- Page 1 Hope Industrial Systems, Inc. User Manual 15” Panel Mount Industrial Monitor Revision E Model Numbers: HIS-ML15- _ _ _ E...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Safety and Regulation Information ......3 Factory Preset Timing ..........4 Setting the Timing Mode ........... 5 OSD and Power Lock Settings ......... 6 Adjusting the Screen Image........7 Main Menu Controls ..........9 Information for Resistive Touchscreen Monitors ..13 Installation Instructions ........... -
Page 3: Safety And Regulation Information
Safety and Regulatory Information Warning To prevent fire or shock hazard, do not expose the unit to rain or moisture. Dangerously high voltages are present inside the unit. Do not disassemble the unit. Refer servicing to qualified personnel only. This equipment is not intended for use in critical applications where its failure to operate would create immediate life threatening circumstances. -
Page 4: Factory Preset Timing
Factory Preset Timing Horizontal Vertical Pixel Sync Frequency Frequen- Clock Polari- Resolution (KHz) (MHz) (Hz) (H/V) IBM, 640 x 350 31.469 70.086 25.175 IBM, 640 x 480 31.469 59.940 25.175 IBM, 720 x 400 31.469 70.087 28.322 VESA, 640 x 480 37.500 75.000 31.500... -
Page 5: Setting The Timing Mode
Setting the Timing Mode Setting the computer’s timing mode is important for maximizing the quality of the screen image and minimizing eye strain. The timing mode consists of the screen resolution (ex. 1024 x 768) and the refresh rate (ex. 60 Hz or vertical frequency). -
Page 6: Osd And Power Lock Settings
OSD and Power Lock Settings OSD Lock: Press and hold the up arrow for 10 seconds. Locking the OSD disables the OSD buttons. If any buttons are pressed, the message OSD Locked will display for 5 seconds. OSD Unlock: Press and hold the up arrow again for 10 seconds. -
Page 7: Adjusting The Screen Image
Adjusting the Screen Image Use the buttons on the rear control panel to display and adjust the OSD controls which dis- play on the screen. Main Menu With OSD Controls • Power Light: • Displays the Main Menu o Green = On or exists the control o Orange = Power screen, saving adjust-... - Page 8 1. To display the Main Menu, press button [1]. Note: All OSD menus and adjustment screens disappear automatically after about 15 seconds. This is adjustable through the OSD timeout setting in the setup menu. 2. To select a control to adjust, press to scroll up or down in the Main Menu.
-
Page 9: Main Menu Controls
Main Menu Controls Adjust the menu items shown below by using the up and down buttons. Control Explanation Auto Image Adjust automatically sizes, centers, and fine tunes the video signal to eliminate waviness and distortion. Press the [2] button to execute Auto Image Adjust. - Page 10 sRGB – This is quickly becoming the industry standard for color manage- ment, with support included in many of the latest applications. Enabling this setting allows the LCD display to more accurately display colors the way they were originally intended. Enabling the sRGB setting will cause the Contract and Brightness adjustment to be disabled.
- Page 11 H. Size (Horizontal Size) adjusts the width of the screen image. Fine Tune sharpens the focus by aligning text and/or graphics with pixel boundaries. Note: Try the Auto Adjust function before using the Fine Tune control. Sharpness adjusts the clarity and focus of the screen image. Setup menu displays the menu shown below: Language Select allows the user to choose the language used in the me- nus and control screens.
- Page 12 OSD Position allows the user to move the on-screen display menus and control screens. OSD Timeout sets the length of time the on-screen display screen is dis- played. For example, with a “15 second” setting, if a control is not pushed within 15 seconds, the display screen disappears.
-
Page 13: Information For Resistive Touchscreen Monitors
Information for Resistive Touchscreen Monitors The enclosed CD-ROM contains documentation and drivers for all major operating systems (touchscreen monitors only). To assure you have the most current information, check the following Internet addresses: http://www.hismonitors.com/Touchscreen_Drivers.htm... -
Page 14: Installation Instructions
Installation Instructions Preparing for Installation Important! Perform the following steps BEFORE Installation of the monitor into the panel. 1. Ensure that sufficient power is available. 2. Ensure that sufficient space is available to allow for proper air flow into and out of the unit. 3. - Page 15 Installation into Panel Refer to the drawing below. Locate position in panel for mounting of the monitor. Assure that there is adequate space begin the panel. Allow extra space (0.5 in. behind and on each side) for air ventilation. Cut a rectangular hole in the panel. Clean and deburr. Dimensions: 16.02”...
-
Page 16: Cleaning
Cleaning CAUTION! DO NOT USE ABRASIVE MATERIALS SUCH AS PAPER TOWELS OR DIRTY SHOP RAGS ON THE DISPLAY AS IT WILL SCRATCH THE PROTECTIVE COATING. ALWAYS USE A SOFT CLOTH, PREFERABLY MADE OF COTTON. Resistive Touchscreen model Any standard glass cleaner can be used to clean the touch- screen. -
Page 17: Troubleshooting
Troubleshooting Blank Screen After installing the power adapter and connecting I/O cable to a PC, the monitor displays a blank screen. • Press the power button and check to see if the power LED is lit. • If the LED turns green, make sure the PC is powered on. Make sure all cables are connected. -
Page 18: Drawings
Drawings Front and Side Views 437.78 (17.235) Rear View (Showing Cutout Dimensions) 406 (16.02”) - Page 19 Rear and Bottom Views...
-
Page 20: Specifications
Specifications Display Type Thin-film transistor (TFT) Active Matrix Liquid Crystal Size 15” diagonal Image size 12.0” (304mm) x 9.0” (228mm) Native resolution XGA (1024 x 768) Plug and Play DDC1/2B compatible` Minimum resolution VGA (640 x 480) Pixel pitch 0.297mm x 0.297mm Number of colors 16 million Viewing Angle (Hori/Vert) - Page 21 Electrical Monitor input 100VAC – 240VAC, 50/60Hz, auto switch Power consumption Less than 30W Power management DPMS/energy star, < 1W Environmental Temperature 0-50°C (consult factory for installation instructions when con- tinuous 24/7 operation exceeds 40°C) Humidity 20% to 90% non-condensing Shock 30g (1/2 sine, 11 msec.) Vibration...
- Page 22 Enclosure Type Panel mount; rear collar compresses gasket against panel, held by 12 M5 studs Panel rating NEMA 12/4/4X (with proper installation) – built to IP65 stan- dards Physical Depth 1.8” behind panel maximum Bezel Powder coated carbon steel – matte finish, black; or Stain- less Steel Front bezel outside di- 17.2”...
-
Page 23: Warranty Statement
Warranty Statement Who is Covered? This warranty covers the purchaser of this product only and is not transferable without our written consent. What Does This Warranty Cover and What is the Period of Coverage? We warrant this product to be free from defects in material and workmanship, subject to the condi- tions set forth below. - Page 24 Hope Industrial Systems, Inc. 1325 Northmeadow Parkway Suite 100 Roswell, GA 30076 www.HISmonitors.com 2006 Hope Industrial Systems, Inc. Publication UM-ML15E June, 2006...
