Symbol And Hazard Pictorials Definitions - Genie Z-60/34 Operator's Manual

Seventh Edition · First Printing
Crush Hazard
Explosion Hazard
Fall Hazard Crush Hazard
Tip-over Hazard Tip-over Hazard
Keep off this Keep away from
surface. moving parts.
Read the No smoking.
operator's No flame.
manual. Stop engine.
Part No. 133083

Symbol and Hazard Pictorials Definitions

Fire Hazard Explosion Hazard
Tip-over Hazard Tip-over Hazard
Read service
Electrocution
manual
Hazard
Maintain required Keep away from
clearance. path of moving
platform.
Recovery procedure if tilt alarm sounds
while elevated.
3
Platform downhill:
Platform uphill:
1 Retract primary
1 Lower primary
2 Lower secondary
2 Lower secondary
3 Lower primary
3 Retract primary
Z-60/34
Operator's Manual
Electrocution
Hazard
Tip-over Hazard
Rated platform
capacity
Only trained
maintenance
personnel should
access
compartments
3
Do not use ether
or other high
energy starting
aids on machines
equipped with
glow plugs.
3
