moved with a rotational move-
ment toward the front.
Mount the navigation system 1
in the lower area and swing
backward with a rotational
movement.
Navigation system audibly en-
gages.
Slide the shut-off lock 2 com-
pletely to the right.
The locking mechanism 3 is
locked.
Turn the ignition key 4 clock-
wise.
Navigation system is locked
and ignition key can be re-
moved.
Remove navigation
system and install cover
with preparation for navigation
system OE
with navigation system
ATTENTION
Dust and dirt on the contacts
of the Mount Cradle
Damage to the contacts
Reinstall the cover after end of
each drive.
OA
Turn the ignition key 1 coun-
terclockwise.
Pull the shut-off lock 2 com-
pletely to the left.
The locking mechanism 3 is
unlocked.
Slide the locking mechanism 3
completely to the left.
The navigation system 4 will
be unlocked.
Remove the navigation sys-
tem 4 downward with a tilting
movement.
