Model UXT42
Model UXT52
16
Motor Switch
Off - On
Note: Speed 1
not used
C25
Motor Characteristics
Power Supply
120 VAC
Frequency
60 Hz
Amperage
1.2 ±10% A
Wattage Rating
73 ±10% Watts
Motor Resistance
White - Red
17.1 ±10% Ohms
White - Black
13.6 ±10% Ohms
N
L
GND
Ground
Screw
Y
Y
Lamp Switch
Off - Low - High
1
2
Lamp Switch
1 - 2
1 - 3 Low
L
3
1 - L High
Rectifier
Diode
Ground
Screw
SE114A
N
L
GND
Switch Operation
Mechanical Push Buttons
L-1
Lamps 120 V 1.5 Ohms
4 Buttons
L-2 Speed 1 120 V 1.5 Ohms
L-3 Speed 2 120 V 2.0 Ohms
L-4
Speed 3
120 V
2.5 Ohms
BR (Line)
Y (Lamp)
GY (Speed 1)
R (Speed 2)
BK (Speed 3)
SE119A
Motor Characteristics
Power Supply
Frequency
Amperage
Wattage Rating
Motor Resistance
White - Grey
White - Red
10.7 ±10% Ohms
White - Black
K33 Motor
Operation
Off
3 Speeds
120 VAC
60 Hz
1.7 ±10% A
145 ±10% Watts
15.5 ±10% Ohms
6 ±10% Ohms
