Hope Industrial Systems, Inc.
User Manual
18" Panel Mount Industrial Monitor
Model No. HIS-ML18-xxxC
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HIS-ML18 C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hope Industrial Systems HIS-ML18 C Series

  • Page 1 Hope Industrial Systems, Inc. User Manual 18” Panel Mount Industrial Monitor Model No. HIS-ML18-xxxC...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety and Regulatory Information......3 Using the LCD Display ..........4 Adjusting the Screen Image ........5 Main Menu Controls ............6 Installation Instructions..........9 Cleaning ..............11 Troubleshooting ............12 Specifications ............13 Warranty Statement ..........16...
  • Page 3: Safety And Regulatory Information

    Safety and Regulatory Information Warning To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dangerously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualified personnel only. This equipment is not intended for use in critical applications where its failure to operate would create immediate life threatening circumstances.
  • Page 4: Using The Lcd Display

    Using the LCD Display Setting the Timing Mode Setting the timing mode is important for maximizing the quality of the screen im- age and minimizing eye strain. The timing mode consists of the resolution (exam- ple 1280 x 1024) and refresh rate (or vertical frequency; example 75 Hz). After setting the timing mode, use the controls to adjust the screen image.
  • Page 5: Adjusting The Screen Image

    Adjusting the Screen Image Use the buttons on the rear control panel to display and adjust the On-Screen Display (OSD) con- trols which display on the screen. Do the following to adjust the screen image: To display the Main Menu, press button [1]. NOTE: All OSD menus and adjustment screens disappear automatically after about 30 seconds.
  • Page 6: Main Menu Controls

    Main Menu Controls Adjust the menu items shown below by using the up ▲ and down ▼ buttons. Control Explanation automatically sizes, centers, and fine tunes the video signal to Auto Image Adjust eliminate waviness and distortion. Press the [2] button to obtain a sharper image. NOTE: Auto Image Adjust works with most common video cards.
  • Page 7 displays the Manual Image Adjust menu. Manual Image Adjust controls are explained below: Manual Image Adjust adjusts the width of the screen image. Horizontal Size moves the screen image left or right. Horizontal Position moves the screen image up or down. Vertical Position sharpens focus by aligning the illuminated text and/or graphic charac- Fine Tune...
  • Page 8 allows you to choose the language used in the menus and control Language screens. displays the Resolution Notice menu shown below. Resolution Notice advises the optimal resolution to use. Resolution Notice allows you to move the on-screen display menus and control OSD Position screens.
  • Page 9: Installation Instructions

    Installation Instructions Preparing for Installation Important! Perform the following steps BEFORE Installation of the moni- tor into the panel. 1. Ensure that sufficient power is available. 2. Ensure that sufficient space is available to allow for proper airflow into and out of the unit.
  • Page 10 Installation into Panel Refer to the drawing below. Locate position in panel for mounting of the monitor. Assure that there is adequate space begin the panel. Allow extra space (0.5 in. behind and on each side) for air ventilation. Cut a rectangular hole in the panel. Clean and deburr. Dimensions: 17.85”...
  • Page 11 Touchscreen Driver Installation The enclosed CD-ROM contains documentation and drivers for all major operating systems. To assure you have the most current information, check the following Internet addresses: Manual - AccuTouch Product Manual - version 3.1a - (Part number 821615-000). http://elotouch.com/Support/dwnldmnls.asp Drivers –...
  • Page 12: Cleaning

    Cleaning Resistive Touchscreen model Any standard glass cleaner can be used to clean the touchscreen. Always spray the glass cleaner on the cloth or towel and then clean the touchscreen. Glass cleaner sprayed directly on the monitor could possibly leak inside a non-sealed unit and cause damage. Vinegar or ammonia will not hurt the touchscreen.
  • Page 13: Troubleshooting

    Troubleshooting Blank Screen After installing the power adapter and connecting I/O cable to a PC, the monitor displays a blank screen. • Press the power button and check to see if the power LED is lit. • If the LED is not lit, make sure the PC is powered on. Make sure all cables are connected.
  • Page 14 Drawings Front View...
  • Page 15 Bottom and Rear View (showing cutout dimensions)
  • Page 16: Specifications

    Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 18.0” diagonal Image size 14.1” (359mm) x 11.3” (287mm) Native resolution SXGA (1280 x 1024) @ 60 Hz Plug and Play DDC1/2B compatible Minimum resolution VGA (640 x 350), operation in native resolution (1280 x 1024) will ensure best results Pixel pitch 0.281mm (H) x 0.281 mm (V)
  • Page 17 Electrical Power Input 108 – 127 VAC, 60 Hz, 1A, or 216 – 254 VAC, 50 Hz, 0.5A Power consumption Approximately 46 watts Power management DPMS/energy star, < 3W Compliance UL 1950, cUL 959; FCC Class A Environmental Temperature 0-45°C (consult factory for installation instructions when continuous 24/7 operation exceeds 40°C) Humidity 20% to 90% non-condensing...
  • Page 18 Enclosure Type Panel mount; rear collar compresses gasket against panel, held by 12 10-32 studs Panel rating NEMA 12/4/4X (with proper installation) – built to IP65 stan- dards Physical Depth 1.9” (48 mm) behind panel maximum Bezel Acrylic - matte finish, black; or Stainless Steel Front bezel outside di- 19.0”...
  • Page 19: Warranty Statement

    Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent. What Does This Warranty Cover and What is the Period of Coverage? We warrant this product to be free from defects in material and workmanship, subject to the conditions set forth below.
  • Page 20  2002 Hope Industrial Systems, Inc. Publication UM-ML18B-1.0 August 2002...
