- Page 1 Hope Industrial Systems, Inc. User Manual 15” Industrial LCD Monitor Model No. HIS-ML15B...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety and Regulation Information ......3 Factory Preset Timing ..........4 Panel Controls and OSD Functions......5 Brightness/Contrast Controls ........6 On-Screen Display Functions Image Lock Function ............7 Horizontal and Vertical Position Adjustment ..... 8 Reset ................9 Color Temperature and Control ........ -
Page 3: Safety And Regulation Information
Safety and Regulatory Information Warning To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dangerously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualified personnel only. This equipment is not intended for use in critical applications where its failure to operate would create immediate life threatening circums- tances. -
Page 4: Factory Preset Timing
Factory Preset Timing Horizontal Vertical Pixel Sync Frequency Frequency Clock Polari- Resolution (KHz) (Hz) (MHz) (H/V) IBM, 640 x 350 31.469 70.086 25.175 IBM, 640 x 480 31.469 59.940 25.175 IBM, 720 x 400 31.469 70.087 28.322 VESA, 640 x 480 37.500 75.000 31.500... -
Page 5: Panel Controls And Osd Functions
Panel Controls and OSD Functions Control Panel Control Description Button Function Power On/Off switch* Soft power on/off button. POWER Adjacent LED is lit when on. Menu Button Open the On-Screen Display (OSD) and active MENU a highlighted menu item. Adjustment Buttons Use these buttons to highlight and adjust items + , - using the OSD. -
Page 6: Brightness/Contrast Controls
Brightness and Contrast Controls... -
Page 8: Horizontal And Vertical Position Adjustment
Horizontal and Vertical Position Adjustment... -
Page 9: Reset
Reset Functions... -
Page 10: Color Temperature And Control
Color Temperature and Color Control... -
Page 11: Osd Language
OSD Language... -
Page 12: Menu Position
Menu Position... -
Page 13: Menu Display Time, Mode
Menu Display Time and Display Mode... -
Page 14: Auto Adjustment
Auto Adjustment, OSD Lock/Unlock... -
Page 15: Installation Instructions
Installation Instructions Preparing for Installation Important! Perform the following steps BEFORE Installation of the moni- tor into the panel. 1. Ensure that sufficient power is available. 2. Ensure that sufficient space is available to allow for proper air flow into and out of the unit. - Page 16 Installation into Panel Refer to the drawing below. Locate position in panel for mounting of the monitor. Assure that there is adequate space begin the panel. Allow extra space (0.5 in. behind and on each side) for air ventilation. Cut a rectangular hole in the panel. Clean and deburr. Dimensions: 16.02”...
-
Page 17: Cleaning
Cleaning Resistive Touchscreen model Any standard glass cleaner can be used to clean the touchscreen. Always spray the glass cleaner on the cloth or towel and then clean the touchscreen. Glass cleaner sprayed directly on the monitor could possibly leak inside a non-sealed unit and cause damage. Vinegar or ammonia will not hurt the touchscreen. -
Page 18: Troubleshooting
Troubleshooting Blank Screen After installing the power adapter and connecting I/O cable to a PC, the monitor displays a blank screen. • Press the power button and check to see if the power LED is lit. • If the LED turns green, make sure the PC is powered on. Make sure all cables are connected. - Page 19 Self-Test Feature Check...
-
Page 21: Drawings
Drawings Front and Side Views Rear View (Showing Cutout Dimensions) 406 (16.02”) - Page 22 Rear and Bottom Views...
-
Page 23: Specifications
Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 15.1” diagonal Image size 12.0” (304mm) x 9.0” (228mm) Native resolution XGA (1024 x 768) Plug and Play DDC1/2B compatible` Minimum resolution VGA (640 x 480) Pixel pitch 0.297mm x 0.297mm Number of colors 16 million Viewing Angle (Hori/Vert) - Page 24 Electrical Monitor input 100VAC – 240VAC, 50 – 60Hz Power consumption Approximately 30 watts Power management DPMS/energy star, < 3W Compliance UL 1950, cUL 959; FCC Class A Environmental Temperature 0-50°C (consult factory for installation instructions when con- tinuous 24/7 operation exceeds 40°C) Humidity 20% to 90% non-condensing Shock...
- Page 25 Enclosure Type Panel mount; rear collar compresses gasket against panel, held by 12 10-32 studs Panel rating NEMA 12/4/4X (with proper installation) – built to IP65 stan- dards Physical Depth 2.1” behind panel maximum Bezel Acrylic – matte finish, black; or Stainless Steel Front bezel outside di- 17.2”...
-
Page 26: Warranty Statement
Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent. What Does This Warranty Cover and What is the Period of Coverage? We warrant this product to be free from defects in material and workmanship, subject to the condi- tions set forth below. - Page 28 2002 Hope Industrial Systems, Inc. Publication UM-ML15-B1.0 April 2002...
