Transceiver modules

For more information about transceiver modules supported by the HSR6800 routers, see HPE
FlexNetwork 6600/HSR6600/HSR6800 Router Series Interface Module Guide.

Lightning protector for a port

If part of the network cable of a copper Ethernet port must be routed outdoors, connect a lightning
protector to the cable before you plug the cable into the port.
You can install the following port lightning protectors to the router:
Type
10 Mbps/100 Mbps
port lightning
protector
1000 Mbps port
lightning protector
For how to install the lightning protector for a port, see
port."

Power strip with lightning protection

If part of the AC power line is routed outdoors, use a power strip with lightning protection to connect
the AC power cord of the router to the AC power line to protect the router from being damaged by
lightning strikes.
The specifications for the power strip with lightning protection that can be installed on the router are
as follows:
Maximum discharge current: 6500 A, protection voltage: 500 VAC to 220 VAC.
For how to install the power lightning protector, see
strip with lightning

Surge lightning protector

Generally, you need to connect a surge protector before connecting a signal cable to the router. This
can protect electronic devices against surge over-voltage resulting from lightning strokes and other
interferences, and minimize impact on the router.
The router supports the following types of surge protectors:
•
Surge protector—Maximum discharge current 2.5 KA/protection voltage 25V--SMB-75J/
SMB-75J-1W-10Mbps
•
Surge protector—Maximum discharge current 2.5 KA/protection voltage 25V-BNC-75K/
BNC-75K-10Mbps
•
Surge protector (U port)—Maximum discharge current 3 KA/common-mode 400V/differential
mode 170V-RJ11
For how to install the surge lightning protector, see
Port
description
Single port
Single port
protection."
Maximum discharge
current
(8/20μs waveform)
2.5 KA
3 KA
"Installing a lightning protector for a network
"Connecting the AC power supply to a power
"Installing a surge
108
Output voltage
•
Core-core ≤ 15 V
•
Core-ground ≤ 300 V
•
Core-core ≤ 15 V
•
Core-ground ≤ 350 V
protector."
