X& = Active pixels
X* = Active lines
X( = Enable or disable
X1) = Input standard
X1! = Internal temperature
X1@ = Film detect mode
X1# = Horizontal and vertical
frequencies
= Text label
X1$
= Picture adjustment
X1%
= Horizontal position
X1^
= Vertical position
X1&
= Horizontal size
X1*
X1( = Vertical size
X2) = Test patterns
= User presets
X2!
= Input presets
X2@
= On-screen display bug time-
X2#
out
Output sync time-out
X2$ = Executive mode status
= Overscan
X2%
X2^ = Aspect ratio setting
IN1606 and IN1608 Series Scaling Presentation Switcher • SIS Configuration and Control
of the default value
±512
of the default value
±256
= off or disabled
0
= on or enabled
1
= no signal detected on the current input
0
= NTSC 3.85
1
= PAL
2
= NTSC 4.43
3
= SECAM
4
= N/A (occurs when the input is active RGB,
-
YUV, or HDMI signal)
In degrees Celsius
= disabled
0
= auto (default)
1
xxx.x
Up to 63 characters
( = default)
0-127 64
±2048
±1200
0-04096
0-02400
= off (default)
0
= crop
1
= alternating pixels
2
= color bars
3
= grayscale
4
= blue mode
5
= audio test pattern (pink noise)
6
01-16
1-128
= OSD is never displayed, output sync is
0
instantly disabled with no active input
= 1 second increments
1-500
= OSD bug time-out default
3
= OSD bug never times out, output sync
501
never times out
= off or disabled (default)
0
= mode 1 (complete front panel lockout)
1
= mode 2 (only allow input switching and
2
volume control)
= 0.0% (default for RGB, HDMI)
0
= 2.5% (default for RGBcvS, YUV, S-video,
1
and CV)
= 5.0%
2
= fill (default)
1
= follow
2
