Specifications - Genie Z-60/34 Operator's Manual

Seventh Edition · First Printing
Height, working maximum
Height, platform maximum
Height, stowed maximum
Horizontal reach maximum
Width
Length, stowed
Maximum load capacity
Maximum wind speed
Wheelbase
Turning radius (inside)
Turning radius (outside)
Turntable rotation (degrees)
Turntable tailswing
Drive speed, stowed
Drive speed,
raised or extended
Airborne noise emissions
Maximum sound level at normal operating workstations
(A-weighted)
Controls
Platform dimensions,1.2 m
(width x length)
Platform dimensions, 1.5 m
(width x length)
Platform dimensions, 1.8 m
(width x length)
Platform dimensions, 2.4 m
(width x length)
Platform leveling
Platform rotation
AC outlet in platform
Vibration value does not exceed 2.5 m/s
Part No. 133083
20.1 m
18.3 m
2.7 m
10.4 m
2.5 m
8.2 m
227 kg
12.5 m/s
2.5 m
3.04 m
6.1 m
continuous
0
4.8 km/h
12.2 m/9 sec
1.0 km/h
12.2 m/40 sec
105 dB
12V DC proportional
76 cm x 1.2 m
76 cm x 1.5 m
76 cm x 1.8 m
91 cm x 2.4 m
self-leveling
180°
standard
2
Z-60/34
Hydraulic pressure, maximum
(boom functions)
System voltage
Tires
Ground clearance
Fuel tank capacity
Weight
(Machine weights vary with option configurations)
Maximum slope rating, stowed position, 2WD
Platform downhill
Platform uphill
Side slope
Maximum slope rating, stowed position, 4WD
Platform downhill
Platform uphill
Side slope
Note: Slope rating is subject to ground conditions and
adequate traction.
Floor loading information
Tire load, maximum
Tire contact pressure
Occupied pressure
Note: Floor loading information is approximate and
does not incorporate different option configurations. It
should be used only with adequate safety factors.
Continuous improvement of our products is a Genie
policy. Product specifications are subject to change
without notice or obligation.
Operator's Manual

Specifications

166 bar
12V
15 x 19.5, 16-ply
40.1 cm
75.7 liters
See Serial Label
25% (14°)
20% (11°)
25% (14°)
40% (22°)
30% (17°)
25% (14°)
4504 kg
2
4.57 kg/cm
448 kPa
2
1240 kg/m
12.16 kPa
53
