Page 1: Quick Reference Guide
W i d e Fo r mat Pr i nte r Te r i o s t a r LP-10 3 0 Se r i e s Multifunction Model LP-1030-MF Printer Model LP-1030 Quick Reference Guide U00123009604... -
Page 2: Table Of Contents
Preface Your Printer is a Teriostar LP-1030 Series Wide Format Printer. This manual describes the basic operation methods for both the LP-1030 and LP-1030-MF models. For more detailed information, see the User's Manuals on the supplied CD-ROM. Keep this guide in a place where you can easily read it when required. Table of Contents Turning the Power On/Off ……………………... -
Page 3: Turning The Power On/Off
Turning the Power On/Off Power On Power Off Press down for 1 sec. or longer Mode Buttons z COPY button Changes to copy mode, and the lamp at the button's User's left lights up. For more details, see the separate Manual for Multifunction Printer Operation. -
Page 4: Replacing The Paper
Replacing the Paper... - Page 5 Replacing the Paper 60 cm (23.63 inches) ロール紙の交換 Replacing Roll Paper 用紙カッ ト位置 Paper Cut Position...
-
Page 6: Replacing The Toner Cartridge
Replacing the Toner Cartridge... - Page 7 Replacing the Toner Cartridge Disposing of Empty Toner Cartridges Put the used toner cartridge into the bag provided in the box of the new toner cartridge, and dispose of it according to the local regulations.
-
Page 8: Replacing The Waste Toner Bottle
Replacing the Waste Toner Bottle ① ②... - Page 9 Replacing the Waste Toner Bottle ① ② Disposing of Used Toner Bottles Dispose of the waste toner bottle according to the local regulations.
-
Page 10: Replacing The Charger Unit
Replacing the Charger Unit Press down for 1 sec. or longer... - Page 11 Replacing the Charger Unit ‘ The charger unit can be installed in either direction. If lines or other defects appear on the printout, inverting the charger unit right and left sides may solve the problem.
-
Page 12: Replacing The Process Cartridge
Replacing the Process Cartridge Press down for 1 sec. or longer... - Page 13 Replacing the Process Cartridge...
-
Page 14: Part Names
Part Names Front Side Multifunction Model Scanner cover Original output guide Document table Latch lever Filter cover Drawer for roll 1 Waste toner door Drawer for roll 2 Printer Model Latch lever Filter cover Drawer for roll 1 Waste toner door Drawer for roll 2... -
Page 15: Printer Model
Part Names Rear Side Multifunction Model Printer Model Toner door Toner door Rear door Rear door Process cartridge drawer Fuser unit drawer Paper outlet cover... -
Page 16: Paper Jams
Paper Jams The door requiring action is displayed, in accordance with the paper jam location. Open the specified door and take the appropriate action to remove the paper jam. Paper jam in a Roll paper drawer ロール紙の交換 Replacing Roll Paper 用紙カッ... - Page 17 Paper Jams Paper jam in the rear door...
- Page 18 Paper Jams Paper jam in the Fuser unit When you cannot pull out the paper easily: ② ①...
- Page 19 Paper Jams Paper jam in a roll paper drawer or front door ロール紙の交換 Replacing Roll Paper 用紙カッ ト位置 Paper Cut Position...
- Page 20 Paper Jams Original jam...
- Page 21 Paper Jams...
-
Page 22: Copying Mf
Copying Press COPY Set the original Position the original facing down. Set it in the Printer aligned with the original width guide. The inserted original is automatically pulled into the Printer, and set. -
Page 23: Importing Images (Documents) To A Computer Mf
Importing Images (Documents) to a Computer Double-click TerioStation. Click the Scan tab. Click Save Folder. Select the destination folder to save the scanned data. Click OK. Click Scan. - Page 24 Importing Images (Documents) to a Computer Click Preferences. Input the Printer IP address in the Assign host name/IP address field. Click OK. Set the scan conditions, and then click Scan. Load the original. Important If "Scanner is operating in another mode" is displayed, press SCAN on the operation panel. ‹...
-
Page 25: Operating The Printer From A Computer Mf
Operating the Printer from a Computer Start the web browser and enter "http://(IP address set on the Printer)" in the address field. Press Enter. Click English. Click an item from the left menu to check the settings or Printer status. -
Page 26: Troubleshooting
Troubleshooting When an Error Message Appears Automatic Paper Cutting After a Certain Time Take the action specified by the panel message. Set Top Cut Timer in the Printer Engine menu. User's Manual for Basic Printer Operation, Or see the Menu Chapter Smears on a Printout Replace the process cartridge. -
Page 27: Automatic Paper Cutting After Opening
Troubleshooting Automatic Paper Cutting After Opening Wrinkles on Tracing Paper and Closing a Door Set Humidity for Tracing Paper to High Humidity Set Top Cut at Door Open to On in the Printer in the Printer Engine menu. Engine menu. Menu Menu Printer Engine... -
Page 28: Missing Print Or Slow Data Reception
Change the driver settings. In Start Menu, open Devices and Printers. Change the output process selection from Process with Printer to Process with Computer. Click OK. Right-click the OKI LP-1030 icon, and then click Printing Preferences. Click the Options tab. Click Apply. - Page 29 Troubleshooting Click OK. If the problem persists: Perform steps 1 to 4 and open Driver Operation Mode. Print. If the symptom persists, perform the following setting operation. Set the resolution of the printer driver to 200dpi or 100dpi. Click OK.
- Page 30 Troubleshooting Click Apply. Click OK. Print. The User's Manuals and driver are on the supplied CD-ROM.
-
Page 31: Service Representatives
Service Representatives OKI Data Infotech offers support to ensure you get the most from your Teriostar LP-1030 Series Printer. For details, contact your dealer or nearest service representative. http://www.okidata-infotech.com/distributors/index.html Disposal Method Dispose of the used toner cartridges and waste toner bottles according to the local regulations. - Page 32 Phone : +81 43 211 1363 Fax : +81 43 211 8709 1-8, Nakase, Mihama-ku, Chiba-shi, Chiba, 261-8507, Japan TEL: (043) 211-1369 U00123009604 December, 2015 Copyright© 2015 OKI Data Infotech Corporation. All rights reserved. The contents of this manual may be changed without prior notice.
