- Page 1 A S R O W N E R S M A N U A L Yeti CYCles 600 Corporate Circle, Unit D Golden, CO P//303.278.6909 // 888.576.9384 www.yeticycles.com...
-
Page 2: Table Of Contents
Table of Contents Brand Overview Frame Features Geometry Maintenance Schedule Bike Setup Overview ū Shock Setup FOX RP23 ū Quick Start Guide ū Line Setup Assembly Overview ū Assembly ū Disassembly Tips Exploded Views Part List Warranty Contact Information... -
Page 3: General Information
Overview welCOme tO the tribe Congratulations on your purchase of a new Yeti bicycle and welcome to the Yeti Tribe. We are confident your new bicycle will exceed your expectations for value, performance and ride quality. Each frameset and component has been custom specified and designed to enhance your riding experience. -
Page 4: Frame Features
Frame Features Pure tubinG Yeti Pure tubing is custom butted and tapered to make a lightweight and strong frame without the use of gussets. Unique shape provides added strength at the head tube junctions. bOttOm braCket 73mm shell, for use with a 113mm spindle. CarbOn rear trianGle Carbon chainstay shaves 1/4 of a pound off the frame weight and maintains the lateral rigidity. -
Page 5: Geometry
Geometry G eO metr Y as-r allOY 100 mm fOrk (riDe heiGht 471mm) 80 mm fOrk (riDe heiGht 451mm) 14.5 17.3 18.5 21.3 22.4 23.4 24.4 16.9 16.9 16.9 16.9 16.9 40.2 41.3 42.5 43.5 44.6 12.25 12.25 12.75 12.75 12.75 26.9 27.4... -
Page 6: Maintenance Schedule
maintenanCe? If you are having trouble with any of the maintenance tasks that need to be performed contact your local dealer or visit www.parktool.com and check out the repair help section. This section contains detailed instruction on many of the service items listed in the maintenance schedule. -
Page 7: Bike Setup Overview
Bike Setup tOOls neeDeD Shock Pump Tape Measure time 15-20 minutes Yeti tiPs Inspect your shock for any visible damage. If oil is leaking or you notice any damage to the surfaces or seals, please contact the Fox Racing Shox service center for repair at 800.FOX.SHOX. Removing the shock from the linkage will require the Yeti linkage tool for proper assembly and disassembly. -
Page 8: Quick Start Guide
Quick Start Guide Setup-Fox RP23 air Pressure The main air spring controls the sag of the shock. For quiCk start GuiDe rP23 as-r the AS-R to ride properly it is important to setup the shock with the air sPrinG settinGs correct amount of sag. -
Page 9: Line Setup
hOusinG enD CaPs Yeti recommends using metal end caps to maintain the integrity of the housing. The metal caps do not allow the cable to pull through as do the plastic versions. Do not mix up the shift and brake housing because it will result in a loss in performance. -
Page 10: Assembly
The instructions denote whether to use and disassemble a each bike. a blue Loctite compound or grease. Warning: Service on Yeti bicycles requires special knowledge and tools. Yeti Cycles recommends that all service and repairs be performed by an authorized Yeti dealer. assemblY... - Page 11 threaD PreP Yeti recommends prepping all bolt threads at once on your work bench with Loctite or grease. This will ensure that all bolts are used in assembly. The medium strength (blue) Loctite formula along with proper torque is ideal to keep the bolts snug. Assembly DOGbOne &...
-
Page 12: Disassembly Tips
Assembly Cont. Disassembly Tips mOuntinG rear trianGle Install the main pivot at this point from frame DisassemblY Loosen up seatstay bolts without loosening up the drive side of the bike. Use your dead blow hammer to hammer dogbone bolts. At the seatstay, dogbone and shock junction, back off into place. -
Page 13: Exploded Views
rebuilD kits The individual components of each Yeti bike are not sold separately. All yeti parts are sold in rebuild kits listed below. Each and every part can be obtained by purchas- ing one of the rebuild kits. Cross reference the part number you desire from the parts list to the rebuild list. -
Page 14: Part List
rebuilD kits The individual components of each Yeti bike are not sold separately. All yeti parts are sold in rebuild kits listed below. Each and every part can be obtained by purchas- ing one of the rebuild kits. Cross reference the part number you desire from the parts list to the rebuild list. -
Page 15: Parts List
Parts List PART NUMBER DESCRIPTION QTy. 200020127 AS-R ‘08 ALLOY DOGBONE W/ BEARING 300030036 BEARING 698 MAX EXT RACE 1.5 EXTENDED 300030238 AS-R AL DOGBONE SPACER 19MM OD 14MM ID 7.25MM 300030236 AS-R AL DOGBONE ‘08 XS-S-M-L 200020140 AS-R ‘08 ALLOY BEARING REBUILD 300030036 BEARING 698 MAX EXT RACE 1.5 EXTENDED 300030238... -
Page 16: Warranty
(applies to 303, 4X, DJ) DisClaimer Yeti Cycles will repair or replace, at its option, any frame it determines to be defective materials and / or Yeti Cycles is not responsible for any damages to you or others arising from riding, transporting or other workmanship.
