Muratec PLAIN-PAPER DIGITAL FAX/COPIER/PRINTER/SCANNER MFX-1330 User Manual page 173

Message on the LCD
Feeder In Use
Hang Up Phone
In Relay Box
or
In Secure Box
Invalid I.D. Code
Invalid Number
Invalid Passcode
Line Busy
Macro In Use
Memory Overflow
Start or Cancel
Memory Overflow
Press Stop
Memory Overflow
Rx
Mirror Carriage Error
Mirror Locked
No Command Stored
No Department Code
No Document Stored
No Drum
No Number Stored
No Passcode
No PIN Number
No Report
No Toner Cartridge
Not Allowed in Macro
Open 1st Side Cover
Please Remove Paper
The command you are trying to enter requires the use of the ADF, which is already in
use. Wait for the machine to stop using the ADF, then try again.
The external telephone is not settled completely on its cradle.
You tried to store a document into the F-code box which is set to be a relay box or secu-
rity box. Select the F-code box which is set to be a bulletin box.
The F-code box I.D. code you entered is not valid. Try re-entering your F-code box I.D. code.
You pressed a key which has no function during the current operation.
The protection passcode (see page 9.2) you entered is not valid. Repeat the operation,
entering the correct protection passcode.
You tried to erase a document which someone is polling from your machine. Wait for the
fax to complete the polling operation.
You tried to change the function for a Soft key, but that Soft key has been programmed
in a Macro key. You cannot change the Soft key function until erase the Macro key that
contains the Soft key you want to change. Erase the Macro, then try again.
You tried to enter more pages into memory than your machine could store. Press
to tell your machine to keep as many pages in memory as possible, or press
delete from memory all pages stored during this operation (but not previous operations).
In PC printing, the machine received data more than it can fit in memory.
Press to cancel the printing job. Either delete unnecessary documents, retry after
STOP
more memory becomes available, or split the printing into more than one operation.
Memory has overflowed during the fax reception.
Press stop to return the standby screen.
The mirror carriage of your machine has become inoperable. Contact your Muratec
dealer.
The transport mode is not turned off. Turn off the transport mode (see page 1.11).
./
You pressed
JOB CONFIRM FAX CANCEL
had no stored.
– or –
You pressed a macro key which is not programmed any command.
You tried to turn on the department code setting but there are no department codes
stored in your machine. Store at least one department code.
– or –
You entered incorrect department code at fax sending while the department feature is
on. Enter correct department code.
You tried to print a document from memory, but your machine had none stored.
The drum cartridge is missing or has not been properly installed in your machine.
Please properly install the drum cartridge.
You selected an autodialer, batch box or F-code box number for which there is no fax (or
phone) number programmed. Either choose another number or dial a phone number
directly from the numeric keys.
You tried to program a security feature (see page 9.2), but there are no protection pass-
code stored in your machine. Store a protection passcode (see page 9.2).
You selected "Mode1" in the PIN mask feature and tried to call an autodialer number in
which no PIN has been entered, or to call using numeric keys without PIN. Enter a PIN.
You requested an activity journal or transmit confirmation report, but your machine has
no record of any fax jobs having occurred.
The toner cartridge is missing or has not been properly installed in your machine.
Please properly install the toner cartridge.
During macro registration, you pressed the key which cannot be registered in Macro.
The paper jammed in your machine. Open the side cover and remove the jammed paper
gently and carefully. (See pages 12.11 to 12.13.)
M
Description / Solution
to review upcoming commands, but your machine
& P
AINTENANCE ROBLEM SOLVING
1
2
3
4
5
START
to
CANCEL
6
7
8
9
10
11
12
A
12.15
