- Page 1 Hope Industrial Systems, Inc. User Manual 17” Universal Mount Industrial Monitor Model No. HIS-UM17-___A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety and Regulatory Information ........... 3 Factory Preset Timing .............. 4 Monitor Adjustment Functions Direct Functions ..............5 OSD Functions ..............8 Installation Instructions ............10 Cleaning ................. 15 Troubleshooting..............16 Drawings ................17 Specifications ................. 18 Warranty Statement ............... -
Page 3: Safety And Regulatory Information
Safety and Regulatory Information Warning To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dan- gerously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualified personnel only. This equipment is not intended for use in critical applications where its failure to operate would create immediate life threatening circumstances. -
Page 4: Factory Preset Timing
Factory Preset Timing Horizontal Vertical Pixel Sync Frequency Frequen- Clock Polari- Resolution (KHz) (MHz) (Hz) (H/V) IBM, 640 x 350 31.469 70.086 25.175 IBM, 640 x 480 31.469 59.940 25.175 IBM, 720 x 400 31.469 70.087 28.322 VESA, 640 x 480 37.500 75.000 31.500... - Page 5 Control Panel Buttons and Indicators Control Panel Button Mode Description Opens the OSD menu. Also used to exit the OSD MENU Always menu or return to the previous menu. MagicBright Provides an optimum viewing environment depend- ing on the contents of the image you are watching. Currently four different modes are available.
- Page 6 Control Panel Button Mode Description When the Push to adjust brightness. OSD Menu is NOT Dis- played When the Adjusts items in the menu UP. OSD Menu is Being Dis- played When the Activate a highlighted menu item. ENTER OSD Menu is Being Dis- played Use this button for auto adjustment of the display.
-
Page 7: Direct Functions
Direct Functions Menu Description When the ‘AUTO’ button is pressed, the Auto Adjustment screen ap- pears as shown in the animated screen on the center. Auto adjustment allows the monitor to self-adjust to the incoming video signal. The values of fine, coarse and position are adjusted automati- cally. -
Page 8: Osd Functions
OSD Functions Important Note: Except for Brightness and Contrast, all of these func- tions are automatically set by using the AUTO Button. Picture Menu Description Direct Access Feature : When OSD is not on the screen, push the Brightness button to adjust brightness. Adjust the contrast. - Page 9 On-Screen Display (OSD) Menu Description Language Changes the language used in the Menu. H-Position Changes the horizontal position of the OSD. V-Position Changes the vertical position of the OSD. Transparency Changes the translucency of the background of the OSD. The menu will automatically turn off if no adjustments are made for a cer- Display Time tain time period.
-
Page 10: Installation Instructions
Installation Instructions Preparing for Installation Important! Perform the following steps BEFORE Installation of the monitor. 1. Ensure that sufficient power is available. 2. Ensure that sufficient space is available to allow for proper airflow around the enclosure. 3. Ensure that the air temperature around the unit (top and bottom) will not ex- ceed the rated specifications of the unit. - Page 11 Installation using the Bench Top mounting option Prepare the mounting surface for installation of the bench mounting plate referring to the illustration above. Free the bench mounting plate from the assembly by removing the cotter pin, yoke locking nut and stainless steel washer. Install the bench mounting plate into the mounting surface using the ¼...
- Page 12 Installation using Pedestal mounting option Prepare the mounting surface for installation of the pedestal by referring to the illustration above. Install the pedestal using appropriate hardware and methods for the mount- ing surface selected taking strength, cable routing and sealing into consid- eration.
- Page 13 Note: The ¾” conduit and other sealing hardware are not required for NEMA 12 monitors or NEMA 4/4X monitors with the 4-cable gland.
- Page 14 Free the pedestal top plate from the assembly by removing the retaining screw, yoke locking nut, stainless steel washer and 4 ¼-20 screws. Position and support the monitor and yoke assembly so that cables exiting from the monitor can be easily routed into the top of the pedestal. Install the pedestal top plate and polyethylene friction plate using the four ¼-20 screws insuring all cabling inside the pedestal has been fed through the top of the pedestal top plate.
-
Page 15: Cleaning
Cleaning Resistive Touchscreen model Any standard glass cleaner can be used to clean the touchscreen. Al- ways spray the glass cleaner on the cloth or towel and then clean the touchscreen. Glass cleaner sprayed directly on the monitor could possi- bly leak inside a non-sealed unit and cause damage. -
Page 16: Troubleshooting
Troubleshooting Note: For troubleshooting with a KVM extender installed, please refer to the Instal- ler/User Guide that comes with that equipment. Blank Screen After installing the power adapter and connecting I/O cable to a PC, the monitor displays a blank screen. •... -
Page 17: Drawings
Drawings Front View Bottom, Side and Rear View of NEMA 12 option... -
Page 18: Specifications
Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 17” diagonal Image size 13.3” (338mm) x 10.6” (270mm) Native resolution SXGA (1280 x 1024) Plug and Play DDC1/2B compatible` Minimum resolution VGA (640 x 480) Pixel pitch 0.264mm x 0.264mm Number of colors 16 million Viewing Angle (Hori/Vert) - Page 19 Electrical Monitor input 90VAC – 264VAC, 50/60Hz (+/- 3Hz) Power consumption Less than 34W Power management DPMS/energy star, < 1W Compliance UL 1950, cUL 959; FCC Class A Environmental Temperature 0-45°C Humidity 20% to 90% non-condensing Shock 30g (1/2 sine, 11 msec.) Vibration 0.006 inch p-p 15-57Hz, 1.0g 57-640Hz sine Altitude...
- Page 20 Enclosure Type Self-contained; NEMA 12 black powder coated steel Panel rating NEMA 12 Physical Dimensions – Height, 16.4” (417mm) W x 13.94” (354mm) H Width Depth 3.25” (83mm) Net weight Black Carbon Steel Model – 15.50 lbs. Stainless Steel Model – 17.90 lbs. Shipping weight Black Carbon Steel Model –...
-
Page 21: Warranty Statement
Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent. What Does This Warranty Cover and What is the Period of Coverage? We warrant this product to be free from defects in material and workmanship, subject to the conditions set forth below. - Page 22 Hope Industrial Systems, Inc. 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 www.HISmonitors.com 2006 Hope Industrial Systems, Inc. Publication UM-WL17 Rev A March, 2006...
