Hope Industrial Systems HIS-RL19 Series User Manual

Hope Industrial Systems HIS-RL19 Series User Manual

19" rack mount industrial monitor

Advertisement

Quick Links

19" RACK MOUNT INDUSTRIAL MONITOR
REVISION H
USER MANUAL
Model No. HIS-RL19- _ _ _ H

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIS-RL19 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hope Industrial Systems HIS-RL19 Series

  • Page 1 19" RACK MOUNT INDUSTRIAL MONITOR REVISION H USER MANUAL Model No. HIS-RL19- _ _ _ H...
  • Page 2: Table Of Contents

    Table of Contents Safety and Regulatory Information ���������������������������������������������������������������������������������������3 FCC Notice ������������������������������������������������������������������������������������������������������������������������������������� 3 Hazardous Locations ���������������������������������������������������������������������������������������������������������������������� 4 Waste Electrical and Electronic Equipment Directive (WEEE) ������������������������������������������������������� 4 Mechanical Drawings �������������������������������������������������������������������������������������������������������������5 Front View �������������������������������������������������������������������������������������������������������������������������������������� 5 Bottom View ����������������������������������������������������������������������������������������������������������������������������������� 5 Side View���������������������������������������������������������������������������������������������������������������������������������������� 6 Installation Instructions ���������������������������������������������������������������������������������������������������������7 Step 1: Prepare for Installation ������������������������������������������������������������������������������������������������������...
  • Page 3: Safety And Regulatory Information

    Safety and Regulatory Information Safety and Regulatory Information WARNING! To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dangerously high voltages are present inside the unit� Do not disassemble the unit. Refer servicing to qualified personnel only. Operator could be exposed to dangerously high voltage if AC power is not connected properly�...
  • Page 4: Hazardous Locations

    Users should contact their supplier and check the terms and conditions of the purchase contract� When purchased directly from Hope Industrial Systems, you may contact technical support for disposal arrangements.
  • Page 5: Mechanical Drawings

    Mechanical Drawings Mechanical Drawings Front View 482.6 mm (19.00") 7.1 mm (0.28") 305.6 mm (12.03") 354.3 mm (13.95") 316.9 mm 380.8 mm (12.48") (14.99") 215.3 mm (8.48") 139.1 mm (5.48") 37.5 mm 460.4 mm (1.48") (18.12") Bottom View 448.7 mm (17.66") 60.8 mm (2.40")
  • Page 6: Side View

    Mechanical Drawings Side View 60.8 mm (2.40") 354.3 mm (13.95") RL19H User Manual, 99156B, September 2021...
  • Page 7: Installation Instructions

    Installation Instructions Installation Instructions Step 1: Prepare for Installation IMPORTANT! Perform the following steps BEFORE installation of the monitor into the rack. 1� Ensure that sufficient power is available. 2� Ensure that sufficient space is available to allow for proper air flow into and out of the unit�...
  • Page 8: Step 2: Bench-Test Configuration

    Installation Instructions Step 2: Bench-test Configuration Make sure everything works before installing into the production environment.  TIP! If using a KVM extender, please refer to the installation instructions included with the KVM extender module. It is particularly important to bench-test the full configuration prior to final installation.
  • Page 9 If the video source has a 5 wire analog RGB video output, this can be converted for use with the VGA video port using a simple adapter� Certified adapters are available from Hope Industrial Systems. Contact our sales team for more information�...
  • Page 10: Install Touch Screen Driver

    Serial ports are present on all touch screen monitors, but only one should be used to connect the touch screen interface to the monitor� Contact Hope Industrial Systems if you require a CD-ROM with documentation and drivers for touch screens. For a full list of downloadable drivers, please check the following Internet address: https://www�HopeIndustrial�com/support/drivers/...
  • Page 11 Installation Instructions  the bracket, route one end of the USB cable through the retention bracket and connect it to the USB input port on the monitor. Connect the other end to the USB port on the host computer� NOTE: If this step is not performed, the product will not comply with Class I, Division 2 Hazardous Location requirements.
  • Page 12: Step 3: Install Into Rack

    Hope Industrial Systems' Rack Mount monitors conform to the Electronic Industries Association standard EIA-310-D. Our monitors will fit in type A, B, and C racks with a width of 482.6 mm (19") (preferred EIA rack width)�...
  • Page 13: Video Settings

    Video Settings Video Settings Setting the Timing Mode Setting the timing mode of your computer graphics adapter (or other video source) is important for maximizing the quality of the screen image and for minimizing eye strain. The timing mode consists of the resolution (e.g. 1280 x 1024) and refresh rate (or vertical frequency; e.g. 60 Hz). After setting the timing mode, use the On-Screen Display (OSD) controls to adjust the screen image.
  • Page 14: Control Panel Buttons

    Video Settings Control Panel Buttons Use the control panel buttons located on the back of the monitor to display and adjust various settings on the On-Screen Display (OSD) menu. CONTROL PANEL BUTTONS 1� To display the Main Menu, press button [1]. NOTE: All OSD menus and adjustments screens disappear automatically after 15 seconds.
  • Page 15: Osd And Power Lock Settings

    Video Settings Button Control Functions Menu • Opens the OSD menu� • Exits the OSD menu and saves adjustments. Enter When the OSD menu IS NOT displayed: • Shortcut to Auto Image Adjust. When the OSD menu IS displayed: • Displays the control screen for the highlighted control.
  • Page 16: On-Screen Display (Osd) Menus

    Video Settings On-Screen Display (OSD) Menus To open the OSD menu, press button [1] once. The following screen will appear: Main Menu Description Auto Image Adjust Automatically sizes, centers, and fine tunes the video signal to eliminate waviness and distortion� Contrast / Brightness Includes the Contrast and Brightness functions.
  • Page 17: Auto Image Adjust Menu

    Video Settings Auto Image Adjust Menu The Auto Image Adjust menu automatically sizes, centers, and fine tunes the video signal to eliminate waviness and distortion� NOTE: Auto Image Adjust works with most common video cards. If this function does not work on your display, lower the video refresh rate to 60 Hz and set the resolution to its pre-set value�...
  • Page 18: Color Adjust Menu

    Video Settings Color Adjust Menu The Color Adjust menu provides several color adjustment modes, including preset color temperatures and a User Color mode which allows independent adjustment of red (R), green (G), and blue (B). The factory setting for this product is Native. Color Adjust Menu Description sRGB...
  • Page 19: Information Menu

    Video Settings Information Menu The Information menu displays the timing mode (video signal input) coming from the graphics card in the computer. See your graphics card's user guide for instructions on changing the resolution and refresh rate (vertical frequency)� NOTE: VESA 1280 x 1024 @ 60 Hz (recommended) means that the resolution is 1280 x 1024 and the refresh rate is 60 Hz�...
  • Page 20 Video Settings Manual Image Adjust Description Menu ECO Mode Provides lower power consumption by reducing the brightness. • Standard is the default brightness setting • Optimize reduces brightness by 25% • Conserve reduces brightness by 50% View Mode Allows the user to select from five image modes to find the optimal screen setting for different applications, as well as the default "Standard"...
  • Page 21: Setup Menu

    Video Settings Setup Menu The Setup menu includes the Language Select, Resolution Notice, OSD Position, OSD Time Out, OSD Background, Auto Power Off, and Power Indicator functions. Setup Menu Description Language Select Allows the user to choose the language used in the menus and control screens�...
  • Page 22: Cleaning Instructions

    Cleaning Instructions Cleaning Instructions CAUTION! DO NOT USE ABRASIVE MATERIALS, SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS, ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. IMPORTANT! Always spray the cleaner on the cloth or towel first and then clean the monitor screen.
  • Page 23: Troubleshooting

    If the problem still exists, try bypassing the KVM extender. If this fixes the problem and allows the monitor to work properly, then the KVM extender is the source of the problem� Please refer to the troubleshooting section of the KVM extender manual or contact Hope Industrial Systems for additional assistance. Symptom Causes...
  • Page 24 Troubleshooting Symptom Causes Solutions "Out of Range" The source signal exceeds Adjust the computer settings to the message box the maximum resolution monitor's native resolution: and no image on and/or refresh rate that the 1280 x 1024 @ 60 Hz the screen monitor can handle ( >...
  • Page 25: Touch Screen Troubleshooting

    Troubleshooting Touch Screen Troubleshooting Applies to touch screen monitors only� To be sure that you have the most current driver, please check the following Internet address: https://www�HopeIndustrial�com/support/drivers/ Symptom Causes Solutions No response Touch screen driver has not Download and install the latest driver from when touching been installed�...
  • Page 26: Specifications

    Specifications Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 19" diagonal Image Size (W x H) 374�8 mm x 299�8 mm (14�8" x 11�8") Native Resolution SXGA (1280 x 1024, 5:4 aspect ratio) Minimum Resolution VGA (640 x 480) Pixel Pitch 0�293 mm x 0�293 mm Number of Colors...
  • Page 27: Video

    Specifications Video Input Connectors • HD-15, DVI-D • Compatible inputs using optional adapter (contact Hope Industrial Systems for details): • HDMI (via HDMI to DVI adapter) • DisplayPort (via DisplayPort to DVI adapter) • BNC (via HD-15 to 5-wire BNC adapter) Input Signal Formats •...
  • Page 28: Physical

    Specifications Physical Enclosure Type Rack mount Panel Rating Built to IP20 standards; NEMA/UL Type 1 Bezel Finish Black Powder-Coated Carbon Steel, matte finish Depth Behind Bezel 57�9 mm (2�28") Front Bezel Outside 482�6 mm x 354�3 mm x 3�2 mm (19�0" x 13�95" x 0�125") Dimensions (W x H x D) Net Weight 6.8 kg (15 lbs.)
  • Page 29: Compliances And Certifications

    Specifications Compliances and Certifications Electrical • UL 60950 3 Edition / cUL Recognized Component (File No. E212889) • UL 508A Listed (File No. E318630) • FCC Class A • CAN ICES-3A/NMB-3A • • UKCA • NOM (Registration No. NOM-019-SCFI-1998) Environmental WEEE (Registration No.
  • Page 30: Warranty Statement

    The warranty on all industrial display and keyboard products, KVM2 extender series, and ENCL-TC/ENCL-PC enclosure series remains in force for a five year period beginning on the date we invoice you� If Hope Industrial Systems repairs or replaces a product under warranty, its warranty term is not extended�...
  • Page 31 (This page intentionally left blank.) RL19H User Manual, 99156B, September 2021...
  • Page 32 France Germany Phone: +44 (0) 20 7193 2618 Phone: +44 (0) 20 7193 2618 HopeIndustrial.fr HopeIndustrial.de Italy Spain Phone: +39 80 0740414 Phone: +34 91 1438229 HopeIndustrial.it HopeIndustrial.es RL19H User Manual, 99156B, September 2021 © 2021 Hope Industrial Systems, Inc.
