Summary of Contents for Horizon Hobby Blade Mach 25
- Page 1 Instruction Manual Bedienungsanleitung Manuel d’utilisation Manuale di Istruzioni...
-
Page 2: Safety Precautions And Warnings
NOTICE All instructions, warranties and other collateral documents are subject to change at the sole discretion of Horizon Hobby, LLC. For up-to-date product literature, visit horizonhobby.com and click on the support tab for this product. Meaning of Special Language The following terms are used throughout the product literature to indicate various levels of potential harm when operating this product: NOTICE: Procedures, which if not properly followed, create a possibility of physical property damage AND a little or no possibility of injury. -
Page 3: Table Of Contents
Table of Contents First Flight Preparation .............4 Post-Flight Inspection and Maintenance Checklist ....9 Flying Checklist ...............4 Installing the Propellers............9 Charging Warnings............4 Caring for the Video Transmitter Antenna ......9 Battery Charging ..............4 Troubleshooting Guide ...........10 Transmitter Setup Table ...........5 Exploded View ...............11 SAFE Technology .............5 Parts Listings ..............11 Flight Mode and Rate Selection ........5... -
Page 4: First Flight Preparation
First Flight Preparation Flying Checklist • Remove and inspect contents ❏ Always turn the transmitter on first • Begin charging the flight battery ❏ Plug the flight battery into the lead from the 4-in-1 ESC • Program your computer transmitter ❏... -
Page 5: Transmitter Setup Table
Transmitter Setup Table "Model Transmitter Type" Transmitter Programming Functions Setup List GEAR POS (0) GEAR : ↑ 100%; GEAR/F MODE POS (1) GEAR : ↓ 48% Reverse: Gear – R Throttle Cut: ACT Flaps: Flight Modes: Norm (DN) 100% GEAR (0), ELE D/R (0) = Stability low bank angle DX6i Acro Land (DN) 100%... -
Page 6: Understanding The Primary Flight Controls
Understanding the Primary Flight Controls If you are not familiar with the controls of your quadcopter, take a few minutes to familiarize yourself with them before attempting your first flight. Throttle Left Side View Left Side View Descend Climb Throttle up Throttle down Rudder Rudder left... -
Page 7: Installing The Flight Battery
Installing the Flight Battery 1. Lower the throttle. 2. Power on the transmitter. 3. Center the throttle trim. 4. Attach hook material to the quadcopter frame and loop material to the battery. 5. Install the flight battery on the quadcopter’s bottom frame. Secure the flight battery using the battery o-ring. -
Page 8: Preparing The Mach 25 Quadcopter For Flight
Preparing the Mach 25 Quadcopter for Flight 1. Before each flight, ALWAYS power on the transmitter before connecting the flight battery to the control unit. After each flight, disconnect the flight battery from the control unit before powering off the transmitter. NOTICE: Connecting the flight battery before powering on the transmitter can start the binding process. -
Page 9: Flying The Mach 25
Flying the Mach 25 Quadcopter Takeoff When you are prepared to fly, start the motors by moving both sticks to the bottom inside corners, then back to center. Increase the throttle until the model is approximately 2 ft. (600mm) off the ground and check the trim so the model flies as desired. -
Page 10: Troubleshooting Guide
Troubleshooting Guide Problem Possible Cause Solution Quadcopter not initialized on a level Disconnect the flight battery, center the Quadcopter control response is surface control trim and re-initialize the quadcopter inconsistent or requires extra Battery not correctly placed in Adjust battery position so quadcopter trim to neutralize movement battery slot balances in the center of the frame... -
Page 11: Exploded View
Exploded View Electronics Wiring Battery Diagram Parts Listings Part # Description Part # Description 1 BLH8901 Frame Set: Mach 25 FPV 10 BLH8910 Propeller Set: Mach 25 FPV 2 BLH8902 Camera Mount: Mach 25 FPV 11 BLH8911 Body Set: Mach 25 FPV 3 BLH8903 Arm Clamp (4): Mach 25 FPV 12 BLH8912... -
Page 12: Limited Warranty
Limited Warranty What this Warranty Covers questions and service you in the event that you may need any assistance. For questions or assistance, please visit our website Horizon Hobby, LLC (Horizon) warrants to the original purchaser at www.horizonhobby.com, submit a Product Support Inquiry, or that the product purchased (the "Product") will be free from call the toll free telephone number referenced in the Warranty defects in materials and workmanship at the date of purchase. and Service Contact Information section to speak with a Product What is Not Covered Support representative. This warranty is not transferable and does not cover (i) cosmetic Inspection or Services damage, (ii) damage due to acts of God, accident, misuse, If this Product needs to be inspected or serviced and is compli- abuse, negligence, commercial use, or due to improper use, ant in the country you live and use the Product in, please use installation, operation or maintenance, (iii) modification of or to the Horizon Online Service Request submission process found any part of the Product, (iv) attempted service by anyone other on our website or call Horizon to obtain a Return Merchandise than a Horizon Hobby authorized service center, (v) Product not Authorization (RMA) number. Pack the Product securely purchased from an authorized Horizon dealer, (vi) Product not using a shipping carton. Please note that original boxes may or (vii) use compliant with applicable technical regulations, or be included, but are not designed to withstand the rigors of that violates any applicable laws, rules, or regulations shipping without additional protection. Ship via a carrier that OTHER THAN THE EXPRESS WARRANTY ABOVE, HORIZON... -
Page 13: Warranty And Service Contact Information
Horizon Hobby Limited +44 (0) 1279 641 097 Kingdom Horizon Technischer Service service@horizonhobby.de Christian-Junge-Straße 1 Germany 25337 Elmshorn, Germany Sales: Horizon Hobby GmbH +49 (0) 4121 2655 100 infofrance@horizonhobby.com Service/Parts/Sales: 11 Rue Georges Charpak France Horizon Hobby SAS 77127 Lieusaint, France +33 (0) 1 60 18 34 90 info@horizonhobby.com.cn...
