:099.80% value when the adjustment value.
Page 190: Print Conditions
Print conditions Twelve print modes are available on the printer, including different density levels for the same resolution. You can also select two speeds for the carriage in each of the 13 print modes. Select print conditions to achieve the productivity and quality that match the media and the application. Generally use the printer in Standard print mode with Standard carriage speed.
Page 191: Set The Carriage Speed
Notes ‹ The recommended modes are STANDARD to print in normal density and HIGH QUALITY / HIGH DENSITY to print in high density. Use the other modes according to your needs for productivity and quality. ‹ Printing in HIGH DENSITY uses large quantity of ink. Sometimes it may cause the ink to blur, ink drying problems, or take- up problems.
Page 192: Print Speed
The print speed depends on the print mode and the carriage speed. Print speeds are shown in the table below. The real print speed may be slower than the indicated values depending on factors such as the media width. Print speeds of the IP-5630 * Carriage speed...
Page 193 Print speeds of the IP-5530 * Carriage speed Print mode NORMAL SLOW FAST PRODUCTION 21.3 m 13.5 m2/h PRODUCTION 14.1 m 8.9 m PRODUCTION / HIGH DENSITY * STANDARD 10.2 m 6.2 m STANDARD / HIGH DENSITY * QUALITY 6.8 m 4.1 m QUALITY / HIGH DENSITY * HIGH QUALITY...
Page 194: Adjust The Heaters Temperatures
Adjust the heaters temperatures Each heater initial value is set in the media preset menu. These values are automatically set for the heaters temperatures. Therefore, normally the heater control menu is not required. The heater control menu is used to: - Complete the temperature fine adjustment during the print operation;...
Page 195: Display The Heater Control Menu
The heater temperature control system for printing The Printer receives the RIP data. (Temperature) Delay Standby time Print time Printheater set temperature Preheater set temperature Afterheater set temperature Standby set temperature Ambient temperature (Time) Set temperature maintained Standby temperature Temperature control stop maintained š...
Page 196: Exit The Heater Control Menu Display
Exit the heater control menu display Press the HEATER button while the heater control menu is displayed. When the heater control menu display ends automatically HEATER DISPLAY ENDED If no buttons are input for 30 seconds while the heater control menu is displayed, the message HEATER DISPLAY ENDED appears automatically for two seconds and then the heater control menu display ends.
Page 197 Press the OK button. MENU EDIT MEDIA PRESETS Press the Down button to select >EDIT MEDIA PRESETS AFTERHEATER T. SELECT PRESET NO. Press the OK button. >EDIT MEDIA PRESETS AFTERHEATER T Enter the temperature. >>AFTERHEATER T Press the Left and Right buttons to select a YY°C digit, and press the Up and Down buttons to set a value.
Page 198: Set The Print End Heating Time
Set the print end heating time Set the duration the heater maintains the set temperature after printing. Press the MENU button. PRINTER READY 02:Glossy/1626mm Press the Down button to select SETTING. MENU INFORMATION Press the OK button. MENU SETTING Press the Down button to select MEDIA >SETTING HEATER SET., and then press the OK button.
Page 199: Select The Standby Time
Select the standby time Select the time to maintain the standby set temperature of the heater (including the time for transition to the standby set temperature) after printing. Press the MENU button. PRINTER READY 02:Glossy/1626mm Press the Down button to select SETTING. MENU INFORMATION Press the OK button.
Page 200: Out Of Ink While Printing
Out of ink while printing When the printer runs out of ink during online printing, printing is suspended and the printer enters pause mode. When an ink cartridge is empty, the INK LED goes off. You are advised to follow the message instructions. INK LED goes off.
Page 201: Install An Ink Cartridge
Install an ink cartridge The installation locations (slots) of ink cartridges are defined for each color. Be sure to insert the cartridges to the appropriate slots. LCD message R E P L A C E Y C A R T R ID G E Ink color CAUTION ‹...
Page 202: Replace An Ink Cartridge
Replace an ink cartridge This section describes the reloadable cartridge replacement procedure. Consumables page 260 Consumables. For details about reloadable cartridge names and types, Color identification label (ink cartridge back) Color identification label Upper plate Tail section Lower plate Board protective sheet Spout Ink cartridge for cartridge holder Board...
Page 203 Pull the used ink cartridge, together with the cartridge holder, out of the printer. Remove the cartridge holder cover. While keeping the two cover securing claws open by moving them to the outside (arrows (1) direction), pull the cartridge holder cover toward the top (arrow (2) direction). Remove the cartridge holder cover in the arrow (3) direction.
Page 204 Remove the used ink cartridge tail section from the tail section fixing plate. Remove the used ink cartridge spout from the cartridge holder. Referring to the locations on the cartridge holder shown in the figure, slide the four protrusions of the ink cartridge lower plate in the arrow direction, and remove the ink cartridge from the cartridge holder.
Page 205: Ink Cartridge Installation Procedure
Ink cartridge installation procedure Make sure that the ink cartridge upper plate is face up, and insert the tail section in the Tail section fixing plate hole shown in white in the figure to the right. Upper plate Upper plate Tail section Lower plate Spout...
Page 206 Referring to the locations on the cartridge holder shown in the figure, insert the four protrusions of the ink cartridge lower plate and slide them under the plate guide following the arrow direction. Insert the ink cartridge spout in the cartridge holder.
Page 207 Insert the board in the cartridge holder cover. With the golden surface of the board facing up, insert it so that the board shape matches the shape of the cartridge holder cover. Note ‹ Do not take the board protective sheet off until you install the reloadable cartridge to the printer.
Page 208 Insert the tail section fixing plate hooks into the ink cartridge tail section holes to attach Note ‹ Do not apply an excessive force as the ink cartridge holes may be deformed. Hook the tail section fixing plate to the cartridge holder claws.
Page 209: Troubleshooting
Troubleshooting...
Page 210: Check The Problem
Check the problem Before deciding that there is a serious problem with the printer, check the following items. Power does not turn on. Items to be checked Corrective measures Power cable connection Check that the power cable is correctly plugged into the power outlet. Power supply to the outlet Supply power to the power outlet.
Page 211 Although the printer is in the print mode, printing does not start with PREHEATING displayed on the operation panel. Items to be checked Corrective measures Room temperature Raise the room temperature. (Recommended temperature: 20 to 25ºC) Effect of air flow If the air from an air conditioner or a fan is blowing against the paper guide, change the air flow direction, the orientation of the printer, or the location of the printer.
Page 212 Printing is slow. The carriage sometimes moves. Items to be checked Corrective measures USB connection speed When the data transmission speed is slow, the printer waits for the data with the print heads capped. Check the USB’s transmission speed. If the USB connection is full speed, the speed can be improved by changing the conditions of the connection to the computer as follows, so that the connection becomes high speed.
Page 213: How To Clear Media Jams
How to clear media jams The message to the left appears. MEDIA JAM ERROR LIFT THE LEVER X: Media jam type Meaning 1: Media jam 1 A jam on the carriage is preventing the printer from operating correctly. 2: Media jam 2 A media not supported is used.
Page 214 Close the front cover. The carriage moves to the home position. Load the media on the printer again. CARRIAGE IS MOVING page 40. See To load media on the Printer on PLEASE WAIT Note ‹ When the printer is jammed with media, the print heads may contact the media and cause print misses. In such cases, perform print head recovery.
Page 215: When An Error Message Is Displayed
When an error message is displayed When the ERROR LED lights up, check the message displayed on the operation panel. Error messages shown below are classified into two groups. Service call errors: Errors that the operator (customer) cannot recover, such as hardware/software failures. Contact your service representative.
Page 216 If the system error 2320 is displayed š Try the following procedure as it may recover the error. Required items 1. Dropper 2. Sheet mount cleaning liquid 3. Gloves 4. Cleaning swab Note ‹ The items 1, 2, and 3 above are included in the sheet mount cleaning kit A (IP5-283). ‹...
Page 217 Below the chain shown in the figure, insert the dropper tip in the area (a) and inject the sheet mount cleaning liquid. In the same manner, inject 1 ml of sheet mount cleaning liquid to the areas (b), (c), (d), and (e) shown in the figure.
Page 218 Insert the cleaning swab handle in the area (b) shown in the figure of the chain on the left and move it in the direction of the arrow until it reaches the area (d). Close the capping unit cover and then the front cover.
Page 219 Operator call errors The following errors can be recovered by the operator. <Ink errors> CC INK MISSING Meaning An ink cartridge is not installed. INSTALL INK CRTG Action You are advised to follow the message instructions. If this message appears when a ink cartridge is installed for the specified CC: Ink color color, the ink cartridge installation may not be correct.
Page 220 <Media jam errors> Meaning An obstruction is left in the carriage path and the printer cannot drive MEDIA JAM ERROR the carriage normally. LIFT THE LEVER Action Lift the pressure roller lever and open the front cover. If the media jam (0) error occurs repeatedly although there is no media jam or no obstruction in the carriage path, contact your service representative.
Page 221 <Print head error> Meaning The printer operation was suspended, as the print heads temperature PH COOLING PROCESS exceeded 40ºC. The print heads temperature is always monitored by PLEASE WAIT the printer to guarantee stable ink ejection. Action Secure an ambient temperature between 15 and 30ºC to prevent the print heads temperature increase.
Page 222 Meaning Media of less than 762 mm (30 inches) in width was installed when INSTALL WIDER MEDIA automatic nozzle map was performed. Action Use media of 762 mm (30 inches) or larger when performing automatic nozzle map. (See When an error occurs with automatic configuration on page 100.) Meaning Automatic nozzle map could not be performed.
Page 223: The Media Has Skewed
The media has skewed. When the media skew check setting is on, the printer checks for skewed media after printing a certain length of media. If the media has skewed more than a defined distance, the print pauses and a screen where you can select to continue or stop the print is displayed.
Page 224: Warning Messages
Warning messages After printing, occasionally you may see one of the following messages appear on the operation panel with the ERROR LED flashing. They are warning messages. In such cases, follow the instructions in the Action rows. Meaning The media has not been fed for a long time (about 250 min). Check the CHECK MEDIA media for wrinkles.
Page 225 Meaning CC ink is running out. CC INK IS Action RUNNING OUT Prepare a new ink cartridge. page 201. See Install and replace an ink cartridge on CC: Ink color Meaning Ink end has been detected regardless of ink still remaining in the INK END DETECTED cartridge.
Page 226: Clear Missing Dots (Nozzle Clogging)
Clear missing dots (nozzle clogging) If the missing dots still appear after the daily maintenance and after setting NOZZLE MAP, perform the operation below. Perform the strong cleaning when missing dots still appear after the Strong cleaning normal cleaning. Perform the NOZZLE PRINT To clear the nozzle clogging, fill the cap with ink and moisten the print Fill the cap with ink head nozzle surface with ink.
Page 227: Fill The Cap With Ink
Press the OK button. >STRONG Check visually that the waste ink bottle is not full. BOTTLE IS EMPTY? Cleaning starts. PH RECOVERING Print head cleaning takes several minutes. REQUIRED TIME 2:40 When the cleaning starts, the required time is displayed and the time is counted down every 10 seconds.
Page 228: Fill The Cap With Wiper Cleaning Liquid
Press the OK button. >>FILL CAP WITH INK BOTTLE IS EMPTY? EXECUTING... PLEASE WAIT Cap filling is complete. >PH MAINTENANCE Leave the printer for 1 to 2 hours. FILL CAP WITH INK After the printer has be left for 1 to 2 hours, perform the normal cleaning.
Page 229 Open the front cover, and then the capping OPEN COVERS unit cover. INSERT SHEET MOUNT CLNG LQD INTO CAPS Use the dropper to fill the cap of each color with sheet mount cleaning liquid. Close the capping unit cover and the front CLOSE COVERS cover.
Page 230 Press the OK button. START CLEANING Check visually that the waste ink bottle is not full. BOTTLE IS EMPTY? (The strong cleaning starts.) PH RECOVERING REQUIRED TIME XX:XX Fill the cap with wiper cleaning liquid is complete. >PH MAINTENANCE SET CAP FOR CLNG Troubleshooting...
Page 231: Media Wrinkles Have Been Detected
Media wrinkles have been detected Using the safe scanning system, the Printer detects the media wrinkles during printing. When media wrinkles have been detected, the Printer enters the pause mode and a message appears on the operation panel so that you can select to continue or stop the print.
Page 232 Open the front cover OPEN COVERS Lift the pressure roller up/down lever. LOWER THE LEVER When lifting the pressure roller up/down lever… š When you have lifted the pressure roller up/down lever, place your hand on the media to keep it in place during the operation.
Page 233: Solve Print Quality Issues
Solve print quality issues This section contains hints to enhance the print quality with the printer based on several symptoms. Take appropriate actions according to the symptoms. When several actions are described, they are arranged in order of effectiveness. Therefore, you are recommended to take the actions starting from the top and confirm the effect on the improvement.
Page 234: The Media Is Curled Or Wrinkled
The media is curled or wrinkled. Cause Solution Outside the operating temperature/ (1) Use the printer within the operating temperature/humidity range. humidity range * Note that some media may wrinkles even within the operating temperature and humidity range. (2) Use proven media. The media storage conditions are not the The difference between the media storage conditions and the printer operating same as the printer operating conditions.
Page 235: White Stripes Appear On The Print
White stripes appear on the print. Basic image [Symptom A] [Symptom B] [Symptom C] [Cause] [Cause] [Cause] The media advance adjustment The print head nozzles are The ink does not match well with value is not proper. clogged. the media. [Check] [Check] White stripes appear in all...
Page 236 page [Symptom B] (1) Print a nozzle print pattern, and set nozzle map for the inclined nozzles. ( Print head nozzles inclination page 157) (2) Printing with a color stripe bar is effective to prevent missing dots. ( [Symptom C] (1) Decrease the temperature of all three heaters by 5°C.
Page 237: Black Stripes Appear On The Print
Black stripes appear on the print. Basic image [Symptom A] [Symptom B] [Symptom C] [Symptom D] * Black stripes appear over the print. * Black stripes appear partly on the [Cause] [Cause] print. [Cause] The print head periphery At bidirectional printing, [Cause] The media advance is smeared.
Page 238 [Symptom D] (1) Increase the temperature of all three heaters by 5°C. * The ink dries too slowly. * Before starting the print, ensure that the heater temperatures have been decreased to the target temperature. (Mottling or bleeding occurs.) (2) Change to a more suitable print mode, or set the carriage speed to SLOW. (3) Print in unidirectional mode.
Page 239: The Printout Is Not Clean
The printout is not clean. Basic image [Symptom A] [Symptom B] [Symptom C] [Symptom D] [Cause] [Cause] [Cause] [Cause] The ink is improperly The ink is drooling. The print head is The pressure roller is sprayed from the print scratched by media. dirty.
Page 240 page 116 to clean the pressure roller. [Symptom D] (1) Follow the procedure on The pressure roller is dirty. *1 Adjust the media advance adjustment value again. *2 Note that the print speed differs depending on the mode selected. *3 Be sure to adjust the bidirectional adjustment value again after changing the carriage speed. *4 Adjust the bidirectional adjustment value again.
Page 241: Contours Of Objects Are Blurred
Contours of objects are blurred. Basic image [Symptom A] [Symptom B] [Symptom C] [Symptom D] [Cause] [Cause] [Cause] [Cause] The ink dries too slowly. The print head position The media advance The static electricity The ink is ejected is misaligned. adjustment value is accumulated on the excessively.
Page 242 [Symptom D] (1) Set the ionizer (option) to ON. * Print defect caused by media static electricity (2) Change to a more suitable print mode, or set the carriage speed to SLOW. / Ink sprayed over white portions of the media.
Page 243: Vertical Banding Appears At The Printout Edges
Vertical banding appears at the printout edges. Basic image [Symptom A] [Symptom B] [Cause] [Cause] On the platen, the contacting point of the On the platen, the contacting point of the media left edge and the media edge guard media right edge and the media edge guard is near the platen’s vacuum hole.
Page 244: Different Bands Appear On The Printout Right And Left Sides
Different bands appear on the printout right and left sides. Basic image [Cause] The media is skewed. Cause Solution A skewed media is fed. (1) Check that the media condition is good. If the media roll is damaged or wound in the shape of a cone, replace the roll with a good one.
Page 245: Vertical Bands Appear On The Printout
Vertical bands appear on the printout. Basic image ABCDE ABCDE [Cause] - The media advance adjustment value is not appropriate for the media used. - The media is curled or wrinkled. Cause Solution The media advance adjustment value is (1) Fine adjust the media advance adjustment value in the ± 0.3% range. not appropriate for the media used.
Page 246 Troubleshooting...
Page 247: Menu Tree
Menu tree...
Page 248 PRINTING... MENU CHECK TUR UNIT STANDARD ND BI WARNING INFO (printing) PERFORM START MAINTENANCE <No warnings> NO WARNING MENU >INK INFORMATION >>REMAINING INK CC: Ink color XXX%: Remaining ink INK INFORMATION REMAINING INK CC XXX% (CIS only) >INK INFORMATION >>INK MFG DATE CC: Ink color INK MFG DATE CC YYYY/MM/DD...
Page 249 <Warning examples> PRINTER READY MENU >INFORMATION CHECK MEDIA 01: PAPER / 1626mm FOR WRINKLES INFORMATION WARNING INFO (not printing) PERFORM START MAINTENANCE <No warnings> NO WARNING >>INK INFORMATION >>>REMAINING INK CC: Ink color XXX%: Remaining ink REMAINING INK CC XXX% >>INK INFORMATION >>>INK MFG DATE CC: Ink color...
Page 250 A´ A´´ >>VERSION INFO Displays version and revision of IPB board. :XXX >>VERSION INFO Displays version of ACT board. :XXX >>VERSION INFO Displays version of LEC board. :XXX >>VERSION INFO Displays version of BTC (FPGA) board. :XXX >INFORMATION >>USB INFO Displays USB address.
Page 251 B´ Z: Registration mark (A registration mark * is displayed if the media preset is registered) YYYYYYYY: Current print mode setting >EDIT MEDIA PRESETS >>BIDIR ADJ VAL DET1 >>PRINT MODE UNDEFINED BIDIR ADJ VAL DET1 PRINT MODE:YYYYYYYY ZYYYYYYYY 1:FAST PROD, PROD 2:STRD, QUALITY 3:HIGH QUALITY 4:MAX QUALITY...
Page 252 C´ >EDIT MEDIA PRESETS >>HEATER PRIORITY Z: Registration mark (A registration mark * is displayed if the media preset is registered) YYYY: Heater setting priority after change HEATER PRIORITY ZYYYY Celsius Z: Registration mark (A registration mark * is displayed if the media preset is registered) >EDIT MEDIA PRESETS >>AFTERHEATER T XX: Currently set temperature...
Page 253 D´ >>MISC SETTINGS >>>SUCTION FAN POWER Z: Registration mark A registration mark * is displayed if the media preset is registered YYY: Setting after change SUCTION FAN POWER ZYYY >>MISC SETTINGS >>>MEDIA ADVANCE MODE Z: Registration mark A registration mark * is displayed if the media preset is registered YYY: Setting after change MEDIA ADVANCE MODE ZYYY...
Page 254 E´ >>SYSTEM >>>DATE FORMAT DATE FORMAT YY/MM/DD >>SYSTEM >>>TIME ZONE yy/mm/dd hh:mi: Local time display ZZZ: In the -12 to +12 range (25 values possible) Time zone TIME ZONE yy/mm/dd hh:mi ZZZ >>SYSTEM >>>LENGTH UNIT YYY: Setting after change LENGTH UNIT >>SYSTEM >>>TEMPERATURE UNIT YYY: Setting after change...
Page 255 PRINTER READY ADJUST >MEDIA ADVANCE 01: PAPER / 1626mm MEDIA ADVANCE MEDIA ADVANCE AUTO >MEDIA ADVANCE >>MEDIA ADV MANUAL MEDIA ADV MANUAL 1 PATTERN >>MEDIA ADV MANUAL 3 PATTERNS >>MEDIA ADV MANUAL FEED MEDIA >>MEDIA ADV MANUAL BACK FEED MEDIA >>MEDIA ADV MANUAL >>>...
Page 256 ADJUST >BIDIR ADJ DETAILED >>DETAILED 1 >>>PRINT MODE BIDIR ADJ DETAILED DETAILED 1 PRINT MODE YYYYYYYYY YYYYYYYYY: Print mode UNDEFINED 1:FAST PROD, PROD 2:STRD, QUALITY 3:HIGH QUALITY 4:MAX QUALITY 5:FINE DETAIL >>DETAILED 1 >>>CARRIAGE SPEED CARRIAGE SPEED YYYYYYYYY YYYYYYYYY: Carriage speed NORMAL SLOW >>DETAILED 1...
Page 257 PRINTER READY MAINTENANCE 01: PAPER / 1626mm START MAINTENANCE MAINTENANCE >WIPER MAINTENANCE WIPER MAINTENANCE WIPER BLADE CHECK >WIPER MAINTENANCE REPLACE BLADE >WIPER MAINTENANCE REPLACE LIQUID >WIPER MAINTENANCE REPLACE SPONGE XXXX: Maintenance type MAINTENANCE >PH MAINTENANCE SHEET MOUNT CLNING PH MAINTENANCE XXXX CLEAN FOR STORAGE CLEAN PH &...
Page 258: Appendix
Appendix...
Page 259: Basic Specifications
Basic specifications Specification / Function Item IP-5630 IP-5530 Print method Piezo-type color inkjet printing (main scanning direction) x (subscanning direction) 360 dpi × 180 dpi × DDP, 360 dpi × 360 dpi × DDP, Resolution 540 dpi × 360 dpi × DDP, 540 dpi × 540 dpi × DDP, 720 dpi ×...
Page 260: Consumables
If it is swallowed, do not try to induce vomiting, but consult a doctor. CAUTION ‹ Always use OKI Data specified ink cartridges. Failure to use the recommended ink cartridges may lead to a deterioration of the print quality or a printer malfunction. This may also invalidate your warranty.
Page 261 Daily maintenance kit A Type Content Quantity Cap cleaning liquid A 100 ml Wiper cleaning liquid A 200 ml Cleaning swab 10 pieces IP5-280 Cleaning swab (Thick) 30 pieces Tweezers 1 pair Rubber blade 2 pieces Sponge blade 1 piece WARNING ‹...
Page 262 Sheet mount cleaning kit A Type Content Quantity Head cleaning sheet 12 sheets Cap cleaning sheet 12 sheets Sheet mount cleaning liquid A 2 piece IP5-283 (100 ml) Dropper 3 piece 24 pieces Gloves (12 pairs) Appendix...
Page 263: Options
Options Exhaust attachment (IP-265) An optional unit to attach an exhaust duct to the printer Cutter unit (64) (IP5-262, for IP-5630 model) Cutter unit (54) (IP5-263, for IP-5530 model) This cutter unit is optional to cut the media. Ionizer kit (IP5-254) An optional unit used to neutralize static electricity on the media and minimize quality problems caused by ink mist.
Page 264: Distributors
Österreich www.oki.com/at Canada www.oki.com/ca/ Schweiz/Suisse/Svizzera www.oki.com/ch Brasil www.oki.com/br/printing Polska www.oki.com/pl México www.oki.com/mx/ Česká www.oki.com/cz Argentina www.oki.com/la/ Slovenská www.oki.com/sk Colombia www.oki.com/la/ Magyarország www.oki.com/hu Other countries www.oki.com/printing/ Россия www.oki.com/ru China www.oki.com/cn/printing/ Oki Data Corporation 4-11-22, Shibaura, Minato-ku, Tokyo 108-8551, Japan www.oki.com/printing/ Appendix...
Page 265 47106202EE Rev3...

This manual is also suitable for:

Ip-5530

Oki IP-5630 User Manual

Introduction

Table of Contents

Safety Precautions

Symbol on the Printer

Manual Legend (Notational Rules)

Components Delivered with the Printer

Operating Conditions

FFTSS Library, Employed by the Software Installed on the Printer

Before Printing

Appearance / Main Components and Their

Functions

To Turn the Printer on and off

To Connect the USB Cable

Online and Offline

Cp_Manager

Supported Media

Loading the Media

Loading the Media on the Printer

Setting the Media on the Take-Up Reel Unit

Adjustment of the Take-Up Reel Unit

Removing the Media

Cutting the Media

Unwind the Media from the TUR Unit

Before Making Adjustment

Adjustment Methods

Daily Maintenance

Routine Maintenance

Weekly Maintenance

Maintenance When a Message Is Displayed

Maintenance When the Printer Is Dirty

After the Operation of the Day

When Not Using the Printer for more than 2 Weeks

Check the Printer Information

Handle the Media

How to Use the Lifter

To Change the Printer's Basic Settings

Controlling the Media Advance Adjustment Value

Print Conditions

Adjust the Heaters Temperatures

Out of Ink While Printing

Troubleshooting

Check the Problem

How to Clear Media Jams

When an Error Message Is Displayed

The Media Has Skewed

Warning Messages

Clear Missing Dots (Nozzle Clogging)

Media Wrinkles Have Been Detected

Solve Print Quality Issues

Menu Tree

Appendix

Basic Specifications

Consumables

Options

Distributors

Quick Links

Related Manuals for Oki IP-5630

Summary of Contents for Oki IP-5630
