General view, right side

1 Adjuster for spring preload,
rear ( 117)
2 Brake-fluid reservoir, front
( 161)
3 Vehicle identification num-
ber (on steering head at
right)
Type plate (on steering
head at left)
4 Coolant level indicator
( 163)
Coolant expansion tank
( 164)
5 Tire inflation pressure table
6 Oil filler opening (
7 Engine oil indicator
( 157)
8 Behind the side trim panel:
Battery ( 178)
Remote positive terminal
( 176)
Data link connector
( 183)
9 Brake-fluid reservoir, rear
( 162)
10 Onboard power socket
( 186)
