Assembling and Mounting a Cisco TelePresence
System 1100
Revised: December 7, 2011, OL-19695-01
This chapter contains the procedure you use to mount and assemble a Cisco TelePresence System 1100
(CTS 1100). You can mount the CTS 1100 to any of the following wall types:
•
•
•
This chapter includes the following sections:
•
•
•
•
•
•
•
•
Important Warnings and Cautions
A WARNING alerts you to the possibility of serious injury or death if you do not follow the instructions.
Warning
A CAUTION alerts you to the possibility of damage or destruction of equipment if you do not follow
Caution
the corresponding instructions.
OL-19695-01
A wall with wooden studs
A wall with steel studs
A concrete, concrete block, or brick wall
Important Warnings and Cautions, page 3-1
Required Tools and Accessories, page 3-4
Parts List, page 3-5
Attaching the Mounting Bracket to a Wall With Wooden Studs, page 3-8
Attaching the Mounting Bracket to a Wall With Steel Studs, page 3-14
Attaching the Mounting Bracket to a Concrete, Concrete Block, or Brick Wall, page 3-21
Attaching the Light Reflector, Display, and Cabinet, page 3-27
Completing Installation and Cabling of the CTS 1100, page 3-45
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
3
C H A P T E R
3-1
