Chapter 4 First-Time Setup
Replace the camera cover onto the camera cluster, then tighten the cover release screws to secure the
Step 10
cover to the camera.
Figure 4-19

Setting Up the Speakers

The speakers are set up correctly you can hear sound clearly from each one. You can choose whether you
want to cycle through the speakers automatically or manually.
•
•
•
•
Troubleshooting Speakers
Use
OL-19695-01
Replacing the Camera Cover
Click Speakers on the Hardware Setup window to select the speaker test.
Click Start to begin the speaker setup.
Click Cycle Through Speakers to have sound cycled automatically for 5 seconds on each speaker.
Click Manually Step Through Speakers to test sound on each speaker. Click Next Speaker to
progress to the next speaker.
Table 4-1 to troubleshoot problems with speakers.
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
Cover
release
screws
Cover
release
screws
Setting Up the Speakers
4-27
