Setting Up the Microphone

Table 4-1
Problem
No sound is heard.
Sound heard at wrong speaker.
Sound is not synchronized with
video.
Setting Up the Microphone
The microphone is set up correctly when each microphone registers sound. You must supply sound at
each microphone to complete setup.
To set up the microphones for use with the CTS 1100, complete the following procedure.
Step 1 Navigate to Troubleshooting > Hardware Setup > Microphones.
Step 2 Click Start to begin setup.
Lightly tap the microphone and watch the audio meter on the corresponding display screen to see that
Step 3
sound registers.
Step 4 Click Stop to complete the microphone setup.
Troubleshooting Microphones
Use
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
4-28
Troubleshooting Chart for Speaker Problems
Table 4-2 to troubleshoot problems with microphones.
Possible Cause
Speaker cable is not connected
or is only partially connected.
Speaker cable is not connected in
the correct connector.
—
Chapter 4 First-Time Setup
Possible Solution
Check that the red and black
pronged ends of the speaker
cable are securely fastened under
their corresponding connectors
on the speaker.
Check that the speaker cable is
plugged into the correct receptor
on the primary codec.
Tug on the plug to see if it is
fully plugged in. Press the plug
in firmly until a click is heard.
Check that the speaker cable is
plugged into the correct receptor
on the primary codec. Plug all
speakers into the primary codec.
Contact Cisco technical support.
