Model Tech Fun Fighters P-51 ARF Assembly Instructions Manual page 10

❑ Glue the radiator scoop to the bottom of the wing, using a generous amount of 30 minute epoxy. Quickly wipe away any excess
epoxy, using a paper towel and rubbing alcohol, and use pieces of masking tape to hold the radiator scoop in place until the epoxy
fully cures.
STEP 2: INSTALLINg THE WINg-SCREW DOUBLER
IMPORTANT Before gluing the wing-screw doubler into place in the next procedure, remember to first cut away the covering
material from the gluing surfaces to ensure a strong glue joint.
STEP 3: INSTALLINg THE WINg-SCREW DOUBLER
❑ Draw an outline of the radiator scoop onto the bottom of the wing, then
remove the radiator scoop and cut away the covering material from inside
the outline that you drew and from the base of the radiator scoop, too.
IMPORTANT To ensure a strong glue joint, make sure to cut away the
covering material from the gluing surfaces. Do not glue directly to the
covering material, unless otherwise specified.
❑ Cut away the covering material from over the top and bottom of the
predrilled wing-screw mounting hole in the leading edge of the wing. The
predrilled hole is located on the centerline of the wing, 1-1/8" (28mm) behind
the leading edge.
❑ Cut away the covering material from over the predrilled hole in the wing-
screw doubler.
❑ Glue the wing-screw doubler to the bottom of the wing, making sure to
align the predrilled hole in the wing-screw doubler with the predrilled hole in
the wing.
❑ Place the wing into the wing saddle, push it backward completely, then
push the leading edge down into place.
