- Page 1 Hope Industrial Systems, Inc. User Manual 17” Universal Mount Industrial Monitor Model No. HIS-UM17-_ _ _ C...
-
Page 2: Table Of Contents
Table of Contents Safety and Regulatory Information ............... 3 Warning ............................3 FCC Notice ............................3 Control Panel Buttons and Indicators ..............4 OSD Functions ......................5 Picture ............................. 5 Color ..............................5 Image .............................. 6 On-Screen Display (OSD) ........................ 6 Setup ............................... -
Page 3: Safety And Regulatory Information
Safety and Regulatory Information Warning To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dange- rously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualified personnel only. This equipment is not intended for use in critical applications where its failure to op- erate would create immediate life threatening circumstances. -
Page 4: Control Panel Buttons And Indicators
Control Panel Buttons and Indicators Control Panel Button Mode Description Opens the On-Screen Display (OSD) menu. Also used to MENU Always exit the OSD menu or to return to the previous menu. MagicBright: Provides an optimum viewing environment depending on the contents of the image you are watching. Four different modes are available. -
Page 5: Osd Functions
Control Panel Button Mode Description Use this button for auto adjustment of the display. AUTO Auto adjustment allows the monitor to self-adjust to the incoming video signal. The values of fine, coarse and Always position are adjusted automatically. Auto adjustment will also occur automatically each time the computer resolution is changed. -
Page 6: Image
• Mode 2 : Shows higher gamma(brighter) • Mode 3 : Shows lower gamma(darker) Image Menu Description Removes noise such as vertical stripes. Coarse adjustment may move Coarse the screen image area. You may relocate it the center using the Hori- zontal Control menu. -
Page 7: Setup
Setup Menu Description Image parameters are replaced with the factory default values. Image Reset Color parameters are replaced with the factory default values. Color Reset Information Menu Description Shows the video source and display mode. Information... -
Page 8: Installation Instructions
Installation Instructions Preparing for Installation Important! Perform the following steps BEFORE installation of the monitor. 1. Ensure that sufficient power is available. 2. Ensure that sufficient space is available to allow for proper airflow around the en- closure. 3. Ensure that the air temperature around the unit (top and bottom) will not exceed the rated specifications of the unit . -
Page 9: Installation Using The Yoke And Benchtop Mounting Option
Installation using the yoke and benchtop mounting option 1. Insure mounting surface is smooth enough to seal with gasket and create mounting pattern in surface per the above diagram. 2. Install first two opposing ¼-20 flat head screws (two different lengths provided) 3. -
Page 10: Installation Using Yoke And Pedestal Mounting Option
Installation using yoke and pedestal mounting option 1. Prepare the mounting surface for installation of the pedestal by referring to the illustra- tion. 2. Install the pedestal using appropriate hardware and methods for the mounting sur- face selected taking strength, cable routing and sealing into consideration. - Page 11 Installation using yoke and pedestal mounting option (continued from previous page) Note: The ¾” conduit and other sealing hardware are not required for NEMA 12 monitors or NEMA 4/4X monitors with the 4-cable gland.
-
Page 12: Installation Using Fixed Pedestal Mounting Option
Installation using fixed pedestal mounting option 1. Prepare the mounting surface for installation of the pedestal by referring to the illustra- tion. 2. Install the pedestal using appropriate hardware and methods for the mounting surface selected taking strength, cable routing and sealing into consideration. 3. - Page 13 Installation using fixed pedestal mounting option (continued from previous page)
-
Page 14: Touchscreen Driver Installation
Touchscreen Driver Installation The enclosed CD-ROM contains documentation and drivers for all major operating systems. To be sure you have the most current information, check the following Internet addresses: http://HISmonitors.com/Touchscreen_Drivers.htm Setting the Timing Mode Setting the timing mode of your computer graphics adapter (or other video source) is impor- tant for maximizing the quality of the screen image and for minimizing eye strain. -
Page 15: Cleaning
Cleaning CAUTION! DO NOT USE ABRASIVE MATERIALS SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. Resistive Touchscreen model Any standard glass cleaner can be used to clean the touchscreen. Always spray the glass cleaner on the cloth or towel and then clean the touchscreen. -
Page 16: Troubleshooting
Troubleshooting Symptom Check List Solutions Do you see the “Check Signal Cable” Check the video connection from No image on the message on screen? the monitor to the computer. screen If running Windows and the computer If you see the initial screens, then power is on, reboot the computer and the image goes dark, the computer watch for the initial boot and windows... - Page 17 Symptom Check List Solutions • Make sure the PC display resolu- Image on screen Many possible causes. Try the follow- ing solutions. is not perfect tion matches one the factory pre- set timings shown in this manual. • Recall factory setting. Refer to OSD functions in this manual.
-
Page 18: Drawings
Drawings Front View Side and Rear View... -
Page 19: Specifications
Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 17” (43cm) diagonal Image size 13.3” (338mm) x 10.6” (270mm) Native resolution SXGA (1280 x 1024) Plug and Play VESA DDC Minimum resolution 640 x 350 Pixel pitch 0.264mm x 0.264mm Number of colors 16.2 million Viewing Angle (Hori/Vert) -
Page 20: Electrical
Electrical Monitor input 100VAC - 240VAC, 50/60Hz Power consumption Less than 34W Power management DPMS/energy star, < 1W Video Input connector HD-15 (optional BNC input) Input signal format RGB Analog video 0.7Vp-p Positive at 75 Ohm +-10% Separate H/V sync, Composite H/V sync, Sync on green, TTL level positive or negative. -
Page 21: Enclosure
Enclosure Type Self-contained, stainless steel or powder coated carbon steel Environmental rating NEMA 12, 12/4, or 12/4/4X (built to IP65 standards) Seal NEMA 12 gland, NEMA 4 gland, ¾” conduit, or 4-cable gland Mounting VESA pattern 100mm square, M4 threads Optional Yoke mounting with ¼-20 internal thread interface Physical Dimensions –... -
Page 22: Factory Preset Timing
Factory Preset Timing Horizontal Vertical Pixel Sync Polarity Frequency Frequency Clock (H/V) Resolution (KHz) (Hz) (MHz) IBM, 640 x 350 31.469 70.086 25.175 IBM, 640 x 480 31.469 59.940 25.175 IBM, 720 x 400 31.469 70.087 28.322 MAC, 640 x 480 35.000 66.667 30.240... -
Page 23: Warranty Statement
Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent. What Does This Warranty Cover and What is the Period of Coverage? The warranty remains in force for a three year period beginning on the date we invoice you for the product unless it is a keyboard, for which the warranty period is one year. - Page 24 Hope Industrial Systems, Inc. 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 www.HISmonitors.com 2007 Hope Industrial Systems, Inc. Publication UM17 Rev C December, 2007...
