Field-Replaceable Unit Guide

Revised: February 17, 2010, OL-19695-01
This chapter describes the procedures you take to replace the field-replaceable units (FRUs) for the
Cisco TelePresence System 1100 (CTS 1100) and includes the following sections:
•
•
•
•
•
•
•
•
•
Finding the Serial Number Location
You might need the serial number of your CTS 1100 to order FRUs. The serial number is located on the
lower part of the light reflector as shown in
OL-19695-01
Finding the Serial Number Location, page 6-1
Complete List of Spares For the Cisco TelePresence System 1100, page 6-2
Replacing the Camera—Part Number CTS1100-CAM=, page 6-4
Replacing the Dimmer Box—Part Number CTS-LIGHT-DIM=, page 6-5
Replacing the Auxiliary Control Unit—Part Number CTS-LIGHT-CTRL=, page 6-6
Replacing the Audio/Video Extension Unit—Part Number CTS-AV-EXP=, page 6-9
Replacing a Codec—Part Number CTS-CODEC-PRI-G2=, page 6-11
Replacing a Light Fixture—Part Number CTS-LT-FX-LED-3H=(3.5 Foot) or
CTS-LT-FX-LED-5FT= (5 Foot), page 6-12
Replacing the Display—Part Number CTS-DISP-65-GEN4=, page 6-14
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
C H A P T E R
Figure 6-1.
6
6-1
