Configuration Prerequisites; Enabling Ipv6 Pim-Sm - HP A5500 SI Switch Series Configuration Manual

Task
Configuring IPv6
administrative scoping
Configuring IPv6 multicast source registration
Disabling SPT switchover
Configuring IPv6 PIM common features

Configuration prerequisites

Before you configure IPv6 PIM-SM, complete the following tasks:
Enable IPv6 forwarding and configure any IPv6 unicast routing protocol so that all devices in the
•
domain are interoperable at the network layer.
Determine the IP address of a static RP and the IPv6 ACL that defines the range of IPv6 multicast
•
groups that the static RP will serve.
Determine the C-RP priority and the IPv6 ACL that defines the range of IPv6 multicast groups to be
•
served by each C-RP.
Determine the legal C-RP address range and the IPv6 ACL that define the range of IPv6 multicast
•
groups to be served.
Determine the C-RP-Adv interval.
•
Determine the C-RP timeout.
•
Determine the C-BSR priority.
•
Determine the hash mask length.
•
Determine the IPv6 ACL rule defining a legal BSR address range.
•
Determine the BS period.
•
Determine the BS timeout.
•
Determine the IPv6 ACL for register message filtering.
•
Determine the register suppression time.
•
Determine the register probe time.
•
Determine the IPv6 ACL and sequencing rule for disabling SPT switchover.
•

Enabling IPv6 PIM-SM

With IPv6 PIM-SM enabled, a router sends hello messages periodically to discover IPv6 PIM neighbors
and processes messages from the IPv6 PIM neighbors. When you deploy an IPv6 PIM-SM domain,
enable IPv6 PIM-SM on all non-border interfaces of the routers.
Follow these steps to enable IPv6 PIM-SM:
To do...
Enter system view
Enable IPv6 multicast routing
Enabling IPv6 administrative scoping
Configuring an IPv6 admin-scope zone boundary
Configuring C-BSRs for IPv6 admin-scope zones
Use the command...
system-view
multicast ipv6 routing-enable
348
Remarks
Optional
Optional
Optional
Optional
Optional
Optional
Remarks
—
Required
Disabled by default.
