Summary of Contents for Yeti Cycles ASX '07
- Page 1 ASX Owner’S mAnuAl ‘07 Yeti CYCles 600 Corporate CirCle, Unit D GolDen, Co 80401 303.278.6909 / 888.576.9384 www.yeticycles.com...
-
Page 2: Table Of Contents
Table of Contents Brand overview Frame Features Geometry Maintenance schedule Bike setup overview ū shock setup FoX DHX 5.0 ū shock setup Quick start Guide Cable routing ū assembly overview ū assembly Disassembly tips ū exploded Views part list Warranty Contact information... -
Page 3: General Information
Overview welcome to the tribe Congratulations on your purchase of a new Yeti bicycle and welcome to the Yeti tribe. We are confident your new bicycle will exceed your expectations for value, performance, and ride quality. each frameset and component has been custom specified and designed to enhance your riding experience. -
Page 4: Frame Features
frame Features head tube one.point.five. headtube gave us the flexibility to design oversized custom tubes with huge cross-sections for added strength and stiffness. Compatible with 1-1/8” fork with reducers or step- down headset. bottom bracket 73mm shell, for use with a 113mm spindle seatstay (a) + chainstay (b) oversized boxstays are stiff and strong, but still accommodate a 2.5”... -
Page 5: Geometry
Geometry Geometr y as -x 7.1” travel settinG 6.4” travel settinG 17.5 19.0 20.5 17.5 19.0 20.5 21.5 23.0 24.0 21.5 23.0 24.0 66.5 67-68 67-68 66.0 66-67 66-67 67.5 67.5 67.5 67.0 67.0 67.0 17.0 17.0 17.0 17.0 17.0 17.0 42.75 43.75... -
Page 6: Maintenance Schedule
maintenance? if you are having trouble with any of the maintenance tasks that need to be performed contact your local dealer or visit www.parktool.com and check out the repair help section. this section contains detailed instruction on many of the service items listed in the maintenance schedule. -
Page 7: Bike Setup Overview
Bike Setup tools needed shock pump tape Measure 4mm allen key time 15-20 minutes yeti tips inspect your shock and make sure it is in good condition. if oil is leaking or there is visible damaged. the shock should be returned to an authorized Fox racing shox service center for repair. - Page 8 what is pro-pedal? pro-pedal is compression tune that gives the right amount of low speed compression to filter out unwanted rider induced bob without sacrificing critical mid and high speed damping. no flushing through your travel, no wasted setup time, and no energy sucking suspension movement, just super efficient pedaling performance ready Setup - Fox DHX 5.0 for hits of any size.
- Page 9 Quick Setup Guide quick start Guide dhx 5.0 as-x trail ridinG settinGs downhill ridinG settinGs rebound 10 Clicks rebound 10 Clicks Bottom-out resistance 0 turns Bottom-out resistance 1.5 turns pro-pedal 4 Clicks pro-pedal 2 Clicks Boost Valve 125 psi Boost Valve 125 psi saG settinGs sag %...
- Page 10 housinG end caps Yeti recommends using metal end caps. the metal caps do not allow the cable to pull through as do the plastic versions. Do not mix up the shift and brake housing because it will result in a loss in performance. line Setup asX has full cable housing.
-
Page 11: Tools Needed
Warning: Service on Yeti bicycles requires special knowledge and tools. Yeti Cycles recommends that all service and repairs be performed by an authorized Yeti Dealer assembly... - Page 12 thread prep Yeti recommends prepping all threads with loctite or grease. the medium strength (blue) formula along with proper torque is ideal for keep the bolts snug. Assembly linkaGe assembly slightly loosen the socket Cap (M4 X 16 mm) linkaGe assembly if the Guide pin does not slide in easily it is pinch bolts on the shortlink with a 3mm allen key, so the bearings appropriate to tap the pin with a dead blow hammer.
- Page 13 chanGes We strive to make the best bikes in the world, because of this dedication to be the best, we continually make changes to our bikes as needed. as the bikes are improved, assembly and setup instructions may be affected. any amendments to the existing owners Manual can be found on our website.
- Page 14 Assembly Cont. frame assembly lube the Main pivot pin (M6 X 17 X 67.5 mm) with frame assembly rotate the swingarm into position over the end a lithium or ploylube grease. of the shortlink. slide the Guide pin through the seatstay mount as shown.
-
Page 15: Disassembly Tips
Disassembly Tips frame assembly take two 5mm allen keys and loosen the Button Head bolts. frame assembly one of the Button Heads will break free, remove the Button Head and Washer. frame assembly insert the Guide pin with the stepped end inserting into the ti-stud. -
Page 16: Exploded Views
rebuild kits The individual components of each Yeti bike are not sold separately. All yeti parts are sold in rebuild kits. Each and every part can be obtained by purchasing one of the rebuild kits. Cross reference the part number you desire from the parts list to the rebuild list. -
Page 17: Parts List
Parts list PART NUMBER DESCRIPTION QTy. PART NUMBER DESCRIPTION QTy. 200020055 as-X BearinG sHortlink kit 300030069 WasHer ss 8.5MM iD 12.5MM oD .6MM tHk 300030086 pin - steel sHoCk - 1.30 200020044 as-X Master reBUilD kit ‘03 300030088 pin - steel sHoCk - 1.57 300030006 Bolt-BUtton HD M6X1X12 5MM HeX 300030017... -
Page 18: Warranty
(2) two year limited warranty is conditioned upon the bicycle being use of your bicycle. in the event that your frame breaks or malfunctions, Yeti Cycles shall have no liability or ridden under normal conditions and having been properly maintained. this warranty does not apply to the obligation beyond the repair or replacement of your frame pursuant to the terms outlined in the warranty.
