Required Tools and Accessories

Required Tools and Accessories
The following tools are required to install the CTS 1100:
•
•
•
•
•
•
Note
•
•
•
•
Note
•
•
•
•
•
•
•
•
•
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3-4
The following drill bits:
1/8-inch (3 mm) drill bit to find stud edges (for steel or wooden studs) or as a pilot hole (for concrete,
concrete block, or brick walls)
11/64-inch drill bit (to drill holes in the table for the microphone screws)
7/32-inch drill bit (for wooden stud walls)
10mm drill bit (for concrete, concrete block, or brick walls)
1/2-inch drill bit at least 6 inches (15 cm) long (for drywall anchors in steel stud walls and to drill
holes for the microphone cords)
For more accurate drilling, a drill bit with a pilot tip is recommended.
The following sockets:
6mm socket (to assemble the bezel)
–
10mm socket (with socket extension)
–
12mm socket with at least a 6-inch (15 cm) socket extension
–
1/2-inch socket (to remove the light reflector)
–
– 13mm socket (to install the lag screws for wooden stud walls)
The following screw drivers:
– #1 Phillips screw driver with long reach—8 inches (20 cm) minimum
#3 Phillips screw driver
–
Flat head screw driver
–
3mm Allen wrench at least 6 inches (15 cm) long (for securing the camera)
10mm open end wrench (to remove the light covers)
A 10mm open end ratcheting wrench can be useful to remove the nuts for the light covers.
3 mm Allen wrench with a minimum 6 inch (15 cm) extension (for installing the camera bracket)
Stud finder
Tape measure
Pencil or other marking tool (to mark the wall)
Duct tape or other tape (to mark the wall and to secure the cables to the underside of the cable cover)
Wire cutters for wire cable ties
Level
Uncrating tools—for example, a pry bar or crow bar
Cutting tool (such as tin snips) to remove the metal straps on the crate
