Summary of Contents for Yeti Cycles 303R DH 2013
- Page 1 2010 303R DH OWNER’S MANUAL YETI CYCLES 600 CORPORATE CIRCLE, UNIT D GOLDEN, CO 80401 888.576.9384...
-
Page 2: Table Of Contents
Table of Contents Brand Overview Frame Features Geometry Maintenance Schedule Rail System Lubrication Eccentric Adjustment Shock Setup Shock Setup - quick start guide Cable/Line Setup Assembly Overview Exploded Views Part List Warranty Contact Information... -
Page 3: General Information
Overview welcOme tO the tribe Congratulations on your purchase of a new Yeti bicycle and welcome to the Yeti Tribe. We are confident your new bicycle will exceed your expectations for value, performance, and ride quality. Each frameset and component has been custom specified and designed to enhance your riding experience. -
Page 4: Frame Features
Frame Features head tube Custom butted headtube unique shape provides added strength at the head tube and fork junctions. hydrOfOrmed tubinG The hydrofomed tubes add strength without the added weight penalty over traditional drawn butted tubing inteGrated chainstay prOtectOr The integrated chainstay protector is built specifically for the 303 RDH. -
Page 5: Geometry
Geometry GeO me try 3 0 3 rdh 16.5 16.5 17.0 22.5 23.5 24.5 64-65 64-65 64-65 65-66 65-66 65-66 17.25 17.25 17.25 44.7-44.5 45.7-45.5 46.7-46.5 13.5-14.3 13.8-14.3 13.8-14.3 29.5-30.0 29.5-30.0 29.5-30.0 4.50 4.50 4.50 *All measurements are in inches GeOmetry... -
Page 6: Maintenance Schedule
maintenance? Not sure how to work on your own bike? Contact your authorized Yeti dealer or visit www.parktool.com and check out the repair help section. This section contains detailed instruction on many of the service items listed in the maintenance schedule. Maintenance maintenance tOrque... -
Page 7: Rail System Lubrication
Rail System Lubrication setup Overview Both the rail and block are made from proprietary carbon steel. The rail is then case hardened to between 58 and 64Rc. An Armalloy surface treatment is applied to the rail and the block for corrosion protection and wear resistance. -
Page 8: Eccentric Adjustment
Eccentric Adjustment setup Overview The 303 DH has the ability to change the geometry of the bike via the eccentric mount. The geometry can be adjusted from a 64 degree head angle / 14 inch bottom bracket height through a 66 degree head angle / 15 inch bottom bracket height. -
Page 9: Shock Setup
Shock Setup lOw speed cOmpressiOn The LSC adjuster has an 18 click range setup Overview The DHx RC4 employs both speed sensitive rebound damping and position sensitive of adjustment that is able to be adjusted by hand. The LSC adjuster compression damping. - Page 10 Quick Setup Guide quick start Guide rc4 Rebound 6 Clicks Bottom-Out Resistance 0 Turn Low Speed Compression 6 Clicks High Speed Compression 1 Turn Boost Valve 150 psi saG settinGs Sag % Eye-To-Eye (inches) 8.750” 8.600” 7.95” *All Clicks are clockwise rotation from all the way out or a full counter-clockwise position.
-
Page 11: Cable/Line Setup
Line Setup setup Overview The 303 RDH has full cable housing. utilizing full cable housing helps prevent corrosion from the elements and keeps the shifting smoother for a longer period of time. The 303RDH housing runs internally through the swing arm to protect it from being damaged by chain slap. Caution: The failure to properly route shifter housing can cause malfunction of the shift mechanism and unexpected shifting of gears... - Page 12 Loctite compound or grease. disassembly on each bike Warning: Service on Yeti bicycles requires special knowledge and tools. Yeti Cycles recommends that all service and repairs be performed by an authorized Yeti Dealer assembly...
- Page 13 thread prep Yeti recommends prepping all threads with Loctite or grease. The medium strength (blue) formula along with proper torque is ideal for keep the bolts snug. Assembly main assembly Place the car mount assembly onto the THk© car main assembly Press a 12.7mm x 18mm pivot pin through each of and tighten with four M4x.7x8mm bolts.
- Page 14 Main Assembly main assembly Insert the drive and non-drive side specific bearing main assembly Place the drive retainer caps using four M4x.7x12 flat head bolts with a 2.5mm allen and non-drive side eccentrics in the key. Prep the threads with locktite. push links.
-
Page 15: Exploded Views
rebuild kits The individual components of each Yeti bike are not sold separately. All yeti parts are sold in rebuild kits listed below. Each and every part can be obtained by purchas- ing one of the rebuild kits. Cross reference the part number you desire from the parts list to the rebuild list. -
Page 16: Rebuild Kits
Rebuild Kits PART NUMBER DESCRIPTION QTy. PART NUMBER DESCRIPTION QTy. 200020151 303 RDH ‘09-’10 MASTER REBuILD kIT 300030186 BOLT-TI-FEMALE 8.0x31.0MM 300020030 BEARING 3903 2RS DOuBLE ROW 300030189 PIVOT PIN BOLT M10 x 1 x 22 300020031 BEARING 37802 2RSMAx 300030191 STuD-TI-FEMALE 8x57.5MM 300020034 REDuCER FOx 8x22MM... -
Page 17: Warranty
YETI Cycles is not responsible for any damages to you or others arising from riding, transporting or other use of your bicycle. In the event that your frame breaks or malfunctions, YETI Cycles shall have no liability or materials and/or workmanship. The (2) two year limited warranty is conditioned upon the bicycle being ridden under normal conditions and having been properly maintained.
