Attaching The Mounting Bracket To A Concrete, Concrete Block, Or Brick Wall - Cisco TelePresence System 1100 Assembly Manual

Chapter 3 Assembling and Mounting a Cisco TelePresence System 1100
Step 13 Move the sliders and strips so that they align as closely as possible with the center of the table.
Using duct or other tape, tape the strip between the sliders into the slot in the bracket.
Step 14
Tip The tape prevents the sliders from moving when you install the light reflector.
Figure 3-15 Centering the Studs and Strips to Accommodate Table Placement
Continue to the
Step 15
installation.
Attaching the Mounting Bracket to a Concrete, Concrete Block,
or Brick Wall
This section contains the procedure you use to mount the MSP-CSC6 mounting bracket to a concrete,
concrete block, or brick wall.
To attach the mounting bracket to the wall, perform the following steps:
OL-19695-01

Attaching the Mounting Bracket to a Concrete, Concrete Block, or Brick Wall

Bracket
Bracket
"Attaching the Light Reflector, Display, and Cabinet" section on page 3-27
Cisco TelePresence System 1100 Assembly, First-Time Setup, and Field Replaceable Unit Guide
Sliders
Table
Sliders
Table
to complete
3-21
