Observe and Obey:
Only routine maintenance items specified in this
manual shall be performed by the operator.
Scheduled maintenance inspections shall be
completed by qualified service technicians,
according to the manufacturer's specifications
and the requirements specified in the
responsibilities manual.
Use only Genie approved replacement parts.

Maintenance Symbols Legend

The following symbols have been used in this
manual to help communicate the intent of the
instructions. When one or more of the symbols
appear at the beginning of a maintenance
procedure, it conveys the meaning below.
Indicates that tools will be required to
perform this procedure.
Indicates that new parts will be required to
perform this procedure.
Indicates that a cold engine is required
before performing this procedure.
Part No. 133083

Check the Engine Oil Level

Maintaining the proper engine oil level is essential
to good engine performance and service life.
Operating the machine with an improper oil level
can damage engine components.
Note: Check the oil level with the engine off.
1 Check the oil dipstick. Add oil as needed.
Perkins 404-22 Engine
Oil type
Oil type - cold conditions
Ford DSG-423 EFI Engine (EPA Compliant)
Oil type
Deutz F3L 2011F Engine (Tier II)
Oil type
Oil type - cold conditions
Z-60/34
Operator's Manual
Maintenance
15W-40
5W-40
5W-20
15W-40
5W-30
49
