Input Format — Press the navigation buttons to select an analog video input format for
inputs 1 and 2. All other inputs are digital inputs for HDMI or DVI input signals. The following
table shows the available formats for each input.
Input 1 Input 2 Input 3
RGB RGB HDMI
(default) (default) (default)
YUV YUV
RGBcvS RGBcvS
S-Video S-Video
Composite Composite
Film Mode — Press the navigation buttons to turn Film Mode 3:2 and 2:2 detection on
(auto detect mode) or off.
Start — Press the
and
Left
start values. Press the and
Up
only).
Active — Press the and
Left
pixels. Press the and
Up Down
Total Pixels and Phase — Press the
or . Press the
Pixels Phase
only).
HDCP Authorized — Press the navigation buttons to enable or disable the HDCP
Authorized feature. This feature determines if a digital input will report as an HDCP
authorized sink to a source.
For source devices that require encryption, enable HDCP Authorized. If HDCP Authorized
is disabled for sources that require encryption (for example, a Blu-ray player), the output is
muted or a warning message is displayed.
Some source devices may encrypt their output even if the source material does not require
HDCP encryption, preventing content from being displayed on a non-HDCP compliant
display. Disable HDCP Authorized to allow the output of the scaler to remain unencrypted.
EDID — Press the navigation buttons to select an EDID for the active input. Select a
discrete EDID from a list of factory-supplied EDID or select
resolution and refresh rate (see
and refresh rates).
IN1606 and IN1608 Series Scaling Presentation Switcher • Operation
Input 4 Input 5
HDMI HDMI
(default) (default)
buttons to select the horizontal (H) or vertical (V) pixel
Right
buttons to adjust the selected position (analog inputs
Down
buttons to select the horizontal (H) or vertical (V) active
Right
buttons to adjust the selected value (analog inputs only).
and
Left Right
and buttons to adjust the selected value (analog inputs
Up Down
Resolution on page 33 for a full list of available resolution
Input 6 Input 7 Input 8
(IN1608) (IN1608)
HDMI HDMI
(default) (default)
buttons to select either
Total
to use the output
Match Output
HDMI
(default)
